SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
GENERAL DESCRIPTION
FEATURES
The SGM8091/3 (single), SGM8092 (dual) and SGM8094
● Rail-to-Rail Output
(quad) are rail-to-rail output voltage feedback amplifiers
● Input Offset Voltage: 8mV (MAX)
offering ease of use and low cost. They have bandwidth
● High Speed:
and slew rate typically found in current feedback
350MHz, -3dB Bandwidth (G = +1)
amplifiers. All have a wide input common mode voltage
265V/μs, Slew Rate
range and output voltage swing, making them easy to
32ns Settling Time to 0.1% with 2V Step
use on single supply as low as 2.5V.
Despite being low cost, the SGM8091 series provide
excellent overall performance. They offer wide bandwidth
to 350MHz (G = +1) along with 0.1dB flatness out to
125MHz (G = +1) and offer a typical low power of
4.3mA/amplifier.
The SGM8091 series are low distortion and fast settling,
making them ideal for buffering high speed A/D or D/A
converters. The SGM8093 has a power-down disable
feature that reduces the supply current to 75μA. These
features make the SGM8093 ideal for portable and
battery-powered applications where size and power are
critical. All are specified over the extended -40℃ to
+125℃ temperature range.
● Supply Voltage Range: 2.5V to 5.5V
● Input Voltage Range: -0.2V to 3.8V with VS = 5V
● Excellent Video Specs (RL = 150Ω, G = +2):
Gain Flatness 0.1dB to 70MHz
Diff Gain: 0.004%, Diff Phase: 0.08 Degree
● Low Supply Current:
4.3mA/Amplifier (TYP)
75μA Shutdown Current for SGM8093
● -40℃ to +125℃ Operating Temperature Range
● Small Packaging:
SGM8091 Available in SOIC-8 and SOT-23-5
SGM8092 Available in SOIC-8 and MSOP-8
SGM8093 Available in SOIC-8 and SOT-23-6
SGM8094 Available in SOIC-14 and TSSOP-14
APPLICATIONS
3
Photodiode Preamp
0
Professional Video and Camera
Hand Set
DVD/CD
Base Station
Filter
Normalized Gain (dB)
Imaging
Small Signal Frequency Response
V O = 0.1V P-P
G = +1
RL = 1kΩ
RF = 24Ω
-3
-6
-9
G = +2
RL = 150Ω
RF = 600Ω
-12
-15
A-to-D Driver
SG Micro Corp
www.sg-micro.com
1
10
100
1000
Frequency (MHz)
JANUARY 2013 – REV. B. 4
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
PACKAGE/ORDERING INFORMATION
MODEL
PACKAGE
DESCRIPTION
SPECIFIED
TEMPERATURE
RANGE
ORDERING
NUMBER
PACKAGE
MARKING
PACKING
OPTION
SOT-23-5
-40℃ to +125℃
SGM8091XN5/TR
8091
Tape and Reel, 3000
SOIC-8
-40℃ to +125℃
SGM8091XS/TR
SGM8091XS
XXXXX
Tape and Reel, 2500
SOIC-8
-40℃ to +125℃
SGM8092XS/TR
SGM8092XS
XXXXX
Tape and Reel, 2500
MSOP-8
-40℃ to +125℃
SGM8092XMS/TR
SGM8092
XMS
XXXXX
Tape and Reel, 3000
SOT-23-6
-40℃ to +125℃
SGM8093XN6/TR
8093
Tape and Reel, 3000
SOIC-8
-40℃ to +125℃
SGM8093XS/TR
SGM8093XS
XXXXX
Tape and Reel, 2500
SOIC-14
-40℃ to +125℃
SGM8094XS14/TR
SGM8094XS14
XXXXX
Tape and Reel, 2500
TSSOP-14
-40℃ to +125℃
SGM8094XTS14/TR
SGM8094
XTS14
XXXXX
Tape and Reel, 3000
SGM8091
SGM8092
SGM8093
SGM8094
MARKING INFORMATION
NOTE: XXXXX = Date Code and Vendor Code.
