SI7202-B-04-IBR

Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet The Si7201/2/3/4/5/6 family of Hall effect magnetic sensors switches and latches from Silicon Labs combines a chopper-stabilized Hall element with a low-noise analog amplifier, 13-bit analogto-digital converter, and a flexible comparator circuit. Leveraging Silicon Labs' proven CMOS design techniques, the Si720x family incorporates digital signal processing to provide precise compensation for temperature and offset drift. FEATURES • High-Sensitivity Hall Effect Sensor • Maximum BOP operating point/minimum field strength of 2 V TAMPERb pin IOL = 2 mA VDD > 1.71 V TAMPERb pin IOL = 6 mA VDD > 2 V Output Voltage High VOH TAMPERb pin VDD – 0.4 V IOH = 2 mA VDD > 2.25 V silabs.com | Building a more connected world. Rev. 1.4 | 3 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Electrical Specifications Parameter Current Consumption Symbol IDD Average power depends on the sample rate and percent of time spent sampling versus sleep mode or idle mode. See the ordering guide for average power calculations for specific devices. Test Condition Sleep timer enabled average at VDD = 3.3 V and 200 msec sleep time Min Typ Max Unit 0.4 μA 50 nA Sleep mode VDD = 3.3 V, T = 25 °C VDD = 3.3 V, T = 70 °C 1000 VDD = 5.5 V, T = 125 °C 5000 nA nA Conversion in progress mA VDD = 1.8V 3.5 5.5 VDD = 3.3 V 5 6 6.8 8.0 6.5 8.5 mA 0.6 1 mA 0.9 1.2 mA VDD = 5.5 V Conversion in progress high voltage parts VDD = 3.3 to 26.5 V Idle mode low voltage parts VDD = 1.71 to 5.5 V Idle mode high voltage parts VDD = 3.3 to 26.5 V Conversion Time Sample Rate Wake Up Time TCONV FSAMPLE TWAKE First conversion when waking from sleep or idle 11 µs Additional conversions in a burst 8.8 µs Parts can be configured for sleep or idle between samples. Sleep is lower power, but the fastest sampling rate is 8 kHz. Idle allows sampling rate to be configured to be as high as 113 kHz. See the ordering guide for details. Time from VDD > 1.71 V to first measurement - 1 msec Note: 1. TAMPERb and DIS pin specifications apply when the pin is present (Si7203/4). 2. Idle time can be factory programmed from 13.2 μsec to 206 msec ±10% or set to zero in which case conversions are done every 8.8 μsec. Normally idle time is only used at higher sample speeds. 3. For high voltage parts (VDD = 26.5 V maximum), the power on ramp should be faster than 10 V per second in the start-up region from 2 to 3 V. silabs.com | Building a more connected world. Rev. 1.4 | 4 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Electrical Specifications Table 1.3. Output Pin Specifications Parameter Symbol Test Condition Min Typ Max Unit 0.4 V 0.2 V 0.6 V 1 µA Si7201/2/3/4 Output Voltage Low VOL Open Drain or Push Pull IOL = 3 mA VDD > 2 V IOL = 2 mA VDD > 1.71V IOL = 6 mA VDD > 2 V Leakage IOH Output High Output Pin Open Drain Output Voltage High VOH Output Pin Push Pull Slew Rate IOH = 2 mA VDD – 0.4 V VDD > 2.25 V TSLEW 5 %VDD/ns Si7205/6 Output Voltage Low VOL IOL = 11.4 mA 0.4 V 20 mA 1 µA VDD > 6 V Safe Continuous Sink Current Leakage IOH Output High Output Pin Open Drain Slew Rate TSLEW 5 %VDD/ns 4 mA Digital Output Mode Output Pin Shorted to VDD ISHORT VDD = 12 V Average current as pin cycles silabs.com | Building a more connected world. Rev. 1.4 | 5 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Electrical Specifications The Si7205 and Si7206 can be configured to signal the status equivalent to output high or low by modulating the power supply current. If configured in this way, the following are the specifications for the amount of current that will be drawn for the “output high” state. Table 1.4. IDD Signaling Parameter IDD Signaling Current Symbol IDO Test Condition Min Typ Max Unit 8 10 12 mA Min Typ Max Unit ±150 ±250 µT ±250 +450, -350 µT 0-70°C 5 % Full temperature range 10 % VDDH > 6 V Table 1.5. Magnetic Sensor1 Parameter Offset Symbol BOFF Test Condition 20 mT scale VDD = 1.71 to 3.6 V 0-70°C 20 mT scale VDD = 1.71 to 5.5 V Full temperature range Gain Accuracy Room temp, 20 mT range, VDD = 5 V RMS Noise2 30 µT rms Note: 1. See the Magnetic Sensors Selector Guide for operating release points. These are defined as maximum operating point and minimum release point over the operating temperature range and do not include the effect of noise. 