SM-10C

IFT COILS < Pin Type: SM Series> Type: SM-10C ◆ Product Description ・10.3×10.3mm Max.(L×W), 12.5mm Max. Height. ・Operating frequency: 30MHz Max. ・In addition to the reference versions of parameters shown here, custom designs are available to meet your exact requirements. . ◆ Feature ・Variable shielded type. ・RoHS Compliance ◆ Dimensions (mm) +0.1 φ0.7-0.05 ◆Connection (Bottom View) ③ 10 ±0.3 ④ 7±0.2 ② S① ⑥S 1 2.5 Max. +1.0 -0.5 3.5 7.0±0.2 10.0±0.3 “S”is winding start. ＊ Dimension does not include solder used on coil. ＊ Pin pitch should be measured at the root of terminal. ◆ Specification (Part No.S07165221) Item Inductance Unloaded Q (１−３) ２７５μＨ±１０％ Variable １８０ Min Measuring Condition ７９６ｋＨｚ ７９６ｋＨｚ Please refer to the sales offices on our website for a representative near you www.sumida.com 1/1
