SGM811-ZXKA4

SGM811 SGM812 GENERAL DESCRIPTION The SGM811/SGM812 supervisory circuits monitor the power supply voltage in microprocessor and digital systems. The SGM811/SGM812 is designed to monitor seven different voltages, these voltages have been selected for the effective monitoring of 2.5V, 3 V, 3.3 V, and 5 V supply voltage levels. They provide a reset output during power-up, power-down and brownout conditions. On power-up, an internal timer holds reset asserted for 240 ms. This holds the microprocessor in a reset state until conditions have stabilized. The RESET output remains operational with VCC as low as 1 V. The SGM811 provides an active low reset signal ( RESET ) while the SGM812 provides an active high signal (RESET) output. The SGM811/SGM812 has a manual reset input. The manual reset function is very useful, especially if the circuit in which the SGM811/SGM812 is operating enters into a state that can only be detected by the user. Allowing the user to reset a system manually can reduce the damage or danger that could otherwise be caused by an out-of-control or locked system. The devices come in a 4-pin SOT143 and 5-pin SOT23 packages. Microprocessor Supervisory with Manual Reset Input FEATURES − Superior Upgrade for MAX811/MAX812 and ADM811/ADM812 − Specified over Temperature − Low Power Consumption (17 μA Typ) − Precision Voltage Monitor: 2.5V,3 V, 3.3 V, 5 V Options − Reset Assertion Down to 1 V VCC − 160 ms Min Power-On Reset Logic Low RESET Output (SGM811) Logic High RESET Output (SGM812) − Manual Reset Input − Compact 4-Pin SOT143 and 5-Pin SOT23 Packages PIN CONFIGURATIONS（TOP VIEW） SOT143-4 GND 1 4 VCC RESET/RESET 2 3 MR APPLICATIONS Microprocessor Systems Controllers Intelligent Instruments Automotive Systems Safety Systems Portable Instruments SOT23-5 GND NC RESET/RESET 1 2 3 4 MR 5 VCC TYPICAL OPERATION CIRCUIT VCC VCC MICROPROCESSOR SYSTEM RESET 100KO GND GND SGM811 RESET MR Shengbang Microelectronics Co, Ltd Tel: 86/451/84348461 www.sg-micro.com Nov 2006 ORDERING INFORMATION ORDERING NUMBER SGM811-LXN5 SGM811-M XN5 SGM811-JXN5 SGM811-T XN5 SGM811-S XN5 SGM811-R XN5 SGM811-Z XN5 SGM811-LXKA4 SGM811-MX KA4 SGM811-JX KA4 SGM811-TX KA4 SGM811-SX KA4 SGM811-RX KA4 SGM811-Z X KA4 SGM812-LXN5 SGM812-M XN5 SGM812-JXN5 SGM812-T XN5 SGM812-S XN5 SGM812-R XN5 SGM812-Z XN5 SGM812-LX KA4 SGM812-MX KA4 SGM812-JX KA4 SGM812-TX KA4 SGM812-SX KA4 SGM812-RX KA4 SGM812-Z X KA4 RESET THRESHOLD (V) 4.63 4.38 4.00 3.08 2.93 2.63 2.32 4.63 4.38 4.00 3.08 2.93 2.63 2.32 4.63 4.38 4.00 3.08 2.93 2.63 2.32 4.63 4.38 4.00 3.08 2.93 2.63 2.32 PECKAGE TYPE SPECIFIED TEMPERATURE RANGE PACKAGE MARKING 811L 811M 811J 811T 811S 811R 811Z 811L 811M 811J 811T 811S 811R 811Z 812L 812M 812J 812T 812S 812R 812Z 812L 812M 812J 812T 812S 812R 812Z PACKAGE OPTION SOT23-5 SOT23-5 SOT23-5 SOT23-5 SOT23-5 SOT23-5 SOT23-5 SOT143-4 SOT143-4 SOT143-4 SOT143-4 SOT143-4 SOT143-4 SOT143-4 SOT23-5 SOT23-5 SOT23-5 SOT23-5 SOT23-5 SOT23-5 SOT23-5 SOT143-4 SOT143-4 SOT143-4 SOT143-4 SOT143-4 SOT143-4 SOT143-4 - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C - 40°C to +125°C Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 Tape and Reel, 3000 2 SGM811/812 