2. For a single conversion. This can be reduced by the square root of N by filtering over N samples. See ordering guide for samples taken per measurement. Table 1.6. Temperature Compensation Parameter Symbol Bop and Brp vs Temperature Test Condition Flat Tempco. Min Typ Max Unit < ±0.05 %/°C Neodymium compensation -0.12 %/°C Ceramic compensation -0.2 %/°C 0-70°C silabs.com | Building a more connected world. Rev. 1.4 | 6 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Electrical Specifications Table 1.7. Thermal Characteristics Parameter Symbol Test Condition Value Unit Junction to Air Thermal Resistance θJA JEDEC 4 layer board no airflow SOT23-5 212.8 °C/W Junction to Board Thermal Resistance θJB JEDEC 4 layer board no airflow SOT23-5 45 °C/W Junction to Air Thermal Resistance θJA JEDEC 4 layer board no airflow SOT23-3 254.6 °C/W Junction to Board Thermal Resistance θJB JEDEC 4 layer board no airflow SOT23-3 54.8 °C/W Table 1.8. Absolute Maximum Ratings1 Parameter Symbol Test Condition Min Typ Max Unit Ambient Temperature Under Bias -55 125 °C Storage Temperature -65 150 °C Voltage on I/O Pins -0.3 VDD+0.3 V Voltage on VDD with Respect to Ground -0.3 6 V HBM 2 kV CDM 500 V Si7201/2/3/4 ESD Tolerance Si7205/6 Voltage on Ouput pin2 -21 40 V Voltage on VDD with Respect to Ground3 -21 40 V HBM 8 kV CDM 500 V ESD Tolerance Notes: 1. Absolute maximum ratings are stress ratings only, operation at or beyond these conditions is not implied and may shorten the life of the device or alter its performance. 2. The output pin can withstand EMC transients per ISO 7637-2-2-11 and Ford EMC-CS-2009.1 with a current limiting resistor of 220 Ω to a local bypass cap of 0.1 μF and additional 22 Ω between the capacitor and ground.. 3. VDD can withstand automotive EMC transients per ISO 7637-2-2-11 and Ford EMC-CS-2009.1 with a current limiting resistor of 220 Ω. silabs.com | Building a more connected world. Rev. 1.4 | 7 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Functional Description 2. Functional Description The Si7201/2/3/4/5/6 family of Hall Effect magnetic sensors digitize the component of the magnetic field in the z axis of the device (positive field is defined as pointing into the device from the bottom). The digitized field is compared to a pre-programmed threshold and the output pin goes high or low if the threshold is crossed. The parts are normally used to detect the presence or absence of a magnet in security systems, as position sensors or for counting revolutions. Table 2.1. Part Ordering Guide Part Number Description Si7201 Low voltage switches Si7202 Low voltage latches Si7203 Low voltage switch with tamper and/or disable pins Si7204 Low voltage latches with tamper and/or disable pins Si7205 High voltage switches Si7206 High voltage latches The output pin (push pull or open collector) can go high or low when the magnetic field crosses a threshold. The output pin configuration is determined by the type of part ordered. The parts are preconfigured for the magnetic field measurement range, magnetic field operate and release points, sleep time, temperature compensation, tamper threshold and digital filtering and will wake into this mode when first powered. The specific configuration output type (open collector or push pull) are determined by the part number. See Magnetic Sensors Selector Guide for details. Examples: VOUT VOH VOL Brp Bop BTAMPER Figure 2.1. Unipolar Switch with Tamper silabs.com | Building a more connected world. Rev. 1.4 | 8 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Functional Description VOUT VOH VOL B BTAMPER Bop Brp Brp Bop BTAMPER Figure 2.2. Omnipolar Swith with Tamper VOUT VOH VOL B Brp Bop Figure 2.3. Latch silabs.com | Building a more connected world. Rev. 1.4 | 9 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet DISABLE Pin Timing 3. DISABLE Pin Timing For a part that has a DISABLE pin, DISABLE high will put the part in complete sleep mode with IDD typical of 50 nA. When DISABLE goes low, the part will wake and initiate a measurement. For a single measurement, this takes 11 μsec typically. Additional measurements in a burst take 8.8 μsec. Once the measurement (burst) is complete, the output pin status is updated and the part enters idle mode. The part will make a new measurement or measurement burst at the time-interval determined by the idle timer (typically 1 msec). The idle timer is reset when DISABLE transitions from high to low, so the time from the first measurement until the next measurement will always be the programmed idle time. Disable low pulses can be as short as 1 μsec. For pulses shorter than a conversion burst, the part will make one burst and then go back to sleep. When disable returns high, a measurement in progress (if any) will complete and the part will enter sleep mode. As the idle time is typically long (i.e. 1 msec) compared to the measurement time (i.e. 11 μsec), it is possible to keep the DISABLE pin low duration short (i.e. 15 μsec) and have a long period in the sleep state. This is an effective way to control the sample rate and power. For example, if the part is programmed to make a single measurement at a time and is programmed with an idle time of 1 msec and DISABLE is pulsed low for 15 μsec every 50 msec, then the average IDD will be: • 11 μsec to wake and make a measurement at IDD typical of 5.0 mA (3.3V)/(50.015 msec cycle time) = 1.0 μA • 4 μsec in idle mode at typical current of 600 μA/(50.015 msec cycle time) = 0.05 μA • 50 msec in sleep mode at 50 nA/(50.015 msec cycle time) = 0.05uA • Or 1.1 μA total As the programmed idle time is shorter than the DISABLE low time in the example, the value of the programmed idle time does not make a difference. silabs.com | Building a more connected world. Rev. 1.4 | 10 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Pin Description 4. Pin Description 1 1 3 5 2 2 3 4 1 SOT-23, 3-Pin Top View SOT-23, 5-Pin Top View 2 3 TO-92, 3-Pin Front View Figure 4.1. Si720xxx Pin Assignments Note: The 3-pin option includes part numbers: Si7201/2/5/6. The SOT-23 5 pin option include part numbers: Si7203/4. Table 4.1. Si7201/2/5/6 (SOT23 3-pin Package) Pin Name Pin Number Description VDD 1 Power 1.71 to 5.5 V or 3.3 to 26.5 V OUT1 2 Switch/latch output GND 3 Ground Table 4.2. Si7203/4/5 (SOT23 5-pin Package Excluding Si7203-B-01-IV(R)) Pin Name Pin Number Description OUT2/TAMPERb 1 OUT2/TAMPERb (tamper/high field indicator) GND 2 Ground DIS 3 Disables part (puts into sleep mode) when high. Measurement cycle will resume when pin goes low VDD 4 Power 1.71 to 5.5 V OUT1 5 Switch/latch output silabs.com | Building a more connected world. Rev. 1.4 | 11 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Pin Description Table 4.3. Si7203-B-01-IV(R) (SOT23 5-pin Package) Pin Name Pin Number Description TAMPER 1 TAMPER (tamper) GND 2 Ground FLOAT 3 Must be left floating for correct operation of the device VDD 4 Power 1.71 to 5.5 V OUT1 5 Switch output Table 4.4. Si7201/2/5/6 (TO-92 Package) Pin Name Pin Number Description VDD 1 Power GND 2 Ground OUT1 3 Output silabs.com | Building a more connected world. Rev. 1.4 | 12 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Ordering Guide 5. Ordering Guide Si72 0 1 B xx F V R Silicon Labs Magnetic Sensor Family Output Type Feature Set Major 1, 3, 5 = Switch 2, 4, 6 = Latch Revision