PS-2-4000S IN-PHASE TWO-WAY POWER COMBINER/DIVIDER 20-4000 MHz DESCRIPTION
A two-way in-phase hybrid power combiner/divider is a 180° hybrid power combiner/divider with the difference port (A) internally terminated. As a two-way power divider, a signal fed into the input port yields two in-phase output signals 3 dB down from the input power. As a two-way power combiner, signals applied to the output ports yield a Vector sum at the input port.
FREQUENCY BANDS IN MHz
PARAMETER Input Return Loss (dB min) Output Return Loss (dB min) Insertion Loss (dB max) Amplitude Imbalance (dB max) Phase Imbalance (° max) Isolation (dB min) 20-70 14 11.3 1.0 ± 0.1 ±1 13 701000 14 11.3 1.25 ± 0.2 ±3 10002000 14 11.3 1.75 ± 0.3 ±4 18 20003000 14 11.3 2.0 ± 0.6 ±6 18 30004000 14 11.3 3.0 ± 1.0 ±8 15
18
PORT 1 2 3
FUNCTIONAL SCHEMATIC
IN OUT 1
FUNCTION Out 2 Input Out 1
OUT 2
PACKAGE
MATERIAL:
Housing and Cover: Aluminum Connector Body: Stainless Steel per QQW-S-764, Class 303,Cond A. Contacts: Beryllium Copper per QQ-C-530, Half hard Dielectric: Polytetrafluorethylene per MIL-P-19468 Fed. Std. L-P-403.
ALL DIMENSIONS ARE IN INCHES [mm].
FINISH:
Housing and Cover: Bright Nickel per QQ-N-290, Class I, Form SB, Grade F. Contacts: Gold per MIL-G-45204, Type 1, Grade C, Class 2.
ENVIRONMENTAL CONDITIONS
GUARANTEED ENVIRONMENTAL PERFORMANCE:
All units are designed to meet their specifications over –54°C to +100°C after exposure to any or all of the following tests per MIL-STD-202. Exposure Thermal Shock Altitude H.F. Vibratons Mechanical Shock Random Vibration
(15 minutes per axis) TOLERANCES: .XX = ±.01 .XXX = ±.005
Method 107 105 204 213 214
Test Condition B G D C IIF
`
3.21.05 Rev. A Sirenza Microdevices • 303 Technology Court • Broomfield, Colorado 80021 Phone: (303) 327-3030 • Fax: (303) 410-7088 • Email: sales@sirenza.com • Website: www.sirenza.com