SOIC-8/MSOP-8/SOIC-14/TSSOP-14
XXXXX
Vendor Code
Date Code - Week
Date Code - Year
Green (RoHS & HSF): SG Micro Corp defines "Green" to mean Pb-Free (RoHS compatible) and free of halogen substances. If
you have additional comments or questions, please contact your SGMICRO representative directly.
SG Micro Corp
www.sg-micro.com
JANUARY 2013
2
SGM8091/SGM8092
SGM8093/SGM8094
ABSOLUTE MAXIMUM RATINGS
Supply Voltage, +VS to -VS ............................................. 7.5V
Input Common Mode Voltage Range
.................................................... (-VS) - 0.5V to (+VS) + 0.5V
Package Thermal Resistance @ TA = +25℃
SOT-23-5, θJA .......................................................... 190℃/W
SOT-23-6, θJA .......................................................... 190℃/W
SOIC-8, θJA... ........................................................... 125℃/W
MSOP-8, θJA ............................................................ 216℃/W
Junction Temperature .................................................+150℃
Storage Temperature Range ....................... -65℃ to +150℃
Lead Temperature (Soldering, 10s) ............................+260℃
ESD Susceptibility
HBM ............................................................................. 1000V
MM ................................................................................. 400V
RECOMMENDED OPERATING CONDITIONS
Operating Temperature Range ..................... -40℃ to +125℃
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
OVERSTRESS CAUTION
Stresses beyond those listed in Absolute Maximum Ratings
may cause permanent damage to the device. Exposure to
absolute maximum rating conditions for extended periods
may affect reliability. Functional operation of the device at any
conditions beyond those indicated in the Recommended
Operating Conditions section is not implied.
ESD SENSITIVITY CAUTION
This integrated circuit can be damaged by ESD if you don’t
pay attention to ESD protection. SGMICRO recommends that
all integrated circuits be handled with appropriate precautions.
Failure to observe proper handling and installation procedures
can cause damage. ESD damage can range from subtle
performance degradation to complete device failure. Precision
integrated circuits may be more susceptible to damage
because very small parametric changes could cause the
device not to meet its published specifications.
DISCLAIMER
SG Micro Corp reserves the right to make any change in
circuit design, or specifications without prior notice.
SG Micro Corp
www.sg-micro.com
JANUARY 2013
3
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
PIN CONFIGURATIONS
SGM8091 (TOP VIEW)
1
-VS
2
+IN
3
5
+
+VS
_
4
-IN
OUT
1
-VS
2
+IN
3
8093
OUT
SGM8093 (TOP VIEW)
+
_
6
+VS
5
DISABLE
4
-IN
SOT-23-5
SOT-23-6
SGM8092 (TOP VIEW)
SGM8091/8093 (TOP VIEW)
OUTA
1
-INA
2
_
+INA
3
+
-VS
4
8
+VS
NC
1
7
OUTB
-IN
2
_
6
-INB
+IN
3
+
5
+INB
-VS
4
8
DISABLE
(SGM8093 ONLY)
_
7
+VS
+
6
OUT
5
NC
NC = NO CONNECT
SOIC-8/MSOP-8
SOIC-8
SGM8094 (TOP VIEW)
OUTA
1
-INA
2
_
+INA
3
+
+VS
4
+INB
5
+
-INB
6
_
OUTB
7
14
OUTD
_
13
-IND
+
12
+IND
11
-VS
+
10
+INC
_
9
-INC
8
OUTC
SOIC-14/TSSOP-14
SG Micro Corp
www.sg-micro.com
JANUARY 2013
4
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
ELECTRICAL CHARACTERISTICS
(VS = 5V, G = +2, RF =600Ω, RL = 150Ω, unless otherwise noted.)
