POWER TRANSFORMER
1. CONFIGURATION & DIMENSIONS :
9.53 (0.375)
CS3-10 (F) SERIES
W B
A
4.76(0.187)Quick Connect Solder Lug Terminal 4.76(0.187)Dia. Mfg. Holes
6.35 (0.250) 4.76 (0.187) 3.96 (0.156)
8
7
6
5
H
4
3
2
1
ML L 2.39 (0.094)
UNIT : mm (inch) SIZE 3 VA 2.4 L 52.40 (2.063) W 27.00 (1.063) H 30.18 (1.188) A 41.28 (1.625) B 14.30 (0.563) ML 44.45 (1.75) gram 113.40
2. SCHEMATIC :
1 5
7
4 " " indicates polarity
8
3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. No Load Primary Current c. Secondary Voltage (±5%) Pin 5-8 C.T. Pin 7 d. Secondary Load Current e. Full Load Primary Current f. Full Load Secondary Voltage (±5%) Pin 5-8 C.T. Pin 7 g. DC Resistance Pin 1-2 Pin 5-7 Pin 7-8 h. Insulation Resistance i. Withstand Voltage (Hi-Pot) j. Temperature Rise k. Core Size l. Turns & Wire Gauge Primary Pin 1-4 Secondary Pin 5-7-8 AC 115 V 60 Hz . Less Than 10mA . AC 12.40 V . 0.25A . Less Than 40mA . 10.00V .
Primary = 320 Ohm . Secondary-1 = 2.45 Ohm . Secondary-2 = 2.45 Ohm . DC 500V 100Meg Ohm Of More . AC 2500V 60Hz 1 Minutes . Less Than 60 Deg C . EI-35 x 13.00 m/m . 2669 Turns Diameter 145 x 2 Turns Diameter
NOTE : Specifications subject to change without notice. Please check our website for latest information.
25.02.2008
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 1