Feature Set Minor See Selector Guide for breakdown of feature set Temperature Grade F = (0 to +70) I = (-40 to +125) Package V = SOT23, B = TO92, M = DFN8 Tape and Reel (Optional) Figure 5.1. Si720x Part Numbering silabs.com | Building a more connected world. Rev. 1.4 | 13 Bop max (mT) 1.1 1.1 0.9 2.8 1.4 2.0 2.0 2.0 3.4 OPN Si7201B-00-FV Si7201B-01-FV silabs.com | Building a more connected world. Si7201B-02-FV Si7201B-03-IV Si7201B-04-IV Si7201B-05-IV Si7201B-06-IV Si7201B-07-IV Si7201B-08-IV 1.6 0.6 0.6 0.6 0.2 1.1 0.2 0.2 0.2 Brp min (mT) 2.7 1.6 1.6 1.6 1.0 2.2 0.6 0.8 0.8 Bop Typ (mT) 2.1 1.0 1.0 1.0 0.6 1.6 0.4 0.4 0.4 Brp Typ (mT) 0.6 0.6 0.6 0.6 0.4 0.6 0.2 0.4 0.4 Hyst (mT) Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Type Low (OpenDrain) Low (Open Drain) Low (Open Drain) Low (PushPull) Low (PushPull) High (PushPull) High (PushPull) Low (PushPull) Low (PushPull) Output type 20 20 20 20 20 20 20 20 20 Full Scale (mT) 1000 5 5 5 5 1000 5 5 5 56.7 0.4 0.4 0.4 0.4 56.7 1.1 0.4 0.4 Sample Typical freIdd (uA) quency (Hz) Table 5.1. Switch Product Selection Guide 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-3.6 1.7-3.6 1.7-3.6 Vdd Range (V) -40 125° -40 125° -40 125° -40 125° -40 125° -40 125° 0 - 70° 0 - 70° 0 - 70° Temperature (°C) SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 Package — 19.8 — 19.8 — — 19.8 19.8 — Tamper detection (mT) — — — — — — 0.12% — — — — — — — — 4 sample FIR — — TemDigital pera- filtering ture compensation (% per °C) Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Ordering Guide Rev. 1.4 | 14 Bop max (mT) 2.3 3.7 2.8 3.7 4.9 4.9 4.9 7.0 7.0 7.0 OPN Si7201B-09-IB SI7201B-10-IV Si7201B-11-IB silabs.com | Building a more connected world. SI7201B-12-IV SI7201B-20-IV SI7201B-21-IV SI7201B-22-IV SI7201B-30-IV SI7201B-31-IV SI7201B-32-IV 4.1 4.1 4.1 2.3 2.3 2.3 1.5 1.1 1.5 0.8 Brp min (mT) 6.0 6.0 6.0 4.0 4.0 4.0 3.0 2.2 3.0 1.6 Bop Typ (mT) 5.0 5.0 5.0 3.0 3.0 3.0 2.0 1.6 2.0 1.2 Brp Typ (mT) 1.0 1.0 1.0 1.0 1.0 1.0 1.0 0.6 1.0 0.4 Hyst (mT) Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Type Low (Open Drain) Low (Open Drain) Low (Open Drain) Low (Open Drain) Low (Open Drain) Low (Open Drain) Low (Open Drain) High (pushpull) Low (Open Drain) Low (pushpull) Output type 20 20 20 20 20 20 20 20 20 20 Full Scale (mT) 20 13.3 5 20 13.3 5 20 8000 5 20 1.2 0.9 0.4 1.2 0.9 0.4 1.2 420.7 0.4 1.2 Sample Typical freIdd (uA) quency (Hz) 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 Vdd Range (V) -40 125° -40 125° -40 125° -40 125° -40 125° -40 125° -40 125° -40 125° -40 125° -40 125° Temperature (°C) SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 TO92 SOT233 TO92 Package — — — — — — — — — — Tamper detection (mT) — — — — — — — — — — — — — — — — — — — — TemDigital pera- filtering ture compensation (% per °C) Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Ordering Guide Rev. 1.4 | 15 Bop max (mT) 15.0 15.0 3.4 3.4 3.4 3.7 3.7 3.7 3.7 3.7 OPN SI7201B-40-IV SI7201B-41-IV Si7201B-80-FV silabs.com | Building a more connected world. Si7201B-81-FV Si7201B-82-FV Si7201B-83-IV Si7201B-84-IV Si7201B-85-IV Si7201B-86-IV Si7201B-87-IV 1.4 1.4 1.4 1.4 1.4 1.7 1.7 1.7 9.6 9.6 Brp min (mT) 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 13.2 13.2 Bop Typ (mT) 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 11.2 11.2 Brp Typ (mT) 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 2.0 2.0 Hyst (mT) Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Omnipolar switch Type Low (Opendrain) Low (Opendrain) Low (PushPull) Low (PushPull) High (PushPull) High (PushPull) Low (PushPull) Low (PushPull) Low (Open Drain) Low (Open Drain) Output type 20 20 20 20 20 20 20 20 20 20 Full Scale (mT) 5 5 5 5 1000 5 5 5 13.3 5 0.4 0.4 0.4 0.4 56.7 1.1 0.4 0.4 0.9 0.4 Sample Typical freIdd (uA) quency (Hz) 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-5.5 1.7-3.6 1.7-3.6 1.7-3.6 1.7-5.5 1.7-5.5 Vdd Range (V) -40 125° -40 125° -40 125° -40 125° -40 125° 0 - 70° 0 - 70° 0 - 70° -40 125° -40 125° Temperature (°C) SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 SOT233 Package 19.84 — 19.84 — — 19.84 19.84 — — — Tamper detection (mT) — — — — — 0.12% — — — — — — — — — 4 sample FIR — — — — TemDigital pera- filtering ture compensation (% per °C) Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Ordering Guide Rev. 1.4 | 16 silabs.com | Building a more connected world. 