SP100 and V400 Series Speakers and Speaker/Strobes A Division of Pittway 3825 Ohio Avenue, St. Charles, IL 60174 1-800-SENSOR2 (736-7672), Fax 630-377-6495 http://www.systemsensor.com SP101 Speaker V400 Speaker with ADA Strobe SP100 Speaker Features • Dual voltages: 25 and 70.7 Vrms • Multiple selectable taps –SP100: 1/8 – 4 watts –V400: 1/4 – 2 watts • Peak dBA: –SP100: 96 @ 4 watts –V400: 90 @ 2 watts • Multiple strobe options –ADA/UL 1971 @ 15, 15/75, 75, or 110 cd (24 VDC only) • Listed to UL Standard 1480 for speakers for fire protective signaling systems System Sensor SP100 Series and V400 Series Speakers are the Sound ChoiceTM for voice, tone, and visible signaling. The SP100 Series are high quality speakers and speaker/strobe combinations for evacuation signaling designed to meet UL1480 Fire Standard Specifications. Sound Choice speakers are available with ADA/UL1971 listed strobes for public mode applications. Specifications – SP100 Series Mechanical Input Terminals: Grille Size/Color: Round: Square: Weight: Mounting: 12 to 18 AWG 8″ (203 mm)/white 5″ (127 mm)/red or white 1.6 lb (725 gm) 4″ × 4″ × 21/8″ backbox with 4″ × 4″ × 11/2″ extension ring Included 32° to 120° F (0° to 49° C) APPROVED Electrical Voltage Input: Frequency Range: 25 volts or 70.7 volts (nominal) 400 – 4000 Hz Although the SP100 Series speaker/strobe combination is sold as a unit, the speaker and strobe are electrically independent and require separate power sources. See chart on page 2 for strobe operating requirements. Filler Plugs: Operating Temperature Range: © System Sensor 9/97 This document is not intended to be used for installation purposes. A05-191-04 SP100 Series Speaker/Strobe Power Requirements Supply Voltage: Max. Current @ Listed Voltage: Operating Current @ Rectified Unfiltered Voltage: Rated Light Output SP1W2415ADA SP1R2415ADA 20–30 VDC 75 mA 90 mA 15.0 cd SP1W241575ADA SP1R241575ADA 20–30 VDC 93 mA 120 mA 15/75 cd SP1W2475ADA SP1R2475ADA 20–30 VDC 170 mA 200 mA 75.0 cd SP1W24110ADA SP1R24110ADA 20–30 VDC 210 mA 245 mA 110.0 cd Specifications – V400 Series Mechanical Input Terminals: Grille Size/Color: Weight: Mounting: Semiflush*: Flush*: 14 to 18 AWG 4″ (102 mm)/red or beige .7 lb (317 gm) 4″ × 4″ × 11/2″–21/8″ standard backbox** deep backbox (BBD) with flush mounting plate Operating Temperature Range: Electrical Voltage Input: Frequency Range: 32° to 120° F (0° to 49° C) 25 volts or 70.7 volts (nominal) 400 – 4000 Hz *Order mounting plates separately. **For 12- or 14-gauge wire, a 21/8″ backbox is recommended. Engineering Specifications Speaker shall be a System Sensor Model ______ dual transformer speaker capable of operating at 25 and 70.7 Vrms. Speaker shall be listed to Underwriter’s Laboratories Standard 1480 for fire protective signaling systems. Speaker shall have a frequency range of 400 to 4000 Hz and shall have an operating temperature between 32° and 120° F. Speaker shall have power taps which are selected by means of a jumper wire(s). For speaker/strobe combination: Speaker/strobe shall be a System Sensor Speaker/Strobe Model ______ dual transformer speaker capable of operating at 25 and 70.7 Vrms. Speaker/strobe shall be listed to Underwriter’s Laboratories Standard 1480 for fire protective signaling systems. Speaker shall have a frequency range of 400 to 4000 Hz and shall have an operating temperature between 32° and 120° F. Speaker shall have power taps which are selected by means of a jumper wire(s). Strobe shall be powered independently of the speaker and shall operate from a 24 VDC or 24 Vrms full wave rectified unfiltered