SPC-12-LR-47TDA

SPC-12-LR-47TDA

  • 厂商:

    SOURCE

  • 封装:

  • 描述:

    SPC-12-LR-47TDA - 622 Mbps CWDM SFP Transceiver - Source Photonics, Inc.

  • 数据手册
  • 价格&库存
SPC-12-LR-47TDA 数据手册
622 Mbps CWDM SFP Transceiver SPC-12-LR Features • Compliant with OC12/STM-4 Standards • Single 3.3 V supply • 26 dB minimum link budget • CWDM DFB Laser, 80 km reach • Commercial Temperature Available (-CDA) • Industrial Temperature Available (-TDA) • SFP MSA SFF-8074i compliant • Digital Diagnostic SFF-8472 Compliant • Telcordia GR-468 compliant • RoHS compliant General operating Parameter Supply Voltage Total Current, -40 to Power Supply Noise -5ºCa Total Current, -5 to 85ºC Rejectionb Operating Temperature (-CDA) Operating Temperature (-TDA) Storage Temperature Data Rate OC12/STM-4 a) Denotes deviation from MSA b) 20Hz to 155MHz Symbol Vcc Icc Icc Min. 3.135 100 -5 -40 -40 - Typical 3.3 622 Max. 3.465 500 300 70 85 85 - Unit V mA mA mVp-p ºC ºC ºC Mbps PSR Top Top Tst DR Transmitter Specifications Parameter Optical Power Average Launch Power Of Off Tx Extinction Ratio Eye Mask Optical Jitter Generation Optical Rise Timec Optical Fall Timec Mean Wavelength Spectral Width (-20dB width) Side Mode Suppression Ratio Dispersion Penalty (at 80 Km) Relative Intensity Noise c) 20%-80% values RIN Jgen tr tf λ ∆λ SMSR Symbol POP POff Min -2 10 1xx1-6.5 - Typical 0 1xx1 0.5 - Max +3 -45 0.002 500 500 1xx1+6.5 1 30 1 -120 Unit dBm dBm dB SONET/SDH compliant UI ps ps nm nm dB dB dB/Hz ER LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 1 LUMNDS1926-Aug1108 Rev A.0 622 Mbps CWDM SFP Transceiver SPC-12-LR Transmitter Specifications (Electical) Parameter Input Differential Impedence PECL Single Ended Data Input Swing TxFault_Fault TxFault_Normal TxDisable_Disable TxDisable_Enable Symbol Rin Vin,p-p Vfault Vnormal Vd Ven Min 80 250 2 Vee 2 Vee Typical 100 Max 120 1200 Vcc Vee+0.5 Vcc Vee+0.8 Unit Ω mV V V V V Receiver Specifications Parameter Receive Power Lowd Receive Power High Damage Threshold For Receiver Wavelength LOS Assert LOS De-assert LOS Hysteresis d) 10-12 BER at nominal wavelength Electrical Output Parameter PECL Single Ended Data Output Swing Data Output Rise Time Data Output Fall Time Symbol Vout, p-p tr tf Min 185 Typical Max 800 500 500 Unit mV ps ps Symbol Rsens,low Rsens,high Pin,damage λ Min -8 0 1200 -45 0.5 Typical -30 Max -28 1625 -28 Unit dBm dBm dBm nm dBm dBm dB Timing and Electrical Parameter Tx Disable Negate Time Tx Disable Assert Time Time To Initialize, Including Reset Of Tx Fault Tx Fault Assert Time Tx Disable To Reset Los Assert Time Los De-assert Time Serial ID Clock Rate RX_LOS Voltage (High) RX_LOS Voltage (Low) LOS Output Voltage-Fault LOS Output Voltage-Normal MOD_DEF (0:2)-High MOD_DEF (0:2)-LOW VLOS fault VLOSnormal Vh Vl Symbol t_on t_off t_init t_fault t_reset t_loss_on t_loss_off f_serial_clock Min 10 2 2 Vee 2 Vee Typical Max 1 10 300 100 100 100 100 0.8 Vcc Vee+0.5 Vcc Vee+0.5 Unit ms µs ms µs µs µs µs KHz V V V V V V LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 2 LUMNDS1926-Aug1108 Rev A.0 622 Mbps CWDM SFP Transceiver SPC-12-LR Diagnostics Parameter Temperature (-CDA) Temperature (-TDA) Voltage Bias current TX Power RX Power Range -5 to 70 -40 to 85 0 to Vcc 0 to 120 -2 to +3 -28 to -8 Accuracy ±3 ±3 ±0.1 ±5 ±3 dB ±3 dB Unit ºC ºC V mA dBm dBm Calibration External External External External External External Formula Tc(C) = Tslope*Tad(16 bit signed twos complement value) + Toffset Tc(C) = Tslope*Tad(16 bit signed twos complement value) + Toffset V(Volts) = Vslope*Vad (16 bit unsigned integer) + Voffset I(mA)=Islope*Iad(16 bit unsigned integer)+Ioffset TX_PWR(µW)=TX_PWRslope*TX_PWRad(16 bit unsigned integer) +TX_PWRoffset RX_PWR(µW)=A0+A1*x+A2*x^2+A3*x^3+A4*x^4 Pinout Definitions Pin 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Function VeeT TX_FAULT TX_DISABLE MOD_DEF2 MOD_DEF1 MOD_DEF0 NC LOS Notes TX Ground Open Collector Internally Pulled High Serial Data Input Serial Clock Input Internally Grounded Not Connected Open Collector RX Ground RX Ground RX Ground RX Data Negative RX Data Positive RX Ground RX Power TX Power TX Ground TX Data Positive TX Data Negative TX Ground VeeR VeeR VeeR RXDRXD+ VeeR VccR VccT VeeT TXD+ TXDVeeT LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 3 LUMNDS1926-Aug1108 