CS4-30

POWER TRANSFORMER 1. CONFIGURATION & DIMENSIONS : 9.53 (0.375) CS4-30 (F) SERIES W B A 4.76(0.187)Quick Connect Solder Lug Terminal 4.76(0.187)Dia. Mfg. Holes 6.35 (0.250) 4.76 (0.187) 3.96 (0.156) 8 7 6 5 H 4 3 2 1 ML L 2.39 (0.094) UNIT : mm (inch) SIZE 4 VA 6 L 60.33 (2.375) W 31.75 (1.250) H 34.93 (1.375) A 42.88 (1.688) B 17.48 (0.688) ML 50.80 (2.000) gram 199.58 2. SCHEMATIC : 1 5 7 4 " " indicates polarity 8 3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. No Load Primary Current c. Secondary Voltage (±5%) Pin 5-8 C.T. Pin 7 d. Secondary Load Current e. Full Load Primary Current f. Full Load Secondary Voltage (±5%) Pin 5-8 C.T. Pin 7 g. DC Resistance Pin 1-2 Pin 5-7 Pin 7-8 h. Insulation Resistance i. Withstand Voltage (Hi-Pot) j. Temperature Rise k. Core Size AC 115 V 60 Hz . Less Than 20mA . AC 36.80 V . 0.20A . Less Than 80mA . 30.00V . Primary = 145 Ohm . Secondary-1 = - Ohm . Secondary-2 = - Ohm . DC 500V 100Meg Ohm Of More . AC 2500V 60Hz 1 Minutes . Less Than 60 Deg C . EI-41 x 17.00 m/m . NOTE : Specifications subject to change without notice. Please check our website for latest information. 15.01.2008 SUPERWORLD ELECTRONICS (S) PTE LTD PG. 1