SGM8091/2/3/4
PARAMETER
CONDITIONS
TYP
+25℃
Dynamic Performance
-3dB Small Signal Bandwidth
Gain-Bandwidth Product
Bandwidth for 0.1dB Flatness
Slew Rate
Rise-and-Fall Time
Settling Time to 0.1%
Overload Recovery Time
Noise/Distortion Performance
Input Voltage Noise
Differential Gain Error (NTSC)
Differential Phase Error (NTSC)
DC Performance
Input Offset Voltage (VOS)
Input Offset Voltage Drift
Input Bias Current (IB)
Input offset Current (IOS)
Open-Loop Gain (AOL)
Input Characteristics
Input Common Mode Voltage Range
(VCM)
Common Mode Rejection Ratio (CMRR)
Output Characteristics
Output Voltage Swing from Rail
Output Current
Closed-Loop Output Impedance
Power-Down Disable
Turn-On Time
Turn-Off Time
DISABLE Voltage-Off
DISABLE Voltage-On
Power Supply
Operating Voltage Range
Quiescent Current (per Amplifier)
Supply Current when Disabled
(SGM8093 only)
Power Supply Rejection Ratio (PSRR)
SG Micro Corp
www.sg-micro.com
G = +1, VO = 0.1VP-P, RF = 24Ω, RL = 150Ω
G = +1, VO = 0.1VP-P, RF = 24Ω, RL = 1kΩ
G = +2, VO = 0.1VP-P, RL = 50Ω
G = +2, VO = 0.1VP-P, RL = 150Ω
G = +2, VO = 0.1VP-P, RL = 1kΩ
G = +2, VO = 0.1VP-P, RL = 10kΩ
G = +10, RL =150Ω
G = +10, RL =1kΩ
G = +1, VO = 0.1VP-P
G = +2, VO = 0.1VP-P, RF = 600Ω
G = +1, 2V output step
G = +2, 2V output step
G = +2, 4V output step
G = +2, VO = 0.2VP-P, 10% to 90%
G = +2, VO = 2VP-P, 10% to 90%
G = +2, 2V output step
VIN · G = +VS
f = 1MHz
G = +2, RL = 150Ω
G = +2, RL = 150Ω
VO = 0.3V to 4.7V, RL = 150Ω
VO = 0.2V to 4.8V, RL = 1kΩ
VCM = -0.1V to 3.5V
RL = 150Ω
RL = 1kΩ
f＜100kHz
+25℃
0℃ to
+70℃
-40℃ to
+70℃
-40℃ to
+125℃
300
350
70
140
170
230
135
170
125
70
194/-204
236/-170
265/-218
3.8
7.8
32
14.5
5.9
0.004
0.08
UNITS
MIN/
MAX
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
V/μs
V/μs
V/μs
ns
ns
ns
ns
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
TYP
nV/ Hz
%
degree
TYP
TYP
TYP
MAX
TYP
TYP
TYP
MIN
MIN
±2
3.7
6
2
80
104
±8
±8.9
±9.5
±9.8
75
92
74
91
74
91
73
80
mV
μV/℃
PA
PA
dB
dB
-0.2 to +3.8
80
66
66
65
64
V
dB
TYP
MIN
V
V
mA
Ω
TYP
TYP
MIN
TYP
ns
ns
V
V
TYP
TYP
MAX
MIN
0.12
0.03
115
0.02
108
60
ΔVS = 2.7V to 5.5V, VCM = (-VS) + 0.5
MIN/MAX OVER TEMPERATURE
98
97
94
88
0.8
2
4.3
75
2.5
5.5
7.5
120
2.7
5.5
8.0
127
2.7
5.5
8.0
130
2.7
5.5
8.1
137
V
V
mA
μA
MIN
MAX
MAX
MAX
80
66
66
64
62
dB
MIN
JANUARY 2013
5
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
TYPICAL PERFORMANCE CHARACTERISTICS
At TA = +25℃, VS = 5V, G = +2, RF = 600Ω, RG = 600Ω, and RL= 150Ω connected to VS/2, unless otherwise noted.
