EE-13

General Power Transformer Type: EE-13 ◆ Product Description ・14.0×13.0mm Max.(L×W), 13.5mm Max. Height. ・In addition to the typical versions of parameters shown here, custom designs are available to meet your exact requirements ◆ Feature ・Max. Operating frequency 300kHz, Max Operating Power 9.2W(300kHz), 3.1W(100kHz). ・Ideally used in AC adapter, switching power supply, DC/DC converter. ・RoHS Compliance ◆ Dimensions (mm) 2 .5 2. 5 2 .5 2 . 5 ± 0 .2 14.0 MAX. φ 0.6 ±0.1 13.0 MAX. ①PIN 13.5 MAX. 3.5 ±1.0 8.5 ±0.3 ◆ Schematics (Bottom) ⑤ S④ ③ ② S① “ S” is winding start ⑥ ⑦S ⑧ ⑨S ⑩ ◆ Specification Sample No. 3386-T147 Inductance (1-3) 1kHz/1V Leakage Inductance (1-3) 1kHz/1V Hi-pot (1,2,3,4,5-7,8,9,10)(50/60Hz) AC 1200Vrms/1sec. 10.5mH ± 20% 2.0mH Max. Please refer to the sales offices on our website for a representative near you www.sumida.com 1/1