1.1 3.0 Si7203B-00-FV Si7205B-00-IV* *Note: End of life. Bop max (mT) OPN 0.8 0.2 Brp min (mT) 2.2 0.8 Bop Typ (mT) 1.6 0.4 Brp Typ (mT) 0.6 0.4 Hyst (mT) Omnipolar switch Omnipolar switch Type Low (Open Drain) High (Open Drain) Output type 20 20 Full Scale (mT) 1000 1000 950 412 Sample Typical freIdd (uA) quency (Hz) 3.3-26.5 1.7-3.6 Vdd Range (V) -40 125° 0 - 70° Temperature (°C) SOT233 SOT235 Package — 19.8 Tamper detection (mT) — — — — TemDigital pera- filtering ture compensation (% per °C) Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Ordering Guide Rev. 1.4 | 17 silabs.com | Building a more connected world. -1.0 -1.0 -5.1 -1.0 Si7202B-00-FV Si7202B-01-IB Si7202B-01-IV Si7202B-02-IV Si7202B-04-IB *Note: End of life. -1.0 -0.4 OPN Si7206B-00-IV* Brp Typ [mT] 1.0 1.0 5.1 1.0 1.0 0.4 Bop Typ [mT] -1.5 -1.5 -6.1 -1.5 -1.5 -0.7 Brp min [mT] -0.5 -0.5 -4.3 -0.5 -0.5 -0.1 Brp max [mT] 0.5 0.5 4.3 0.5 0.5 0.1 Bop min [mT] 1.5 1.5 6.1 1.5 1.5 0.7 Bop max [mT] 1.9 1.9 10.2 1.9 1.9 0.8 Hyst (mT) Latch Latch Latch Latch Latch Latch Type Open Drain Push Pull Push Pull Push Pull Push Pull Push Pull Output Type Low Low High Low Low High Output (+ field) Table 5.2. 3-pin Latch Product Selection Guide 1000 5 5 5 5 5 Samples Freq (Hz) 950 0.4 0.4 0.4 0.4 0.4 Idd Typ 3.3 1.7 1.7 1.7 1.7 1.7 Vdd min 26.5 5.5 5.5 5.5 5.5 3.6 Vdd max -40 125° -40 125° -40 125° -40 125° -40 125° 0 - 70° Temp Range SOT233 TO92 SOT233 SOT233 TO92 SOT233 Package Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Ordering Guide Rev. 1.4 | 18 Brp Typ [mT] -0.9 OPN Si7204 - B-00FV 0.9 Bop Typ [mT] -1.2 Brp min [mT] -0.6 Brp max [mT] 0.6 Bop min [mT] 1.2 Bop max [mT] 1.8 Hyst (mT) No Connect Pin 1 Disable Pin 3 Idle Idle/ Sleep Mode Latch Type High Output (+ field) Table 5.3. 5-pin Latch Product Selection Guide 1000 Samples Freq (Hz) - Idd Typ 1.7 Vdd min 3.6 Vdd max 0 - 70° Temp Range SOT23 -5 Package Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Ordering Guide silabs.com | Building a more connected world. Rev. 1.4 | 19 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Ordering Guide Additional Information For information on the below specifications of each OPN please refer to the Magnetic Sensors Selector Guide: • • • • Current Consumption Amount of digital filtering applied to the samples Time between measurements Temperature compensation A temperature compensation can be applied to the field data to adjust for the variation in field with temperature for common magnet types. Note: North pole of a magnet at the bottom of a SOT23 package, top of a DFN 8 package(coming soon) or front of a TO92 package is defined as positive field. silabs.com | Building a more connected world. Rev. 1.4 | 20 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Package Outline 6. Package Outline 6.1 SOT23 3-Pin Package silabs.com | Building a more connected world. Rev. 1.4 | 21 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Package Outline Table 6.1. SOT23 3-Pin Package Dimensions Dimension Min Max A -- 1.25 A1 0.00 0.10 A2 0.85 1.15 b 0.30 0.50 c 0.10 0.20 D 2.90 BSC E 2.75 BSC E1 1.60 BSC e 0.95 BSC e1 1.90 BSC L 0.30 0.60 θ 0° 8° aaa 0.15 bbb 0.20 ccc 0.10 ddd 0.20 Note: 1. All dimensions shown are in millimeters (mm) unless otherwise noted. 2. Dimensioning and Tolerancing per ANSI Y14.5M-1994. 