Non-Inverting Small Signal Frequency Response
RF = 24Ω
G = +1
V O = 0.1V P-P
0
-3
G = +2
-6
G = +5
-9
G = +10
-12
-15
V O = 0.1V P-P
-3
G = -2
-6
G = -5
-9
G = -10
-12
0.1
RL = 10kΩ
Normalized Gain (dB)
CL = 0pF
V O = 0.1V P-P
-3
-6
RL = 150Ω
-9
-12
RL = 50Ω
1
10
100
CL = 100pF
RS = 33.2Ω
-3
-6
VIN
+
V+
SGM8091
V-
-12
V O = 0.1V P-P
CL = 0pF
10
100
Frequency(MHz)
RF = 510Ω
1000
CL = 100pF
RS = 0Ω
V O = 0.1V P-P
6
RF = 600Ω
Vo
Frequency Response for Various CL
9
RF = 620Ω
CL = 47pF
RS =50Ω
(RL is
Optional)
1
Normalized Gain (dB)
0.5
0.4
0.3
0.2
0.1
0
-0.1
-0.2
-0.3
-0.4
-0.5
CL
RF=600Ω
Frequency (MHz)
0.1dB Gain Flatness for Various RF
Rs
-
-9
1000
1000
CL = 6pF
RS =100Ω
V O = 0.1V P-P
0
-15
-15
10
100
Frequency (MHz)
Frequency Response vs. CL
3
RL = 1kΩ
0
1
RL=150Ω
1000
RG=600Ω
10
100
Frequency (MHz)
Frequency Response for Various RL
3
Normalized Gain (dB)
G = -1
0
-15
1
Normalized Gain (dB)
Inverting Small Signal Frequency Response
3
Normalized Gain (dB)
Normalized Gain (dB)
3
3
CL = 47pF
0
-3
CL = 6pF
-6
-9
-12
1
10
Frequency (MHz)
SG Micro Corp
www.sg-micro.com
100
-15
1
10
100
1000
Frequency (MHz)
JANUARY 2013
6
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
TYPICAL PERFORMANCE CHARACTERISTICS (continued)
At TA = +25℃, VS = 5V, G = +2, RF = 600Ω, RG = 600Ω, and RL= 150Ω connected to VS/2, unless otherwise noted.
Non-Inverting Large Signal Step Response
Output Voltage (50mV/div)
Output Voltage (500mV/div)
Non-Inverting Small Signal Step Response
Time (50ns/div)
Time (50ns/div)
V S = 5V
G = +2
f IN = 2MHz
5
4
3
2
Disabled
1
V OUT = 2V
0
-1
dG/dP (%/degrees)
Output Voltage (1V/div)
Enabled
6
Disable Voltage (V)
Large-Signal Disable/Enable Response
Output Voltage (V p-p)
4
2
3
4
Rail-to-Rail
Maximum Output Voltage
w ithout Slew -Rate
Induced Distortion
V S = 5.5V
dG
Number of 150Ω Loads
Maximum Output Voltage vs. Frequency
5
dP
1
Time (500ns/div)
6
Composite Video Differential Gain and Phase
1.2
1.1
1
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
4.88V
G = +2
RF = 600Ω
R
3
1kΩ
V S = 2.7V
2
1
0V
0
1
10
Frequency (MHz)
SG Micro Corp
www.sg-micro.com
100
Time (200ns/div)
JANUARY 2013
7
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
TYPICAL PERFORMANCE CHARACTERISTICS (continued)
At TA = +25℃, VS = 5V, G = +2, RF = 600Ω, RG = 600Ω, and RL= 150Ω connected to VS/2, unless otherwise noted.
Pow er Supply Rejection Ratio vs. Frequency
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
-100
0.01
PSRR (dB)
CMRR (dB)
Common Mode Rejection Ratio vs. Frequency
0.1
1
10
100
1000
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
-100
0.01
-PSRR
+PSRR
0.1
1
Frequency (MHz)
Closed-Loop Output Impedance vs. Frequency
100
-
Zo
V-
1
Disabled Isolation (dB)
10
RF=600Ω
0.1
0.01
1000
V O = 0.2V P-P
V DISABLE = 0V
RL = 1kΩ
-20
-30
-40
-50
-60
-70
-80
0.001
0.01
0.7
-90
0.1
1
10
100
1
100
1000
Frequency (MHz)
Output Settling Time to 0.1%
Input Voltage Noise Spectral Density vs. Frequency
1000
V O = 2V P-P
Voltage Noise (nV/√Hz)
0.3
0.1
-0.1
-0.3
-0.5
0
10
Frequency (MHz)
0.5
Output Error (%)
100
Disabled Output Isolation Frequency Response
-10
SGM8091
RG=600Ω
Output Impedance (Ω)
0
V+
+
10
Frequency (MHz)
10
20
Time (ns)
SG Micro Corp
www.sg-micro.com
30
40
50
100
10
1
0.01
0.1
1
10
100
1000 10000
Frequency (kHz)
JANUARY 2013
8
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
TYPICAL PERFORMANCE CHARACTERISTICS (continued)
At TA = +25℃, VS = 5V, G = +2, RF = 600Ω, RG = 600Ω, and RL= 150Ω connected to VS/2, unless otherwise noted.
