14A-2.5-20

POWER TRANSFORMER 1. CONFIGURATION & DIMENSIONS : W E Square PC terminals 14A-2.5-20 (F) SERIES C C A D B L 4.763(0.187) Min. A A H Clearance for optional WTG screws F B A PCB Pattern UNIT : mm (inch) VA 2.500 gram 113.4 L 41.28 W 33.33 H 28.58 A 5.08 B 6.35 C 25.4 D E F 26.98 Dim Pin 0.64 SQ (1.625) (1.312) (1.125) (0.200) (0.250) (1.000) (1.062) (0.025)SQ 2. SCHEMATIC : 4 115V 50/60Hz 3 2 115V 50/60Hz 1 indicates polarity 8 7 6 5 3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. NO Load Primary Current Input AC 115V 60Hz . Input AC 230V 50Hz . c. Secondary Voltage (±5%) d. Secondary Load Current e. Full Load Primary Current Input AC 115V 60Hz . Input AC 230V 50Hz . f. Full Load Secondary Voltage (±5%) g. DC Resistance Pin 1-2 Pin 3-4 Pin 5-6 Pin 7-8 h. Insulation Resistance i. Withstand Voltage (HI-POT) j. Temperature Rise k. Core Size AC 115/230 V 50/60 Hz . Less Than 25mA . Less Than 30mA . Series AC 27.00V . Parallel AC 13.50V . Series 120mA . Parallel 240mA . Less Than 45mA . Less Than 50mA . Series 20.00V . C.T. Parallel 10.00V . Primary = 800 Ohm . = 1030 Ohm . Secondary = - Ohm . = - Ohm . DC 500V 100Meg Ohm Of More . AC 3750V 50Hz 1 Minutes . Less Than 75 Deg C . EI-41 x 10.40 m/m . NOTE : Specifications subject to change without notice. Please check our website for latest information. 25.02.2008 SUPERWORLD ELECTRONICS (S) PTE LTD PG. 1
