SPD-5-1000

4-WAY POWER DIVIDER SURFACE MOUNT MODEL SPD-5-1000 WIDE BANDWIDTH SPECIFICATIONS: (Rev. A 07/12/06) Operating Frequency: Insertion Loss: (dB) 5-50 MHz 50-500 MHz 500-1000 MHz Isolation: (dB) 5-50 MHz 50-500 MHz 500-1000 MHz 5 - 1000 MHz (Typ) / (Max) 0.7 / 1.0 0.65 / 1.0 0.7 / 1.0 (Typ) / (Min) 27 / 20 23 / 20 23 / 20 Phase Unbalance: Amplitude Unbalance: Impedance: VSWR: Input: Output: Input Power: Operating Temp. Range: 5.0º (Max) 0.5 dB (Max) 50 ohms 1.3:1 (Max) 1.3:1 (Max) 1 Watt (Max) -40ºC to +85º C 5 - 1000 MHz MECHANICAL OUTLINE:219 Copyright © 2006 Synergy Microwave Corporation 201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361 E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com 4-WAY POWER DIVIDER SURFACE MOUNT MODEL SPD-5-1000 WIDE BANDWIDTH PERFORMANCE PLOTS 5 - 1000 MHz Copyright © 2006 Synergy Microwave Corporation 201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361 E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
