SP-FE-LX-CNC

Fast Ethernet SFP Transceiver SP-FE-LX Features • Compliant with OC3/STM-1, IEEE 802.3ah, 100BASE-LX10 • Single 3.3 V Supply • 10 dB Minimum Link Budget • 15 km Minimum Reach • 1310nm FP Laser • Commercial Temperature Available (-Cxx) • Industrial Temperature Available (-Txx) • SFP MSA SFF-8074i Compliant • Telcordia GR-468 Compliant • Digital Diagnostic SFF-8472 Compliant • Color coded bail latch tube: Grey • RoHS-5/6 compliant product (lead exemption) (-xxA) • RoHS-6/6 compliant product (lead free soldering) (-xxC) General operating Parameter Supply Voltage Total Current Power Supply Noise Rejectiona Operating Temperature (-Cxx) Operating Temperature (-Txx) Storage Temperature Data Rate a)20 Hz to 155 MHz Symbol Vcc Icc PSR Top Top Tst DR Min. 3.135 100 -5 -40 -40 10 Typical 3.3 125 Max. 3.465 300 70 85 85 155 Unit V mA mVp-p ºC ºC ºC Mbps Transmitter Specifications Parameter Optical Power Average Launch Power Of Off Tx Extinction Ratio Eye Mask Optical Rise Timeb Optical Fall Timeb Mean Wavelength Spectral Width (RMS) Optical Return Loss Tolerance b) 20%-80% values tr tf λ Δλ ORLT 1260 1310 Symbol POP POff Min -15 6.6 Typical -11 - Max -8 -45 2 2 1360 7.7 12 Unit dBm dBm dB ns ns nm nm dB ER IEEE 802.3ah and SONET/SDH Compliant LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 1 LUMNDS856-Dec0806 Rev A.1 Fast Ethernet SFP Transceiver SP-FE-LX Transmitter Specifications (Electical) Parameter Input Differential Impedence PECL Single Ended Data Input Swing TxFault_Fault TxFault_Normal TxDisable_Disable TxDisable_Enable Symbol Rin Vin,p-p Vfault Vnormal Vd Ven Min 80 250 2 Vee 2 Vee Typical 100 Max 120 1200 Vcc Vee+0.5 Vcc Vee+0.8 Unit Ω mV V V V V Receiver Specifications Parameter Receive Power Lowc Receive Power High Damage Threshold For Receiver Wavelengthd Los Assert Los De-assert Los Hysteresis c) 27-1 PRBS, BER 10-12 d) Operational over 1200 to 1625 nm range Electrical Output Parameter PECL Single Ended Data Output Swing Data Output Rise Time Data Output Fall Time Symbol Vout, p-p tr tf Min 185 Typical Max 800 2 2 Unit mV ns ns Symbol Rsens,low Rsens,high Pin,damage λ Min -8 0 1260 -44 0.5 Typical -34 1310 Max -25 1360 -25 Unit dBm dBm dBm nm dBm dBm dB Timing and Electrical Parameter Tx Disable Negate Time Tx Disable Assert Time Time To Initialize, Including Reset Of Tx Fault Tx Fault Assert Time Tx Disable To Reset Los Assert Time Los De-assert Time Serial ID Clock Rate RX_LOS Voltage (High) RX_LOS Voltage (Low) Los Output Voltage-Fault Los Output Voltage-Normal MOD_DEF (0:2)-High MOD_DEF (0:2)-LOW VLOS fault VLOSnormal Vh Vl Symbol t_on t_off t_init t_fault t_reset t_loss_on t_loss_off f_serial_clock Min 10 2 2 Vee 2 Vee Typical Max 25 10 300 100 300 100 100 0.8 Vcc Vee+0.5 Vcc Vee+0.5 Unit ms µs ms µs µs µs µs KHz V V V V V V LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 2 LUMNDS856-Dec0806 Rev A.1 Fast Ethernet SFP Transceiver SP-FE-LX Digital Diagnostics Parameter Temperature (-CDx) Temperature (-TDx) Voltage Bias Current Tx Power Rx Power Range -5 to 70 -40 to 85 0 to Vcc 0 to 120 -15 to -8 -25 to -8 Accuracy ±3 ±3 0.1 5 ±3 ±3 Unit ºC ºC V mA dBm dBm Calibration Bit Value Internal Internal Internal External External External 1/256 C 1/256 C 100µV Formula Tc(C) = Tad(16 bit signed twos complement)/256 Tc(C) = Tad(16 bit signed twos complement)/256 V(Volts) = Vad(16 bit unsigned integer)*0.1 I(mA) = Islope * Iad(16 bit unsigned integer)+Ioffset Tx_PWR(µW) = Tx_PWRslope*Tx_PWRad(16 bit unsigned integer)+Tx_PWRoffset Rx_PWR(µW) = A0+A1*x+A2*x^2+A3*x^3+A4*x^4 EEPROM Serial ID Name of Field Description of Field Address 20 21 22 23 24 Vendor Name SFP Vendor name(ASCII) 25 26 27 28 29 30 37 Vendor OUI IEEE vendor OUI code for LuminentOIC Inc. 38 39 40 41 42 Vendor PN Part number in ASCII, e.g. SP-FE-LX-CDA 43 44 45 46 47 48 Hex 4C 55 4D 49 4E 45 4E 54 4F 49 43 00 06 B5 53 50 46 45 4C 58 43 44 41 S P F E L X C D A ASCII L U M I N E N T O I C LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 3 LUMNDS856-Dec0806 Rev A.1 Fast Ethernet SFP Transceiver SP-FE-LX Pinout Definitions Pin 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Function VeeT TX_FAULT TX_DISABLE MOD_DEF2 