Rev A.0 622 Mbps CWDM SFP Transceiver SPC-12-LR EEPROM Serial ID Name of Field Description of Field Address 20 21 22 23 24 Vendor Name SFP Vendor name(ASCII) 25 26 27 28 29 30 37 Vendor OUI IEEE vendor OUI code for LuminentOIC Inc. 38 39 40 41 42 43 44 Vendor PN Part number in ASCII, e.g. SPC12LRxxCDA 45 46 47 48 49 50 51 Hex 4C 55 4D 49 4E 45 4E 54 4F 49 43 00 06 B5 53 50 43 31 32 4C 52 xx xx 43 44 41 S P C 1 2 L R x x C D A ASCII L U M I N E N T O I C LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 4 LUMNDS1926-Aug1108 Rev A.0 622 Mbps CWDM SFP Transceiver SPC-12-LR Outline drawing Units in mm(inches) LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 5 LUMNDS1926-Aug1108 Rev A.0 622 Mbps CWDM SFP Transceiver SPC-12-LR Suggested Transceiver Interface 1�H Vcc 10�F 0.1�F 1�H .01�F VCCT Protocol IC R1 TX_DISABLE 10K� TX_DISABLE LuminentOIC SFP TX_FAULT TX_FAULT Laser Driver .01�F SerDes TD + 100� TD VEET .01�F VCCR 10�F 0.1�F RD + Receiver Amplifier .01�F 100� RD - RX_LOS Vcc RX_LOS R 1 .01�F VEER EEPROM R1 R1 R1 MOD_DEF 2 MOD_DEF 1 R1=4.7K to 10K� MOD_DEF 0 LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 6 LUMNDS1926-Aug1108 Rev A.0 622 Mbps CWDM SFP Transceiver SPC-12-LR Ordering Information Available Options: SPC-12-LR-xxCDA SPC-12-LR-xxTDA Part numbering Definition: SPC - 12 - LR - xx Temperature Diagnostic Revision • SPC = Small Form Pluggable CWDM 12 = OC12, 622 Mbps LR = Long Reach 80 km • xx = 1xx1 nm center wavelength 47, 49, 51, 53, 55, 57, 59, 61 • Operating Temperature C = Commercial Temperature (-5 to 70ºC) T = Industrial Temperature (-40 to 85ºC) • D = Digital Diagnostic (SFF-8472) • Design Revision A = RoHS compliant Warnings: Handling Precautions: This device is susceptible to damage as a result of electrostatic discharge (ESD). A static free environment is highly recommended. Follow guidelines according to proper ESD procedures. Laser Safety: Radiation emitted by laser devices can be dangerous to human eyes. Avoid eye exposure to direct or indirect radiation. Legal Notes: IMPORTANT NOTICE! All information contained in this document is subject to change without notice, at LuminentOIC’s sole and absolute discretion. LuminentOIC warrants performance of its products to current specifications only in accordance with the company’s standard one-year warranty; however, specifications designated as “preliminary” are given to describe components only, and LuminentOIC expressly disclaims any and all warranties for said products, including express, implied, and statutory warranties, warranties of merchantability, fitness for a particular purpose, and non-infringement of proprietary rights. Please refer to the company’s Terms and Conditions of Sale for further warranty information. LuminentOIC assumes no liability for applications assistance, customer product design, software performance, or infringement of patents, services, or intellectual property described herein. No license, either express or implied, is granted under any patent right, copyright, or intellectual property right, and LuminentOIC makes no representations or warranties that the product(s) described herein are free from patent, copyright, or intellectual property rights. Products described in this document are NOT intended for use in implantation or other life support applications where malfunction may result in injury or death to persons. LuminentOIC customers using or selling products for use in such applications do so at their own risk and agree to fully defend and indemnify LuminentOIC for any damages resulting from such use or sale. THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROVIDED ON AN “AS IS” BASIS. Customer agrees that LuminentOIC is not liable for any actual, consequential, exemplary, or other damages arising directly or indirectly from any use of the information contained in this document. Customer must contact LuminentOIC to obtain the latest version of this publication to verify, before placing any order, that the information contained herein is current. © LuminentOIC, Inc. 2003 All rights reserved LUMINENTOIC.COM 20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486 9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213 7 LUMNDS1926-Aug1108 Rev A.0
SPC-12-LR-47TDA 价格&库存

很抱歉,暂时无法提供与“SPC-12-LR-47TDA”相匹配的价格&库存,您可以联系我们找货

免费人工找货