3. This drawing conforms to the JEDEC Solid State Outline MO-193, Variation AB. 4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020D specification for Small Body Components. silabs.com | Building a more connected world. Rev. 1.4 | 22 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Package Outline 6.2 SOT23-5 5-Pin Package silabs.com | Building a more connected world. Rev. 1.4 | 23 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Package Outline Table 6.2. SOT23-5 5-Pin Package Dimensions Dimension Min Max A -- 1.25 A1 0.00 0.10 A2 0.85 1.15 b 0.30 0.50 c 0.10 0.20 D 2.90 BSC E 2.75 BSC E1 1.60 BSC e 0.95 BSC e1 1.90 BSC L 0.30 L2 θ 0.60 0.25 BSC 0° 8° aaa 0.15 bbb 0.20 ccc 0.10 ddd 0.20 Note: 1. All dimensions shown are in millimeters (mm) unless otherwise noted. 2. Dimensioning and Tolerancing per ANSI Y14.5M-1994. 3. This drawing conforms to the JEDEC Solid State Outline MO-193, Variation AB. 4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020D specification for Small Body Components. silabs.com | Building a more connected world. Rev. 1.4 | 24 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Package Outline 6.3 TO92S 3-Pin Package Table 6.3. TO92S 3-Pin Package Dimensions Dimension Min Max A 1.42 1.62 A1 0.66 0.86 b 0.33 0.48 b1 0.40 0.51 b2 0 0.76 c 0.33 0.51 D 3.90 4.10 D1 2.28 2.68 E 3.05 3.25 e 1.27 TYP e1 2.44 2.46 L 15.10 15.50 θ 45° TYP Notes: 1. All dimensions shown are in millimeters (mm) unless otherwise noted. 2. Dimensioning and Tolerancing per ANSI Y14.5M-1994. silabs.com | Building a more connected world. Rev. 1.4 | 25 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Land Patterns 7. Land Patterns 7.1 SOT23 3-Pin PCB Land Pattern Dimension (mm) C 2.70 E 0.95 X 1.05 Y 0.60 silabs.com | Building a more connected world. Rev. 1.4 | 26 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Land Patterns 7.2 SOT23-5 5-Pin PCB Land Pattern Dimension (mm) C 2.70 E 0.95 X 1.05 Y 0.60 Note: General 1. All dimensions shown are in millimeters (mm) unless otherwise noted. 2. Dimensioning and Tolerancing is per the ANSI Y14.5M-1994 specification. 3. This Land Pattern Design is based on the IPC-7351 guidelines. 4. All dimensions shown are at Maximum Material Condition (MMC). Least Material Condition (LMC) is calculated based on a Fabrication Allowance of 0.05 mm. Card Assembly 1. A No-Clean, Type-3 solder paste is recommended. 2. The recommended card reflow profile is per the JEDEC/IPC J-STD-020D specification for Small Body Components. silabs.com | Building a more connected world. Rev. 1.4 | 27 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Top Marking 8. Top Marking 8.1 SOT23 3-Pin Top Marking Note: TTTT is a manufacturing code. silabs.com | Building a more connected world. Rev. 1.4 | 28 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Top Marking 8.2 SOT23-5 5-Pin Top Marking Note: TTTT is a manufacturing code. 8.3 TO92 Top Marking Note: TTTT is a manufacturing code. PPPP is 72xx. silabs.com | Building a more connected world. Rev. 1.4 | 29 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Revision History 9. Revision History Revision 1.4 May, 2020 • Added EOL note for Si7205/06 in the Ordering Guide (200324717 End of Life Notification for High Voltage Si72xx Devices). Revision 1.3 October, 2019 • Updated Chapter 5. Ordering Guide with newly released part numbers. • Si7203-B-01-IV • Added specific pinout for newly release Si7203-B-01-IV Revision 1.2 July, 2019 • Updated Chapter 5. Ordering Guide with newly released part numbers. • Si7201-B-1x • Si7201-B-2x • Si7201-B-3x • Si7201-B-4x • Si7201-B-8x • Si7201-B-9x • Updated wording on frontpage to clarify package types and switch vs latch Revision 1.1 March, 2019 • Removed all mention of AEC-Q100 qualification in product description and feature list. Revision 1.0 July 2018 • Updated power numbers to be consistent with production test limits. • Added more detailed part characteristics to the ordering guide. • Updated