DOUBLE-BALANCED MIXER SURFACE MOUNT MODEL: SGM-2-17
WIDE BANDWIDTH
FEATURES: ► High Reliability ► Low Construction Cost ► Small Size, Surface Mount ► RoHS Compliant ► Lead Free REL-PRO® Technology
SPECIFICATIONS (Rev. B 05/24/07)
Frequency (MHz) RF/LO 250 - 3250 Typ. 6.5 Typ. Isolation (dB) LO/RF LO/IF RF/IF LO Power 1 dB Comp. Pt. Input IP3 RF Input Power Impedance Operating Temperature Range +17 dBm (Nom.) +10 dBm (Typ.) +18 dBm (Typ.) 100 mW (Max.) 50 Ohms (Nom.) -40 to +85 °C 30 10 30 IF DC - 700 Max. 8.5 Min. 15 5 15 Package # 310
250 - 3250 MHz
Conversion Loss (dB)
Copyright © 2006 Synergy Microwave Corporation 201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361 E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
DOUBLE-BALANCED MIXER SURFACE MOUNT MODEL: SGM-2-17
WIDE BANDWIDTH 250 - 3250 MHz
0 -1 -2 -3 -4 -5 -6 -7 -8 -9 -10 250 550 850 1150 1450 1750 2050 2350 2650 2950 3250
PERFORMANCE PLOTS
Conversion Loss (dB)
RF Frequency (MHz)
+10 dBm +13 dBm +17 dBm
25 20
Input IP3 (dBm)
15
10 5 0 250 550 850 1150 1450 1750 2050 2350 2650 2950 3250 RF Frequency (MHz)
+10 dBm +13 dBm +17 dBm
Copyright © 2006 Synergy Microwave Corporation 201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361 E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
DOUBLE-BALANCED MIXER SURFACE MOUNT MODEL: SGM-2-17
WIDE BANDWIDTH 250 - 3250 MHz
PERFORMANCE PLOTS
0
LO-IF Isolation (dB)
-5 -10 -15 -20 -25 250
550
850
1150 1450 1750 2050 2350 2650 2950 3250 Frequency (MHz) +10 dBm +13 dBm +17 dBm
0
LO-RF Isolation (dB)
-5 -10 -15 -20 -25 -30 -35 -40 250 550 850 1150 1450 1750 2050 2350 2650 2950 3250 Frequency (MHz) +10 dBm +13 dBm +17 dBm
Copyright © 2006 Synergy Microwave Corporation 201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361 E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
DOUBLE-BALANCED MIXER SURFACE MOUNT MODEL: SGM-2-17
WIDE BANDWIDTH 250 - 3250 MHz
0 -5
RF-IF Isolation (dB)
PERFORMANCE PLOTS
-10 -15 -20 -25 -30 -35 -40 -45 250 550 850 1150 1450 1750 2050 2350 2650 2950 3250 Frequency (MHz) +10 dBm +13 dBm +17 dBm
Copyright © 2006 Synergy Microwave Corporation 201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361 E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
