SM-10F

IFT COILS < Pin Type: SM Series> Type: SM-10F ◆ Product Description ・11.0×11.0mm Max.(L×W), 16.0mm Max. Height. ・Operating frequency: 30MHz Max. ・In addition to the reference versions of parameters shown here, custom designs are available to meet your exact requirements. ◆ Feature ・High inductance fixed shielded type. ・Can be used as DC-DC converter transformer. ・RoHS Compliance ◆ Dimensions (mm) 1.5±0.3 4.0±0.5 7.0±0.2 +0.1 φ0.7-0 .05 11.0 M AX . 1kHz 100kHz 1/1 1 6.0 MA X. 3.5 +1.0 -0.5 11.0 MAX. ＊ Dimension does not include solder used on coil. ＊ Pin pitch should be measured at the root of terminal. ◆ Connection (Bottom View) ③ S② ◆ Specification (Part No.: 4309-T001) Measuring Condition Variable ④S Item (4-6) Inductance S① ⑥ 850µH±6% Unloaded Qu “S” is winding start. 60 Min. Please refer to the sales offices on our website for a representative near you w ww.sumida.com 7.0±0.2