Open-Loop Gain vs. Temperature
CMRR and PSRR vs. Temperature
120
110
RL = 1kΩ
110
CMRR, PSRR (dB
Open–Loop Gain (dB)
120
100
RL = 150Ω
90
80
PSRR
100
90
80
CMRR
70
70
-50 -30 -10 10
30
50
70
60
-50 -30 -10 10
90 110 130
Temperature (℃)
Shudow n Current vs. Temperature
75
65
V S = 3V
60
V S = 2.7V
55
50
45
40
-50 -30 -10 10
5
4
3.5
2.5
30
50
70
2
-50 -30 -10 10
90 110 130
3
25℃
V S = 5V
135℃
1
-50℃
Sourcing Current
-50℃
Sinking Current
0
0
25
50
75
100
Output Current (mA)
SG Micro Corp
www.sg-micro.com
50
70
90 110 130
125
Output Voltage Sw ing vs. Output Current
3
2
25℃
30
Temperature (℃)
Output Voltage (V)
Output Voltage (V)
135℃
V S = 3V
V S = 2.7V
3
Output Voltage Sw ing vs. Output Current
4
90 110 130
V S = 5V
4.5
Temperature (℃)
5
70
5.5
V S = 5V
70
50
Supply Current vs. Temperature
6
Supply Current (mA)
Shutdown Current (μA)
80
30
Temperature (℃)
Sourcing Current
135℃
2
25℃
V S = 3V
1
135℃
25℃
-50℃
-50℃
Sinking Current
0
150
0
20
40
60
80
100
120
Output Current (mA)
JANUARY 2013
9
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
TYPICAL PERFORMANCE CHARACTERISTICS (continued)
At TA = +25℃, VS = 5V, G = +2, RF = 600Ω, RG = 600Ω, and RL= 150Ω connected to VS/2, unless otherwise noted.
V S = ±2.5V
V IN = 2.32V
G = +2
2.5V
2.32V
0V
Time (25ns/div)
Channel Separation (dB)
Overload Recovery Time
Channel Separation vs. Frequency
-20
-30
-40
-50
-60
-70
-80
-90
-100
-110
-120
0.1
1
10
100
Frequency (MHz)
1000
Percentange of Amplifiers (%)
Offset Voltage Production Distribution
22
20
18
16
14
12
10
8
6
4
2
0
Typical production
distribution of
packaged units.
-8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8
Offset Voltage (mV)
SG Micro Corp
www.sg-micro.com
JANUARY 2013
10
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
APPLICATION NOTES
Driving Capacitive Loads
The SGM8091/2/3/4 are optimized for bandwidth and
speed, not for driving capacitive loads. Output capacitance
will create a pole in the amplifier’s feedback path,
leading to excessive peaking and potential oscillation. If
dealing with load capacitance is a requirement of the
application, the two strategies to consider are (1) using
a small resistor in series with the amplifier’s output and
the load capacitance and (2) reducing the bandwidth of
the amplifier’s feedback loop by increasing the overall
noise gain.
Figure 1 shows a unity gain follower using the series
resistor strategy. The resistor isolates the output from
the capacitance and, more importantly, creates a zero
in the feedback path that compensates for the pole
created by the output capacitance.
For the high speed operational amplifier, soldering the
part to the board directly is strongly recommended. Try
to keep the high frequency current loop area small to
minimize the EMI (electromagnetic interference).