power supply. Strobe shall have a light output rating of 15, 75, or 110 candela and shall be UL 1971 listed as a primary signaling device. Page 2 A05-191-04 Power Tap Selection and Sound Output Jumper Wire, 25 V: Jumper Wire, 70.7 V: UL Reverberant (dBA @ 10 ft): Anechoic (dBA @ 10 ft): Peak Anechoic (dBA @ 10 ft): 4W 1B 2A 90 93 96 2W 1A 3B 87 90 93 SP100* 1 1W /2 W 2B 2A 4B 5B 84 87 90 81 84 87 V400 1 /4 W 3B 6B 78 81 84 1 /8 W 4B 6A 75 78 81 2 – – 84 87 90 1 – – 81 84 87 1 /2 – – 1 /4 – – 78 81 84 75 78 81 * Example: To select 1/4 watt output @ 25 V connect blue lead to post #3, yellow to post B. Power Tap Selection 2W 1/4W 1W 1/2W RED TO STROBE BLADE FROM PANEL OR PREVIOUS DEVICE BLACK TO STROBE BLADE COM 25 70.7 STROBE TO NEXT DEVICE OR EOL 25 OR 70.7V TO NEXT DEVICE OR EOL SP100 V400 4″×4″×21/8″ BACKBOX 4″×4″×11/2″ EXTENSION RING 8-32 SCREWS MP-SF #8 NUTS 8-32x5/8 V400 8-32x5/8 #8 S.M. STROBE/SPEAKER (SP101 SERIES) SP101 Mounting Diagram FILLER PLUGS 8-32X1-7/16 #8 S.M. 8-32X1-7/16 V400 Semiflush Mounting Diagram Page 3 A05-191-04 Ordering Information – Sound ChoiceTM Speakers Description SP100 Series Speakers Red White – SP100W SP101R SP101W SP1R2415ADA SP1W2415ADA SP1R241575ADA SP1W241575ADA SP1R2475ADA SP1W2475ADA SP1R24110ADA SP1W24110ADA V400 Series Speakers Red Beige V400R V400B V4R2415ADA – V4R241575ADA – V4R2475ADA – V4R24110ADA – MP-F MP-FB BB-D – MP-SF MP-SFB Speaker Voltage Strobe Voltage Candela Round, 8″ grille, 1/8–4 watt power taps Square, 5″ grille, 1/8–4 watt power taps Square, 5″ grille, 1/8–4 watt power taps, wall strobe, UL 1971 Square, 5″ grille, 1/8–4 watt power taps, wall strobe, UL 1971 Square, 5″ grille, 1/8–4 watt power taps, wall strobe, UL 1971 Square, 5″ grille, 1/8–4 watt power taps, wall strobe, UL 1971 25/70.7 Vrms 25/70.7 Vrms 25/70.7 Vrms 25/70.7 Vrms 25/70.7 Vrms 25/70.7 Vrms – – 24 VDC 24 VDC 24 VDC 24 VDC – – 15 cd 15/75 cd 75 cd 110 cd White V400W – – – – MP-FW – MP-SFW Square, 4″ grille, 1/4–2 watt power taps Square, 4″ grille, 1/4–2 watt power taps, wall strobe, UL 1971 Square, 4″ grille, 1/4–2 watt power taps, wall strobe, UL 1971 Square, 4″ grille, 1/4–2 watt power taps, wall strobe, UL 1971 Square, 4″ grille, 1/4–2 watt power taps, wall strobe, UL 1971 Flush mounting plate Flush mounting deep backbox, 23/4″ deep Semi-flush mounting plate 25/70.7 Vrms 25/70.7 Vrms 25/70.7 Vrms 25/70.7 Vrms 25/70.7 Vrms – 24 VDC 24 VDC 24 VDC 24 VDC – 15 cd 15/75 cd 75 cd 110 cd UL 1638 Strobe attachments for V400* Red Beige SS12LO – SS24LO SS24LOB SS24LOC – SS24M – SS24MC – Signal strobe Signal strobe Ceiling mount signal strobe Signal strobe Ceiling mount signal strobe – – – – – 12 VDC 24 VDC 24 VDC 24 VDC 24 VDC 1.5 cd 1.5 cd 1.5 cd 15 cd 15 cd * Although the SSLO and SSM Series signal strobes are UL listed as primary signaling devices, when combined with the V400 speaker they are considered as a secondary signaling device only. How to Order SP100 Series Speakers with Strobes SP1R2415ADA 15 = 15 cd, UL 1971 Strobe 1575 = 15 cd, UL 1971, 75 cd on axis 75 = 75 cd, UL 1971 Strobe 110 = 110 cd, UL 1971 Strobe 24 = 24 VDC Strobe SP1R = Square Grille, Red Speaker SP1W = Square Grille, White Speaker V4R = V400 Square, Red Speaker System Sensor Worldwide Manufacturing & Distribution In Canada: Telephone: 905-812-0767 Fax: 905-812-0771 In China: Telephone: 852-2191-9003 Fax: 852-2736-6580 Page 4 In the Far East: Telephone: 852-2191-9003 Fax: 852-2736-6580 In India: Telefax: 91-022-8202564 In Italy: Telephone: 39-40-9490-111 Fax: 39-40-382137 In the United Kingdom: Telephone: 44-1403-276500 Fax: 44-1403-276501 A05-191-04