ELECTRICAL CHARACTERISTICS (VCC Typ = 5 V for L/M/J Models, 3.3 V for T/S Models, 3 V for R Models, 2.5 V for Z Models; unless otherwise noted.) PARAMETER SUPPLY Voltage TA = 0°C to 70°C TA = - 40°C to +125°C VCC < 5.5 V, SGM81_L/M/J, TA = 25°C Current VCC < 5.5 V, SGM81_L/M/J, TA = - 40°C to +125°C VCC < 3.6 V, SGM81_R/S/T/Z, TA = 25°C VCC < 3.6 V, SGM81_R/S/T/Z, TA = - 40°C to +125°C RESET VOLTAGE THRESHOLD SGM81_L SGM81_M SGM81_J SGM81_T SGM81_S SGM81_R SGM81_Z RESET THRESHOLD Temperature Coefficient VCC to RESET/ RESET Delay Reset Active Timeout Period TA = - 40°C to +125°C MANUAL RESET 100 840 ms TA = 25°C TA = - 40°C to +125°C TA = 25°C TA = - 40°C to +125°C TA = 25°C TA = - 40°C to +125°C TA = 25°C TA = - 40°C to +125°C TA = 25°C TA = - 40°C to +125°C TA = 25°C TA = - 40°C to +125°C TA = 25°C TA = - 40°C to +125°C 4.537 4.40 4.292 4.16 3.92 3.8 3.003 2.92 2.857 2.78 2.564 2.50 2.262 2.22 CONDITIONS MIN 1.0 1.2 TYP MAX 5.5 5.5 UNITS V V µA µA µA µA V V V V V V V V V V V V V V ppm/°C µs 20 17 30 50 25 45 4.63 4.38 4.00 3.08 2.93 2.63 2. 23 4.723 4.86 4.468 4.56 4.08 4.2 3.157 3.23 3.003 3.08 2.696 2.76 2.378 2.42 30 VCC = VTH to (VTH –100 mV) TA = - 40°C to +85°C 160 20 240 560 ms Minimum Pulsewidth Glitch Immunity RESET/ RESET Propagation Delay Pull-Up Resistance The Manual Reset Circuit Will Act On: An Input Rising Above An Input Falling Below An Input Rising Above An Input Falling Below VCC > VTH(MAX), SGM81_L/M/J VCC > VTH(MAX), SGM81_L/M/J VCC > VTH(MAX), SGM81_R/S/T/Z VCC > VTH(MAX), SGM81_R/S/T/Z 10 µs 100 0.5 1 2.3 0.8 0.7×VCC 0.25×VCC ns µs MΩ V V V V 3 SGM811/812 ELECTRICAL CHARACTERISTICS (continued) (VCC Typ = 5 V for L/M/J Models, 3.3 V for T/S Models, 3 V for R Models, 2.5 V for Z Models; unless otherwise noted.) PARAMETER RESET/ RESET OUTPUT VOLTAGE Low (SGM811R/S/T/Z) Low (SGM811L/M/J) Low (SGM811R/S/T/Z/L/M/J) High (SGM811R/S/T/Z) High (SGM811L/M/J) Low (SGM812R/S/T/Z) Low (SGM812L/M/J) High (SGM812 R/S/T/Z/L/M/J) VCC = VTH(MIN), ISINK = 1.2mA VCC = VTH(MIN), ISINK = 3.2mA VCC > 1.0 V, ISINK = 50µA VCC > VTH(MAX), ISOURCE = 500µA VCC > VTH(MAX), ISOURCE = 800µA VCC = VTH(MAX), ISINK = 1.2mA VCC = VTH(MAX), ISINK = 3.2mA 1.8 V < VCC < VTH(MIN), ISOURCE = 150µA 0.8×VCC 0.8×VCC VCC– 1.5 0.3 0.4 0.3 0.4 0.3 V V V V V V V V CONDITIONS MIN TYP MAX UNITS Specifications subject to change without notice. ABSOLUTE MAXIMUM RATINGS (Typical values are at TA = 25°C, unless otherwise noted.) Terminal Voltage (With Respect to Ground) VCC................................................................................–0.3 V to +6 V All Other Inputs ............................................ –0.3 V to VCC + 0.3 V Input Current VCC , MR ................................................................................ 20 mA Output Current RESET, RESET ..................................................................... 20 mA Power Dissipation, PD @ TA = 25℃ SOT23-5 .....................................................................................0.4W SOT143-4.................................................................................. 0.32W Operating Temperature Range...........................