PC40-20

POWER TRANSFORMER 1. CONFIGURATION & DIMENSIONS : H 1.0414 (0.041) W B A-6 A-6 PC40-20 (F) SERIES A-6 B 2 5 6 L 1 3 4 A-6 4.76 (0.188) PC Terminal (Plug-in mounting) TYPE PC 6 PINS PCB Pattern UNIT : mm (inch) SIZE (VA) 1.0 L 25.40 (1.000) W 35.30 (1.390) H 21.08 (0.830) A-6 6 PIN 6.35 (0.250) B 30.48 (1.200) WT. (gram) 98.93 OPTIONAL BRACKET * NO. --MW --MD --- 2. SCHEMATIC : 1 3 1 3 115V PRI 4 5 115V PRI Eo 4 5 Eo 2 Series Connected 6 2 Parallel Connected 6 3. ELECTRICAL CHARACTERISTICS ( @ 25°C ) : a. Primary Voltage b. No Load Primary Current c. Secondary Voltage (±5%) d. Secondary Load Current e. Full Load Primary Current f. Full Load Secondary Voltage (±5%) g. DC Resistance Pin 1-2 Pin 3-4 Pin 5-6 h. Insulation Resistance i. Withstand Voltage (Hi-Pot) j. Temperature Rise k. Core Size l. Turns & Wire Gauge Primary Pin 1-2 Secondary-1 Pin 3-4 Secondary-2 Pin 5-6 AC 115 V 60 Hz . Less Than 10mA . Series AC 48.00 V . Parallel AC 24.00 V . Series 20mA . Parallel 40mA . Less Than 15 mA . Series 40.00V . Parallel 20.00V . Primary = 820 Ohm . Secondary = 107.80 Ohm . = 116.10 Ohm . DC 500V 100Meg Ohm Of More . AC 1500V 60Hz 1 Minutes . Less Than 60 Deg C . EI-25.4 x 18.50 m/m . 3000 629 629 Turns Diameter Turns Diameter Turns Diameter 0.07 m/m . 0.10 m/m . 0.10 m/m . NOTE : Specifications subject to change without notice. Please check our website for latest information. 25.02.2008 SUPERWORLD ELECTRONICS (S) PTE LTD PG. 1