detailed description to be clearer and more accurate. Revision 0.92 October 4, 2017 • Added new part number to Chapter 5. Ordering Guide (Si7202-B-01-IV(R). Revision 0.91 August 7, 2017 • Added new part number to Chapter 5. Ordering Guide (Si7201-B-08-IV(R). Revision 0.9 June 30, 2017 • Updated Chapter 1. Electrical Specifications . • Updated Chapter 5. Ordering Guide. • Minor typo corrections. silabs.com | Building a more connected world. Rev. 1.4 | 30 Si720x Switch/Latch Hall Effect Magnetic Position Sensor Data Sheet Revision History Revision 0.1 February 1, 2016 • Initial release. silabs.com | Building a more connected world. Rev. 1.4 | 31 Smart. Connected. Energy-Friendly. Products Quality Support and Community www.silabs.com/products www.silabs.com/quality community.silabs.com Disclaimer Silicon Labs intends to provide customers with the latest, accurate, and in-depth documentation of all peripherals and modules available for system and software implementers using or intending to use the Silicon Labs products. Characterization data, available modules and peripherals, memory sizes and memory addresses refer to each specific device, and "Typical" parameters provided can and do vary in different applications. Application examples described herein are for illustrative purposes only. Silicon Labs reserves the right to make changes without further notice to the product information, specifications, and descriptions herein, and does not give warranties as to the accuracy or completeness of the included information. Without prior notification, Silicon Labs may update product firmware during the manufacturing process for security or reliability reasons. Such changes will not alter the specifications or the performance of the product. Silicon Labs shall have no liability for the consequences of use of the information supplied in this document. This document does not imply or expressly grant any license to design or fabricate any integrated circuits. The products are not designed or authorized to be used within any FDA Class III devices, applications for which FDA premarket approval is required, or Life Support Systems without the specific written consent of Silicon Labs. A "Life Support System" is any product or system intended to support or sustain life and/or health, which, if it fails, can be reasonably expected to result in significant personal injury or death. Silicon Labs products are not designed or authorized for military applications. Silicon Labs products shall under no circumstances be used in weapons of mass destruction including (but not limited to) nuclear, biological or chemical weapons, or missiles capable of delivering such weapons. Silicon Labs disclaims all express and implied warranties and shall not be responsible or liable for any injuries or damages related to use of a Silicon Labs product in such unauthorized applications. Trademark Information Silicon Laboratories Inc.®, Silicon Laboratories®, Silicon Labs®, SiLabs® and the Silicon Labs logo®, Bluegiga®, Bluegiga Logo®, ClockBuilder®, CMEMS®, DSPLL®, EFM®, EFM32®, EFR, Ember®, Energy Micro, Energy Micro logo and combinations thereof, "the world’s most energy friendly microcontrollers", Ember®, EZLink®, EZRadio®, EZRadioPRO®, Gecko®, Gecko OS, Gecko OS Studio, ISOmodem®, Precision32®, ProSLIC®, Simplicity Studio®, SiPHY®, Telegesis, the Telegesis Logo®, USBXpress® , Zentri, the Zentri logo and Zentri DMS, ZWave®, and others are trademarks or registered trademarks of Silicon Labs. ARM, CORTEX, Cortex-M3 and THUMB are trademarks or registered trademarks of ARM Holdings. Keil is a registered trademark of ARM Limited. Wi-Fi is a registered trademark of the Wi-Fi Alliance. All other products or brand names mentioned herein are trademarks of their respective holders. Silicon Laboratories Inc. 400 West Cesar Chavez Austin, TX 78701 USA http://www.silabs.com