- 40°C to +125°C Junction Temperature...........................................................+150°C Storage Temperature.............................................- 65°C to +150°C Lead Temperature (soldering, 10s).....................................+260°C ESD Susceptibility HBM..........................................................................................4000V MM..............................................................................................400V Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. PIN DESCRIPTION Pin Number NAME SGM811 SOT143-4 SOT23-5 GND 1 1 2 2 3 — SGM812 SOT143-4 1 Ground No connect. Active Low Logic Output. RESET remains low while VCC is below the reset threshold or when MR is low; RESET then remains low for at least 160 ms after VCC rises above the reset threshold. Active High Logic Output. RESET remains high while VCC is below the reset threshold or when MR is low; RESET then remains high for 240 ms (typical) after VCC rises above the reset threshold. Manual Reset. This active low debounced input will ignore input pulses of 100 ns or less (typical) and is guaranteed to accept input pulses of greater than 10 µs. Leave floating when not used. Power supply voltage that is monitored. 4 FUNCTION NC RESET RESET — — 2 MR VCC 3 4 4 5 3 4 SGM811/812 TYPICAL PERFORMANCE CHARACTERISTICS Power-Down RESET Delay vs.Temperature 250 SGM811L/M/J VOD = VTH - VCC VOD = 10mV 150 100 50 0 -50 -30 -10 10 30 50 70 90 110 130 VOD = 100mV VOD = 200mV VOD = 20mV Power-Down RESET Delay vs.Temperature 300 SGM811T/S/R VOD = VTH - VCC VOD = 10mV Power-Down RESET (µS) 200 Power-Down RESET (µS) 250 200 150 100 50 0 -50 -30 -10 VOD = 20mV VOD = 100mV VOD = 200mV 10 30 50 70 90 110 130 Temperature(℃) Temperature(℃) Power-Up RESET Delay vs.Temperature 264 262 260 258 256 254 252 250 248 -50 -30 -10 10 30 50 70 90 110 130 SGM811S Supply Current vs. Temperature (No Load) 30 25 VCC = 5.5V Power-Down RESET (mS) Supply Current (µA) 20 15 10 5 0 -50 -30 -10 10 30 50 70 VCC = 3.6V 90 110 130 Temperature(℃) Temperature(℃) Normalized RESET Voltage Threshold vs. Temperature Normalized RESET Threshold 1.006 1.004 1.002 1 0.998 0.996 0.994 0.992 0.99 0.988 -50 -30 -10 10 30 50 70 90 110 130 Maximum Transient Duration Without Causing a Reset Pulse vs. RESET Comparator Overdrive Maximum Transient Duration (µS) 400 350 300 250 200 150 100 50 0 1 10 100 1000 SGM811T/S/R SGM811L/M/J 1.008 Temperature(℃) ５ RESET Comparator Overdrive, VTH - VCC(mV) SGM811/812 TYPICAL PERFORMANCE CHARACTERISTICS RESET Output Voltage vs. Supply Voltage Supply Voltage 5VP-P 2V/div RESET Output Voltage SGM811R SGM811S 200ms/div ６ SGM811/812 APPLICATION NOTES MANUAL RESET The SGM811/SGM812 is equipped with a manual reset input This input is designed to operate in a noisy environment where unwanted glitches could be induced. These glitches could be produced by the bouncing action of a switch contact, or where a manual reset switch may be located some distance away from the circuit (the cabling of which may pick-up noise). The manual reset input is guaranteed to ignore logically valid inputs that are faster than 100 ns and to accept inputs longer in duration than 10 µs. BENEFITS