6102-3

Connectors (Inlets/Outlets) www.schurter.com/pg07 IEC Appliance Inlet C18, Screw-on Mounting, Front or Rear Side, Solder or Quick-connect Terminal 602-3 6102-3 C18 70° C Description - Panel Mount: Screw-on mounting from front or rear-side - Appliance Inlet, Pin temperature 70 °C, Protection class II - Solder terminals or quick connect terminals - Alternative: Version in protection class I 6100-3 Other versions on request - Types for rivet mounting available upon request - Sealing (IP54) of appliance and power input - Types for enhanced glow wire test requirements acc. IEC 60695-211 to -13 for the use in unattended household equipment acc. IEC 60335-1 Approvals References Weblinks - VDE License Number: 40015595 - UL License Number: E96454 General Product Information Approvals, RoHS, CHINA-RoHS, Mating Connectors, e-Store, Distributor-Stock-Check, Accessories Technical Data Ratings IEC Ratings UL/CSA Dielectric Strength Allowable Operation Temp. Degree of Protection Protection Class Terminal Panel Thickness s Material: Housing 10 A / 250 VAC; 50 Hz 15 A / 250 VAC; 60 Hz > 2 kVAC between L-N (1 min/50 Hz) -25 °C to 70 °C from front side IP 40 acc. to IEC 60529 Suitable for appliances with protection class 2 acc. to IEC 61140 Solder terminals or quick connect terminals Screw: max 8 mm Mounting screw torque max 0.5 Nm Thermoplastic, black, UL 94V-0 Appliance Inlet C18 acc. to IEC/EN 60320-1, UL 498, CSA C22.2 no. 42 (for cold conditions) pin-temperature 70 °C, 10 A, Protection Class 2 Dimensions 6100-3 (6102-3) 6.3x90˚ 3.5 48 mm 2.5 M3 max.R3 E 5 min.27.5 40 40 48 E: Solder terminals 20.5 mm E: Quick connect terminals 23.5 mm Connectors min.20 23  602-3 www.schurter.com/pg07 Variants Type 6102-3 6102-3 6102-3 Protection Class 2 2 2 Panel mounting Screw Screw Screw Panel Thickness s [mm] Terminal Quick connect terminals 4.8 x 0.8 mm Quick connect terminals 6.3 x 0.8 mm Solder terminals 3.8 x 0.8 mm Connectors (Inlets/Outlets) Order Number 6102.3200 6102.3300 6102.3100 Option with IP54 sealing protects from entering fluids and dust into the appliance and the power input. This option can be ordered with ending ".30" (61xx. xxxx.30). The sealing to the appliance on its own (no protection of power input) is available as accessory (sealing kit). Articles for enhanced glow wire test requirements acc. IEC 60695-2-11 to -13 can be ordered with ending ".15" (xxxx.xxxx.15). They are suitable for the use in unattended household equipment acc. IEC 60335-1. Packaging unit Accessories 50 Pcs Description Sealing Kit Sealing for Appliance Inlets IP 54 0098.0103 Assorted Covers Rear Cover 0859.0048 4311.9401 4311.9402 4311.9404 Cord retaining kits Cord retaining strain relief Flat head, A 4700.0001 Mating Outlets/Connectors Category / Description Connector Overview complete IEC Connector C15, Rewireable, Straight IEC Connector C15A, Rewireable, Straight IEC Connector C15A, Rewireable, Straight IEC Connector C15A, Rewireable, Angled IEC Connector C13, Rewireable, Angled Connector further types to 6102-3 Power Cord Overview complete Power Cord with IEC Connector C17, Angled Power Cord with IEC Connector C13, Angled Power Cord with IEC Connector C13, Angled Power Cord with IEC Connector C13, Angled Power Cord with IEC Connector C13, Angled Power Cord further types to 6102-3 0301 0311 3011 3012 3013 ... 0101 0102 0102-G 0112 4012 ... 2 Connectors Connectors (Inlets/Outlets) www.schurter.com/pg07 602-3 Category / Description Power Supply or Interconnection Cord Overview complete Divers Power Supply and Interconnection Cords 10 A Power Supply or Interconnection Cord further types to 6102-3 Kabelverbindung/10 A The specifications, descriptions and illustrations indicated in this document are based on Connectors current information. All content is subject to modifications and amendments. 3