+VS
+VS
10μF
10μF
0.1μF
0.1μF
VN
VN
_
VOUT
SGM8091
VP
_
VOUT
SGM8091
VP
+
+
10μF
0.1μF
-VS (GND)
_
RISO
SGM8091
VIN
+
VOUT
-VS
CL
Figure 1. Series Resistor Isolating Capacitive Load
Power Supply Bypassing and Layout
The SGM8091/2/3/4 operate from either a single 2.7V
to 5.5V supply or dual ±1.35V to ±2.75V supplies. For
single-supply operation, bypass the power supply +VS
with a 0.1µF ceramic capacitor which should be placed
close to the +VS pin. For dual-supply operation, both
the +VS and the -VS supplies should be bypassed to
ground with separate 0.1µF ceramic capacitors. 2.2µF
tantalum capacitor can be added for better performance.
Figure 2. Amplifier with Bypass Capacitors
Grounding
A ground plane layer is important for high speed circuit
design. The length of the current path in an inductive
ground return will create an unwanted voltage noise.
Broad ground plane areas will reduce the parasitic
inductance.
Input-to-Output Coupling
To minimize capacitive coupling, the input and output
signal traces should not be in parallel. This helps
reduce unwanted positive feedback.
Good PC board layout techniques optimize performance
by decreasing the amount of stray capacitance at the
operational amplifier’s inputs and output. To decrease
stray capacitance, minimize trace lengths and widths
by placing external components as close to the device
as possible. Use surface-mount components whenever
possible.
SG Micro Corp
www.sg-micro.com
JANUARY 2013
11
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
TYPICAL APPLICATION CIRCUITS
Differential Amplifier
The circuit shown in Figure 3 performs the difference
function. If the resistor ratios are equal (R4/R3 = R2/R1),
then VOUT = (VP - VN) × R2/R1 + VREF.
Driving Video
The SGM8091/2/3/4 can be used in video applications
as shown in Figure 5.
VIN
R2
+
75Ω
SGM8091
R1
VN
_
_
SGM8091
VP
R3
75Ω
CABLE
VOUT
+
RF
VOUT
RG
75Ω
R4
G = 1 + RF/RG
VREF
Figure 5. Typical Video Driving
Figure 3. Differential Amplifier
Active Low-Pass Filter
The low-pass filter shown in Figure 4 has a DC gain of
(-R2/R1) and the -3dB corner frequency is 1/2πR2C.
Make sure the filter bandwidth is within the bandwidth
of the amplifier. Feedback resistors with large values
can couple with parasitic capacitance and cause
undesired effects such as ringing or oscillation in
high-speed amplifiers. Keep resistor values as low as
possible and consistent with output loading consideration.
C
R2
R1
VIN
_
SGM8091
VOUT
+
R3 = R1 // R2
Figure 4. Active Low-Pass Filter
SG Micro Corp
www.sg-micro.com
JANUARY 2013
12
SGM8091/SGM8092
SGM8093/SGM8094
350MHz, Rail-to-Rail Output
CMOS Operational Amplifiers
REVISION HISTORY
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
JANUARY 2013 ‒ REV.B.3 to REV.B.4
Page
Updated Package Outline Dimensions section ............................................................................................................................................ 14~19
