14A-30-10

POWER TRANSFORMER 1. CONFIGURATION & DIMENSIONS : W E Square PC terminals 14A-30-10 (F) SERIES C C A A D B L 4.763(0.187) Min. A A H Clearance for optional WTG screws F B PCB Pattern UNIT : mm (inch) VA 30.0 gram 521.63 L 66.68 W 55.55 H 40.80 A 13.97 B 6.99 C 42.67 D 55.37 E 44.45 F Dim Pin 1.1 SQ (0.043)SQ (2.625) (2.187) (1.610) (0.550) (0.275) (1.680) (2.180) (1.750) 2. SCHEMATIC : 6 115V 50/60Hz 4 3 115V 50/60Hz 1 indicates polarity 12 10 9 7 3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. No Load Primary Current Input AC 115V 60Hz . Input AC 230V 50Hz . c. Secondary Voltage (±5%) d. Secondary Load Current e. Full Load Primary Current Input AC 115V 60Hz . Input AC 230V 50Hz . f. Full Load Secondary Voltage (±5%) g. DC Resistance Pin 1-3 Pin 4-6 Pin 7-9 Pin 10-12 h. Insulation Resistance i. Withstand Voltage (Hi-Pot) j. Temperature Rise k. Core Size AC 115/230 V 50/60 Hz . Less Than 70mA . Less Than 70mA . Series AC 12.00V . C.T. Parallel AC 6.00V . Series 3000mA . Parallel 6000mA . Less Than 210mA . Less Than 150mA . Series 10.00V . C.T. Parallel 5.00V . Primary = 52 Ohm . = 64 Ohm . Secondary = - Ohm . = - Ohm . DC 500V 100Meg Ohm Of More . AC 3750V 50Hz 1 Minutes . Less Than 75 Deg C . EI-66 x 16.80 m/m . NOTE : Specifications subject to change without notice. Please check our website for latest information. 25.02.2008 SUPERWORLD ELECTRONICS (S) PTE LTD PG. 1
