12A-2.5-12

POWER TRANSFORMER 1. CONFIGURATION & DIMENSIONS : H W Square PC terminals C 12A-2.5-12 (F) SERIES C A 3.500(0.138) Min. B L A A B A PCB Pattern D UNIT : mm (inch) VA 2.5 gram 115.0 L 35.30 W 30.00 H 32.00 A 6.30 B 6.30 C 30.70 D 36.00 E F Dim Pin 0.70 SQ (0.027)SQ (1.390) (1.182) (1.260) (0.250) (0.250) (1.210) (1.420) 2. SCHEMATIC : 4 115V 50/60Hz 3 2 115V 50/60Hz 1 indicates polarity 8 7 6 5 3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. No Load Primary Current c. Secondary Voltage (±5%) d. Secondary Load Current e. Full Load Primary Current f. Full Load Secondary Voltage (±5%) g. DC Resistance Pin 1-2 Pin 3-4 Pin 5-6 Pin 7-8 h. Insulation Resistance i. Withstand Voltage (Hi-Pot) j. Temperature Rise k. Core Size AC 115/230 V 60/50 Hz . Less Than 40mA . Series AC - V Parallel AC - V Series 200 mA . Parallel 400 mA . Less Than - mA . Series 12.6 V . Parallel 6.3 V . Primary = 845 Ohm . = 690 Ohm . Secondary = - Ohm . = - Ohm . DC 500V 100Meg Ohm Of More . AC 3750V 50Hz 1 Minutes . Less Than 75 Deg C . EI-35 x 14.00 m/m . NOTE : Specifications subject to change without notice. Please check our website for latest information. 25.02.2008 SUPERWORLD ELECTRONICS (S) PTE LTD PG. 1
