KDS-20-225

DIRECTIONAL COUPLER MODEL KDS-20-225 OPTIMIZED BANDWIDTH SPECIFICATIONS: Operating Frequency: Coupling: Coupling Flatness: Mainline Loss: 225 - 400 MHz 20.0 dB ± 1.0 dB (Nom) ± 0.5 dB 0.2 dB (Typ) 0.4 dB (Max) 50 Watts (CW) Directivity: VSWR: Impedance: Operating Temp. Range: 18 dB (Min) 25 dB (Typ) 1.20:1 (Typ) 1.35:1 (Max) 50 Ohms -40o to +70oC 225 - 400 MHz Input Power MECHANICAL OUTLINE: 255 PIN-OUT Input 6 Output 1 Fwd. Coupled 4 No Connection 3 Case Ground 2,5 Copyright © 2004 Synergy Microwave Corporation 201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361 E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com DIRECTIONAL COUPLER MODEL KDS-20-225 OPTIMIZED BANDWIDTH PERFORMANCE PLOTS 225 - 400 MHz Copyright © 2004 Synergy Microwave Corporation 201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361 E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
