T-11-1250-R3-M

PIN-TIA Receiver Modules-Receptacle & Pigtailed(3.3V) T-11-1250-X3-XXX-X-XX Features • InGaAs/InP PIN Photodiode with transimpedance amplifier • High sensitivity with AGC* • Differential ended output • Single +3.3V operation • -40~85ºC operating temperature Packaging • FC/ST/SC receptacle packaged • SM/MM fiber pigtailed with optional FC/ST/SC connector Application • 1.25Gbps SDH/SONET/ATM receivers • RoHS Compliant available Absolute Maximum Ratings (Tc=25ºC) Parameter Supply Voltage Operating Temperature Storage Temperature Symbol VCC Topr Tstg Value 4.5 -40 ~ 85 -40 ~ 85 Unit V ºC ºC DC Electrical Characteristics (Tc=25ºC) Parameter Power Supply Differential Ouptput Voltage Supply Current (no load) Symbol VCC Vd Icc Min. 3.0 185 - Typ. 3.3 250 26 Max. 3.6 415 50 Unit V mV mA (Operating at Vcc=3.3V , Tc=25ºC , λ=1310nm , 9/125µm SM fiber & 50/125µm MM fiber) AC/Optical and Electrical Characteristics (Tc=25ºC) Parameter Detection Range Gain@10Mbps Differential Bandwidth (to -3dB point) Saturation Power Sensitivity Output Resistance Symbol - Min 1100 1.92 700 -3 48 Typ 1310 2.5 920 0 -26 50 Max 1650 3.4 1100 -23 62 Unit nm V/mW MHz dBm dBm ohm Test Conditions Measure differentially with 30uAp-p signal BER