Added Tape and Reel Information section ................................................................................................................................................... 20, 21
MAY 2011 ‒ REV.B.2 to REV.B.3
Page
Changed packages’ name ................................................................................................................................................................................. All
JUNE 2010 ‒ REV.B.1 to REV.B.2
Page
Changed Electrical Characteristics section .......................................................................................................................................................... 3
Changed Package Outline Dimensions section ........................................................................................................................................... 11~16
APRIL 2009 ‒ REV.B to REV.B.1
Page
Changed 16pin packages to 14pin packages..................................................................................................................................................... All
AUGUST 2008 ‒ REV.A to REV.B
Page
Changed Absolute Maximum Ratings section ...................................................................................................................................................... 3
Changes from Original (NOVEMBER 2006) to REV.A
Page
Changed from product preview to production data ............................................................................................................................................. All
SG Micro Corp
www.sg-micro.com
JANUARY 2013
13
PACKAGE INFORMATION
PACKAGE OUTLINE DIMENSIONS
SOT-23-5
1.90
D
e1
E1
2.59
E
0.99
b
e
0.69
0.95
RECOMMENDED LAND PATTERN (Unit: mm)
L
A
A1
θ
A2
Symbol
Dimensions
In Millimeters
MIN
MAX
c
0.2
Dimensions
In Inches
MIN
MAX
A
1.050
1.250
0.041
0.049
A1
0.000
0.100
0.000
0.004
A2
1.050
1.150
0.041
0.045
b
0.300
0.500
0.012
0.020
c
0.100
0.200
0.004
0.008
D
2.820
3.020
0.111
0.119
E
1.500
1.700
0.059
0.067
E1
2.650
2.950
0.104
0.116
e
0.950 BSC
0.037 BSC
e1
1.900 BSC
0.075 BSC
SG Micro Corp
www.sg-micro.com
L
0.300
0.600
0.012
0.024
θ
0°
8°
0°
8°
TX00033.000
PACKAGE INFORMATION
PACKAGE OUTLINE DIMENSIONS
SOT-23-6
D
e1
e
2.59
E
E1
0.99
b
0.95
0.69
RECOMMENDED LAND PATTERN (Unit: mm)
L
A
A1
θ
A2
Symbol
Dimensions
In Millimeters
MIN
MAX
c
0.2
Dimensions
In Inches
MIN
MAX
A
1.050
1.250
0.041
0.049
A1
0.000
0.100
0.000
0.004
A2
1.050
1.150
0.041
0.045
b
0.300
0.500
0.012
0.020
c
0.100
0.200
0.004
0.008
D
2.820
3.020
0.111
0.119
E
1.500
1.700
0.059
0.067
E1
2.650
2.950
0.104
0.116
e
0.950 BSC
0.037 BSC
e1
1.900 BSC
0.075 BSC
SG Micro Corp
www.sg-micro.com
L
0.300
0.600
0.012
0.024
θ
0°
8°
0°
8°
TX00034.000
PACKAGE INFORMATION
PACKAGE OUTLINE DIMENSIONS
SOIC-8
0.6
D
e
2.2
E1
E
5.2
b
1.27
RECOMMENDED LAND PATTERN (Unit: mm)
L
A
A1
c
θ
A2
Symbol
Dimensions
In Millimeters
MIN
MAX
Dimensions
In Inches
MIN
MAX
A
1.350
1.750
0.053
0.069
A1
0.100
0.250
0.004
0.010
A2
1.350
1.550
0.053
0.061
b
0.330
0.510
0.013
0.020
c