MOD_DEF1 MOD_DEF0 NC LOS Notes TX GND Open Collector Internally Pulled High Serial Data Input Serial Clock Input Internally Grounded Not Connected Open Collector RX Ground RX Ground RX Ground RX Data Negative RX Data Positive RX GND RX Power TX Power TX GND TX Data Positive TX Data Negative TX GND VeeR VeeR VeeR RXDRXD+ VeeR VccR VccT VeeT TXD+ TXDVeeT LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 4 LUMNDS856-Dec0806 Rev A.1 Fast Ethernet SFP Transceiver SP-FE-LX Outline drawing Units in mm(inches) LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 5 LUMNDS856-Dec0806 Rev A.1 Fast Ethernet SFP Transceiver SP-FE-LX Suggested Transceiver Interface 1�H Vcc 10�F 0.1�F 1�H .01�F VCCT Protocol IC R1 TX_DISABLE 10K� TX_DISABLE LuminentOIC SFP TX_FAULT TX_FAULT Laser Driver .01�F SerDes TD + 100� TD VEET .01�F VCCR 10�F 0.1�F RD + Receiver Amplifier .01�F 100� RD - RX_LOS Vcc RX_LOS R 1 .01�F VEER EEPROM R1 R1 R1 MOD_DEF 2 MOD_DEF 1 R1=4.7K to 10K� MOD_DEF 0 LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 6 LUMNDS856-Dec0806 Rev A.1 Fast Ethernet SFP Transceiver SP-FE-LX Ordering Information Available Options: SP-FE-LX-CDA SP-FE-LX-CDC SP-FE-LX-CNA SP-FE-LX-CNC SP-FE-LX-TDA SP-FE-LX-TDC SP-FE-LX-TNA SP-FE-LX-TNC Part numbering Definition: SP • SP= Small Form Pluggable • Data Rate FE = Fast Ethernet (100 Mbps) • Standard LX = 100BASE-LX10 - FE - LX - Temperature Diagnostic Revision • Operating Temperature C = Commercial temperature (-5 to 70ºC) T = Industrial temperature (-40 to 85ºC) • D = Digital diagnostic (SFF-8472) N = No Digital diagnostic • Design Revision A = RoHS-5/6 compliant product (lead exemption) C = RoHS-6/6 compliant product (no exemption) Warnings: Handling Precautions: This device is susceptible to damage as a result of electrostatic discharge (ESD). A static free environment is highly recommended. Follow guidelines according to proper ESD procedures. Laser Safety: Radiation emitted by laser devices can be dangerous to human eyes. Avoid eye exposure to direct or indirect radiation. Legal Notes: IMPORTANT NOTICE! All information contained in this document is subject to change without notice, at LuminentOIC’s sole and absolute discretion. LuminentOIC warrants performance of its products to current specifications only in accordance with the company’s standard one-year warranty; however, specifications designated as “preliminary” are given to describe components only, and LuminentOIC expressly disclaims any and all warranties for said products, including express, implied, and statutory warranties, warranties of merchantability, fitness for a particular purpose, and non-infringement of proprietary rights. Please refer to the company’s Terms and Conditions of Sale for further warranty information. LuminentOIC assumes no liability for applications assistance, customer product design, software performance, or infringement of patents, services, or intellectual property described herein. No license, either express or implied, is granted under any patent right, copyright, or intellectual property right, and LuminentOIC makes no representations or warranties that the product(s) described herein are free from patent, copyright, or intellectual property rights. Products described in this document are NOT intended for use in implantation or other life support applications where malfunction may result in injury or death to persons. LuminentOIC customers using or selling products for use in such applications do so at their own risk and agree to fully defend and indemnify LuminentOIC for any damages resulting from such use or sale. THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROVIDED ON AN “AS IS” BASIS. Customer agrees that LuminentOIC is not liable for any actual, consequential, exemplary, or other damages arising directly or indirectly from any use of the information contained in this document. Customer must contact LuminentOIC to obtain the latest version of this publication to verify, before placing any order, that the information contained herein is current. © LuminentOIC, Inc. 2003 All rights reserved LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 7 LUMNDS856-Dec0806 Rev A.1