OF A VERY ACCURATE RESET THRESHOLD Because the SGM811/SGM812 can operate effectively even when there are large degradations of the supply voltages, the possibility of a malfunction during a power failure is greatly reduced. Another advantage of the SGM811/SGM812 is its very accurate internal voltage reference circuit. Combined, these benefits produce an exceptionally reliable microprocessor supervisory circuit. VCC RESET OUTPUT On power-up and after VCC rises above the reset threshold, an internal timer holds the reset output active for 240 ms (typical). This is intended as a power-on reset signal for the processor. It allows time for both the power supply and the microprocessor to stabilize after power-up. If a power supply brownout or interruption occurs, the reset output is similarly activated and remains active for 240 ms (typical) after the supply recovers. This allows time for the power supply and microprocessor to stabilize. The SGM811 provides an active low reset output ( RESET ) while the SGM812 provides an active high output ( RESET ). During power-down of the SGM811, the RESET output remains valid (low) with VCC as low as 1 V. This ensures that the microprocessor is held in a stable shutdown condition as the supply falls and also ensures that no spurious activity can occur via the microprocessor as it powers up. Glitch Immunity The SGM811/SGM812 contains internal filtering circuitry providing glitch immunity from fast transient glitches on the power supply line. VREF VCC SGM811 RESET VCC VREF VREF VREF RESET GND t1 t1 t1= RESET Time = 240ms Typical VREF = RESET Voltage Threshold Figure 1. Ensuring a Valid RESET Output Down to VCC = 0V ENSURING A VALID RESET OUTPUT DOWN TO VCC = 0 V When VCC falls below1.0 V, the SGM811/SGM812’s RESET no longer sinks current. Therefore, a high impedance CMOS logic input connected to RESET may drift to undetermined logic levels. To eliminate this problem, a 100 k Ω resistor should be connected from RESET to ground. Figure 2. Power Fail RESET Timing INTERFACING TO OTHER DEVICES Output The SGM811/SGM812 is designed to integrate with as many devices as possible. One feature of the SGM811/SGM812 is the reset output, which is directly proportional to VCC (this is guaranteed only while VCC is greater than 1 V). This enables the part to be used with both 3 V and 5 V, or any nominal voltage within the minimum and maximum specifications for VCC. ７ SGM811/812 PACKAGE OUTLINE DIMENSIONS SOT23-5 D b L 0 θ 0.20 Symbol A A1 Dimensions In Millimeters Min 1.050 0.000 1.050 0.300 0.100 2.820 1.500 2.650 1.800 0.300 0° Dimensions In Inches Min 0.041 0.000 0.041 0.012 0.004 0.111 0.059 0.104 0.071 0.012 0° Max 1.250 0.100 1.150 0.400 0.200 3.020 1.700 2.950 2.000 0.600 8° Max 0.049 0.004 0.045 0.016 0.008 0.119 0.067 0.116 0.079 0.024 8° E1 A2 b c E L e e1 A1 D C E E1 e e1 0.950TYP 0.700REF 0.037TYP 0.028REF A2 L L1 θ A ８ SGM811/812 PACKAGE OUTLINE DIMENSIONS SOT143- 4 D e1 S C L Symbol A A1 B B1 C D E Dimensions In Millimeters Min 0.890 0.013 0.760 0.370 0.085 2.800 1.200 Max 1.120 0.100 0.940 0.510 0.180 3.040 1.400 H e2 B B1 E e1 e2 H L S 1.920 BSC 0.200 BSC 2.100 0.450 2.640 0.600 0.55 REF A1 A ９ SGM811/812