0.170
0.250
0.006
0.010
D
4.700
5.100
0.185
0.200
E
3.800
4.000
0.150
0.157
E1
5.800
6.200
0.228
0.244
e
SG Micro Corp
www.sg-micro.com
1.27 BSC
0.050 BSC
L
0.400
1.270
0.016
0.050
θ
0°
8°
0°
8°
TX00010.000
PACKAGE INFORMATION
PACKAGE OUTLINE DIMENSIONS
MSOP-8
b
E1
E
4.8
1.02
e
0.41
0.65
RECOMMENDED LAND PATTERN (Unit: mm)
D
L
A
A1
c
θ
A2
Symbol
Dimensions
In Millimeters
MIN
MAX
Dimensions
In Inches
MIN
MAX
A
0.820
1.100
0.032
0.043
A1
0.020
0.150
0.001
0.006
A2
0.750
0.950
0.030
0.037
b
0.250
0.380
0.010
0.015
c
0.090
0.230
0.004
0.009
D
2.900
3.100
0.114
0.122
E
2.900
3.100
0.114
0.122
E1
4.750
5.050
0.187
0.199
e
SG Micro Corp
www.sg-micro.com
0.650 BSC
0.026 BSC
L
0.400
0.800
0.016
0.031
θ
0°
6°
0°
6°
TX00014.000
PACKAGE INFORMATION
PACKAGE OUTLINE DIMENSIONS
SOIC-14
D
E
5.2
E1
2.2
e
b
0.6
1.27
RECOMMENDED LAND PATTERN (Unit: mm)
L1
R1
R
A3
A A2
h
L2
θ
A1
Symbol
h
L
Dimensions
In Millimeters
MIN
MAX
Dimensions
In Inches
MIN
MAX
A
1.35
1.75
0.053
0.069
A1
0.10
0.25
0.004
0.010
A2
1.25
1.65
0.049
0.065
A3
0.55
0.75
0.022
0.030
b
0.36
0.49
0.014
0.019
D
8.53
8.73
0.336
0.344
E
5.80
6.20
0.228
0.244
E1
3.80
4.00
0.150
e
L
1.27 BSC
0.45
L1
0.80
0.018
1.04 REF
L2
0.157
0.050 BSC
0.032
0.040 REF
0.25 BSC
0.01 BSC
R
0.07
0.003
R1
0.07
0.003
h
0.30
0.50
0.012
0.020
θ
0°
8°
0°
8°
SG Micro Corp
www.sg-micro.com
TX00011.001
PACKAGE INFORMATION
PACKAGE OUTLINE DIMENSIONS
TSSOP-14
D
E
E1
5.94
1.78
e
b
0.42
0.65
RECOMMENDED LAND PATTERN (Unit: mm)
L
A
A1
θ
A2
Symbol
Dimensions
In Millimeters
MIN
MAX
Dimensions
In Inches
MIN
MAX
1.200
0.047
A
A1
c
H
0.050
0.150
0.002
0.006
A2
0.800
1.050
0.031
0.041
b
0.190
0.300
0.007
0.012
c
0.090
0.200
0.004
0.008
D
4.860
5.100
0.191
0.201
E
4.300
4.500
0.169
0.177
E1
6.250
6.550
0.246
0.258
0.700
0.02
e
L
0.650 BSC
0.500
H
θ
SG Micro Corp
www.sg-micro.com
0.026 BSC
0.25 TYP
1°
0.028
0.01 TYP
7°
1°
7°
TX00019.001
PACKAGE INFORMATION
TAPE AND REEL INFORMATION
REEL DIMENSIONS
TAPE DIMENSIONS
P2
W
P0
Q1
Q2
Q1
Q2
Q1
Q2
Q3
Q4
Q3
Q4
Q3
Q4
B0
Reel Diameter
A0
P1
K0
Reel Width (W1)
DIRECTION OF FEED
NOTE: The picture is only for reference. Please make the object as the standard.
KEY PARAMETER LIST OF TAPE AND REEL
Reel
Diameter
Reel Width
W1
(mm)
A0
(mm)
B0
(mm)
K0
(mm)
P0
(mm)
P1
(mm)
P2
(mm)
W
(mm)
Pin1
Quadrant
SOT-23-5
7″
9.5
3.20
3.20
1.40
4.0
4.0
2.0
8.0
Q3
SOT-23-6
7″
9.5
3.17
3.23
1.37
4.0
4.0
2.0
8.0
Q3
SOIC-8
13″
12.4
6.40
5.40
2.10
4.0
8.0
2.0
12.0
Q1
MSOP-8
13″
12.4
5.20
3.30
1.50
4.0
8.0
2.0
12.0
Q1
SOIC-14
13″
16.4
6.60
9.30
2.10
4.0
8.0
2.0
16.0
Q1
TSSOP-14
13″
12.4
6.95
5.60
1.20
4.0
8.0
2.0
12.0
Q1
SG Micro Corp
www.sg-micro.com
TX10000.000
DD0001
Package Type
PACKAGE INFORMATION
CARTON BOX DIMENSIONS
NOTE: The picture is only for reference. Please make the object as the standard.
KEY PARAMETER LIST OF CARTON BOX
Length
(mm)
Width
(mm)
Height
(mm)
Pizza/Carton
7″ (Option)
368
227
224
8
7″
442
410
224
18
13″
386
280
370
5
SG Micro Corp
www.sg-micro.com
DD0002
Reel Type
TX20000.000
工商网监
湘ICP备2023018690号
