CS5-12

POWER TRANSFORMER 1. CONFIGURATION & DIMENSIONS : 9.53 (0.375) CS5-12 (F) SERIES W B A 4.76(0.187)Quick Connect Solder Lug Terminal 4.76(0.187)Dia. Mfg. Holes 6.35 (0.250) 4.76 (0.187) 3.96 (0.156) 8 7 6 5 H 4 3 2 1 ML L 2.39 (0.094) UNIT : mm (inch) SIZE 5 VA 12 L 71.45 (2.813) W 38.10 (1.500) H 41.28 (1.625) A 49.23 (1.938) B 24.61 (0.969) ML 60.33 (2.375) gram 317.51 2. SCHEMATIC : 1 5 7 4 " " indicates polarity 8 3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. No Load Primary Current c. Secondary Voltage (±5%) Pin 5-8 C.T. Pin 7 d. Secondary Load Current e. Full Load Primary Current f. Full Load Secondary Voltage (±5%) Pin 5-8 C.T. Pin 7 g. DC Resistance Pin 1-2 Pin 5-7 Pin 7-8 h. Insulation Resistance i. Withstand Voltage (Hi-Pot) j. Temperature Rise k. Core Size l. Turns & Wire Gauge Primary Pin 1-4 Secondary Pin 5-7-8 AC 115 V 60 Hz . Less Than 20mA . AC 15.10 V . 1.0A . Less Than 180mA . 12.60V . Primary = 71.10 Ohm . Secondary-1 = 0.561 Ohm . Secondary-2 = 0.632 Ohm . DC 500V 100Meg Ohm Of More . AC 2500V 60Hz 1 Minutes . Less Than 60 Deg C . EI-48 x 20.80 m/m . 1027 Turns Diameter 0-68-136 Turns Diameter 0.18 m/m . 0.50 m/m . NOTE : Specifications subject to change without notice. Please check our website for latest information. 25.02.2008 SUPERWORLD ELECTRONICS (S) PTE LTD PG. 1
