MV-MD

厂商：
SHIELD
封装：
描述：
MV-MD - Indramat® brushless motor cables PUR - SHIELD s.r.l.

数据手册：

下载MV-MD.pdf

立即购买

详情介绍
数据手册
价格&库存

MV-MD 数据手册

CABLES - CAVI MV-MD Indramat® brushless motor cables PUR Description. Conductor insulation of halogen free TPE-E, separation soft tape, tinned copper braid, min. coverage 85%, on each signal pair and on the total, EMC 89/336/EC. Sheath of matt halogen free polyether polyurethane (PUR). Application. Designed for brushless motors for heavy duty applications. Completely halogen free cable, it does not emit halogens in case of ﬁre. Flame resistance degree: UL94 horizontal ﬂame test, IEC 60332-1. Very good resistance to common chemical agents and oils (UL 1581). Abrasion resistance and excellent mobile laying behaviour (10 m/s2, 220 m/min). Max working voltage: 1000 V. Test voltage: 4000 V. Note to table: (a) example: 2 = two wires; 3+1 = three wires + yellow/green earth; s = shielding. (b) colours: N = black with white numbers; yellow/green earth if present. (c) norms: UL = UL recognized (United States) / CSA = CSA recognized (Canada). Cavi per motori brushless Indramat® PUR Descrizione. Isolante conduttori in TPE-E senza alogeni, nastro morbido di separazione, schermo a treccia in rame stagnato, copertura minima 85%, su ciascuna coppia di segnali e sul totale, EMC 89/336/CE. Guaina in poliuretano (PUR) polietere opaco senza alogeni. Impiego. Progettato per motori brushless per applicazioni particolarmente gravose. Interamente senza alogeni, non emette sostanze corrosive in caso di incendio. Grado di resistenza alla ﬁamma: UL94 test ﬁamma orizzontale, IEC 60332-1. Ottima resistenza agli agenti chimici e agli idrocarburi comuni (UL1581). Ottimo comportamento in posa mobile (10 m/s2, 220 m/min) e resistenza all’abrasione. Tensione massima di lavoro: 1000 V. Tensione di prova: 4000 V. Note alla tabella: (a) esempio: 2 = due conduttori; 3+1 = tre conduttori + terra giallo/verde; s = schermo. (b) colori: N = nero con numeri bianchi; terra giallo/verde se presente. (c) norme: UL = certiﬁcato UL (Stati Uniti) / CSA = certiﬁcato CSA (Canada). Formation Formazione Descriptive code Codice descrittivo Short code Codice breve Refer. or style Rifer. o style Sheath colour Colore guaina Wires colour Colore cond. (b) Copper class Classe rame IEC 60228 Static application Applicazione statica °C Dynamic application Applicazione dinamica °C Note Nota n x mm2 (a) (c) RAL MV-MD2 [(3+1)x0,75 + (2x0,50)s]s MV-MD25-06JN5 [(3+1)x1,00 + 2x(2x0,75)s]s MV-MD26-08HN5 [(3+1)x1,50 + 2x(2x0,75)s]s MV-MD27-08HN5 [(3+1)x2,50 + 2x(2x1,00)s]s MV-MD2A-08HN5 [(3+1)x4 + (2x1,00)s + (2x1,50)s]s MV-MD2C-08JN5 [(3+1)x6 + (2x1,00)s + (2x1,50)s]s MV-MD2D-08JN5 [(3+1)x10 + (2x1,00)s + (2x1,50)s]s MV-MD2E-08JN5 [(3+1)x16 + 2x(2x1,50)s]s MV-MD2F-08HN5 [(3+1)x25 + 2x(2x1,50)s]s MV-MD2H-08HN5 [(3+1)x35 + 2x(2x1,50)s]s MV-MD2J-08HN5 [(3+1)x50 + 2x(2x2,50)s]s MV-MD2K-08HN5 626 733 A33 C33 D33 E33 F33 H33 J33 K33 1000V 80°C UL-CSA 1000V 80°C UL-CSA 1000V 80°C UL-CSA 1000V 80°C UL-CSA 1000V 80°C UL-CSA 1000V 80°C UL-CSA 1000V 80°C UL-CSA 1000V 80°C UL-CSA 1000V 80°C UL-CSA 1000V 80°C UL-CSA 1000V 80°C UL-CSA og 2003 og 2003 og 2003 og 2003 og 2003 og 2003 og 2003 og 2003 og 2003 og 2003 og 2003 N N N N N N N N N N N 6 6 6 6 6 6 6 6 6 6 6 -40...+ 80 -40...+ 80 -40...+ 80 -40...+ 80 -40...+ 80 -40...+ 80 -40...+ 80 -40...+ 80 -40...+ 80 -40...+ 80 -40...+ 80 -30...+ 80 -30...+ 80 -30...+ 80 -30...+ 80 -30...+ 80 -30...+ 80 -30...+ 80 -30...+ 80 -30...+ 80 -30...+ 80 -30...+ 80 INK-0670 Indramat INK-0653 Indramat INK-0650 Indramat INK-0602 Indramat INK-0603 Indramat INK-0604 Indramat INK-0605 Indramat INK-0606 Indramat INK-0607 Indramat INK-0667 Indramat INK-0668 Indramat Mentioned Companies’ registered trade marks are reported only for information purposes. I marchi registrati delle aziende citate sono riportati solo a scopo informativo. 33 MV-M www.shield.net

下载 PDF

MV-MD

1. 物料型号： - MV-MD2、MV-MD25-06JN5、MV-MD26-08HN5、MV-MD27-08HN5、MV-MD2A-08HN5、MV-MD2C-08JN5、MV-MD2D-08JN5、MV-MD2E-08JN5、MV-MD2F-08HN5、MV-MD2H-08HN5、MV-MD2J-08HN5、MV-MD2K-08HN5

2. 器件简介： - 该文档描述的是Indramat®无刷电机电缆。这种电缆采用无卤TPE-E绝缘，软带分隔，镀锡铜编织层，至少85%的覆盖率，符合EMC 89/336/EC标准。外护套为无卤聚醚聚氨酯(PUR)，设计用于重型无刷电机应用。该电缆完全无卤，火灾时不释放卤素。阻燃等级：UL94水平火焰测试，IEC 60332-1。对常见化学品和油有良好抵抗力（UL 1581）。耐磨性和优秀的移动铺设行为（10 m/s²，220 m/min）。最大工作电压：1000V。测试电压：4000V。

3. 引脚分配： - 例如：(3+1)x0.75+(2x0.50)s 表示3根0.75平方毫米的导线加上2根0.50平方毫米屏蔽导线，s表示屏蔽。

4. 参数特性： - 工作电压：1000V，测试电压：4000V。 - 温度范围：静态-40°C至+80°C，动态-30°C至+80°C。 - 导体绝缘材料：无卤TPE-E，屏蔽：镀锡铜编织，至少85%覆盖率。 - 外护套：无卤聚醚聚氨酯(PUR)。

5. 功能详解和应用信息： - 适用于特别重型的无刷电机应用，完全无卤，火灾时不释放腐蚀性物质。具有很好的抗化学品和油的抵抗力，优秀的耐磨性和移动铺设行为。

6. 封装信息： - 外护套颜色：RAL色卡中的og 2003色号。 - 导体：铜导体，符合IEC60228标准中的6类铜。 - 符合的认证和标准：UL（美国）和CSA（加拿大）认证。
