CS7-10

POWER TRANSFORMER 1. CONFIGURATION & DIMENSIONS : 9.53 (0.375) 4.76(0.187)Quick Connect Solder Lug Terminal CS7-10 (F) SERIES W B A 10 9 8 7 6 4.76(0.187)Dia. Mfg. Holes 4.76 (0.187) 3.96 (0.156) 6.35 (0.250) H 5 4 3 2 1 ML L 2.39 (0.094) UNIT : mm (inch) SIZE 7 VA 56 L 93.68 (3.688) W 46.05 (1.813) H 57.15 (2.250) A 68.28 (2.688) B 27.00 (1.063) ML 79.38 (3.125) gram 771.11 2. SCHEMATIC : 2 6 8 4 " " indicates polarity 10 3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. No Load Primary Current c. Secondary Voltage (±5%) Pin 6-10 C.T. Pin 8 d. Secondary Load Current e. Full Load Primary Current f. Full Load Secondary Voltage (±5%) Pin 6-10 C.T. Pin 8 g. DC Resistance Pin 2-4 Pin 6-8 Pin 8-10 h. Insulation Resistance i. Withstand Voltage (Hi-Pot) j. Temperature Rise k. Core Size l. Turns & Wire Gauge Primary Pin 2-4 Secondary Pin 6-8-10 AC 115 V 60 Hz . Less Than 30mA . AC 11.60 V . 5.00A . Less Than 620mA . 10.00V . Primary = 10.50 Ohm . Secondary-1 = 0.06 Ohm . Secondary-2 = 0.07 Ohm . DC 500V 100Meg Ohm Of More . AC 2500V 60Hz 1 Minutes . Less Than 60 Deg C . EI-66 x 26.00 m/m . 585 Turns Diameter 0-30-60 Turns Diameter 0.40 m/m . 1.20 m/m . NOTE : Specifications subject to change without notice. Please check our website for latest information. 25.02.2008 SUPERWORLD ELECTRONICS (S) PTE LTD PG. 1
