LC-128_1

General Power Transformer Type: LC-128 ◆ Product Description ・￠13.0mm Max.(L×W), 8.5mm Max. Height. ・In addition to the typical versions of parameters shown here, custom designs are available to meet your exact requirements. ◆ Feature ・Magnetically shielded construction. ・Max. Operating frequency 500kHz, Max. Operating Power 5.0W (500kHz), 3.6W(300kHz), 1.5W(100kHz) ・Ideally used in Portable equipment, Drive for fluorescent display tube. ・RoHS Compliance ◆ Dimensions (mm) +0.1 φ0.5-0.05 36 ゜ MAX.8.5 +1.0 -0.5 2.5 φ10.0±0.3 φ12.5±0.5 ◆ Schematics (Bottom) S ④ ③ ② S ⑤ ⑥ ⑦S ⑧S ⑨ S ① “ S” is winding start ◆ Specification Sample No. 0351 -T158 Inductance (7-9) 1kHz/1V 2.3mＨ±30% D.C.R. (1-2) 1.18Ω Max. D.C.R. (3-4) 273 mΩ Max D.C.R. (5-6) 124 mΩ Max Please refer to the sales offices on our website for a representative near you www.sumida.com 1/1
