14A-10-28

POWER TRANSFORMER 1. CONFIGURATION & DIMENSIONS : W E Square PC terminals 14A-10-28 (F) SERIES C C A D B L 4.763(0.187) Min. A A H Clearance for optional WTG screws F B A PCB Pattern UNIT : mm (inch) VA 10.00 gram 240.4 L 48.50 W 40.50 H 35.30 A 5.08 B 10.16 C 28.96 D E F 31.75 Dim Pin 0.80 SQ (1.910) (1.595) (1.390) (0.200) (0.400) (1.140) (1.250) (0.032)SQ 2. SCHEMATIC : 4 115V 50/60Hz 3 2 115V 50/60Hz 1 indicates polarity 8 7 6 5 3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. No Load Primary Current Input AC 115V 60Hz . Input AC 230V 50Hz . c. Secondary Voltage (±5%) d. Secondary Load Current e. Full Load Primary Current Input AC 115V 60Hz . Input AC 230V 50Hz . f. Full Load Secondary Voltage (±5%) g. DC Resistance Pin 1-2 Pin 3-4 Pin 5-6 Pin 7-8 h. Insulation Resistance i. Withstand Voltage (Hi-Pot) j. Temperature Rise k. Core Size AC 115/230 V 50/60 Hz . Less Than 50mA . Less Than 60mA . Series AC 34.60V . C.T. Parallel AC 17.30V . Series 360mA . Parallel 720mA . Less Than 120mA . Less Than 120mA . Series 28.00V . C.T. Parallel 14.00V . Primary = 180 Ohm . = 215 Ohm . Secondary = - Ohm . = - Ohm . DC 500V 100Meg Ohm Of More . AC 3750V 50Hz 1 Minutes . Less Than 75 Deg C . EI-48 x 16.80 m/m . NOTE : Specifications subject to change without notice. Please check our website for latest information. 25.02.2008 SUPERWORLD ELECTRONICS (S) PTE LTD PG. 1
