CS6-6

POWER TRANSFORMER 1. CONFIGURATION & DIMENSIONS : 9.53 (0.375) 4.76(0.187)Quick Connect Solder Lug Terminal CS6-6 (F) SERIES W B A 10 9 8 7 6 4.76(0.187)Dia. Mfg. Holes 4.76 (0.187) 3.96 (0.156) 6.35 (0.250) H 5 4 3 2 1 ML L 2.39 (0.094) UNIT : mm (inch) SIZE 6 VA 30 L 82.55 (3.250) W 42.88 (1.688) H 49.23 (1.938) A 74.63 (2.938) B 27.00 (1.063) ML 71.45 (2.813) gram 498.95 2. SCHEMATIC : 2 6 8 4 " " indicates polarity 10 3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. No Load Primary Current c. Secondary Voltage (±5%) Pin 6-10 C.T. Pin 8 d. Secondary Load Current e. Full Load Primary Current f. Full Load Secondary Voltage (±5%) Pin 6-10 C.T. Pin 8 g. DC Resistance Pin 2-4 Pin 6-8 Pin 8-10 h. Insulation Resistance i. Withstand Voltage (Hi-Pot) j. Temperature Rise k. Core Size l. Turns & Wire Gauge Primary Pin 2-4 Secondary Pin 6-8-10 AC 115 V 60 Hz . Less Than 35mA . AC 7.2 V . 5.00A . Less Than 340mA . 6.00V . Primary = 22.50 Ohm . Secondary-1 = - Ohm . Secondary-2 = - Ohm . DC 500V 100Meg Ohm Of More . AC 2500V 60Hz 1 Minutes . Less Than 60 Deg C . EI-57 x 26.00 m/m . 684 Turns Diameter 0.28 m/m . 0-22-44 Turns Diameter 1.10 m/m . NOTE : Specifications subject to change without notice. Please check our website for latest information. 25.02.2008 SUPERWORLD ELECTRONICS (S) PTE LTD PG. 1
