T2-05

T2-05 Miniature diaphragm pumps FEATURES · Ultra-compact size, long life, and high efficiency · Ideal for use in portable air and gas applications · Quiet operation and low vibration · Intrinsically safe motor · Broad media compatibility · Contamination-free WETTED MATERIALS Diaphragm: EPDM Valve: EPDM Head: ABS ELECTRICAL Voltage (nominal) Max. power @ nom. voltage Electrical termination 3.3 VDC 0.36 W 5.9 inch wire leads SPECIFICATIONS Max. ambient and media temperature Weight 0 to +50 °C 14 g August 2007 / 266 1/3 www.sensortechnics.com T2-05 Miniature diaphragm pumps PERFORMANCE CHARACTERISTICS (Standard conditions: 22 °C (70 °F) and 14.7 psia) Part no. T5-1HE-03-1EEB Max. flow 0.65 lpm Max. pressure Max. vacuum (intermittent and continuous) (intermittent and continuous) 430 mbar (6.2 psi) 365 mbar (10.8 inch Hg) FLOW CURVE August 2007 / 266 2/3 www.sensortechnics.com T2-05 Miniature diaphragm pumps OUTLINE DRAWING third angle projection dimensions in inches (mm) ORDERING INFORMATION Order no: T5-1HE-03-1EEB Note: Custom specific modifications are widely available. Please contact your nearest Sensortechnics sales office for further information. Sensortechnics reserves the right to make changes to any products herein. Sensortechnics does not assume any liability arising out of the application or use of any product or circuit described herein, neither does it convey any license under its patent rights nor the rights of others. August 2007 / 266 3/3 www.sensortechnics.com
