BRL1608T100M

for General Electronic Equipment Notice for TAIYO YUDEN products Please read this notice before using the TAIYO YUDEN products. REMINDERS ■ Product Information in this Catalog Product information in this catalog is as of October 2020. All All of of the the January 2021. contents specified herein and production status of the products listed in this catalog are subject to change without notice due to technical improvement of our products, etc. Therefore, please check for the latest information carefully before practical application or use of our products. (4) Powe r g e n e r atio n c o ntro l e quip m e nt (nu c le a r p owe r, hydroelectric power, thermal power plant control system, etc.) (5) Undersea equipment (submarine repeating equipment, underwater work equipment, etc.) (6) Military equipment (7) Any other equipment requiring extremely high levels of safety and/or reliability equal to the equipment listed above Please note that TAIYO YUDEN shall not be in any way responsible for any damages and defects in products or equipment incorporating our products, which are caused under the conditions other than those specified in this catalog or individual product specification sheets. *Notes: 1. There is a possibility that our products can be used only for aviation equipment that does not directly affect the safe operation of aircraft (e.g., in-flight entertainment, cabin light, electric seat, cooking equipment) if such use meets requirements specified separately by TAIYO YUDEN. Please be sure to contact TAIYO YUDEN for further information before using our products for such aviation equipment. 2. Implantable medical devices contain not only internal unit which is implanted in a body, but also external unit which is connected to the internal unit. ■ Approval of Product Specifications Ple a se c ont ac t TA IYO YUD EN for fur the r det a ils of p ro duc t specifications as the individual product specification sheets are available. When using our products, please be sure to approve our product specifications or make a written agreement on the product specification with TAIYO YUDEN in advance. ■ Pre-Evaluation in the Actual Equipment and Conditions Please conduct validation and verification of our products in actual conditions of mounting and operating environment before using our products. ■ Limited Application 1. Equipment Intended for Use The products listed in this catalog are intended for generalpurpose and standard use in general electronic equipment (e.g., AV equipment, OA equipment, home electric appliances, office equipment, information and communication equipment including, without limitation, mobile phone, and PC) and other equipment specified in this catalog or the individual product specification sheets. TAIYO YUDEN has the line-up of the products intended for use in automotive electronic equipment, telecommunications infrastructure and industrial equipment, or medical devices classified as GHTF Classes A to C (Japan Classes I to III). Therefore, when using our products for these equipment, please check available applications specified in this catalog or the individual product specification sheets and use the corresponding products. 2. Equipment Requiring Inquiry Please be sure to contact TAIYO YUDEN for further information before using the products listed in this catalog for the following equipment (excluding intended equipment as specified in this catalog or the individual product specification sheets) which may cause loss of human life, bodily injury, serious property damage and/or serious public impact due to a failure or defect of the products and/or malfunction attributed thereto. (1) Transportation equipment (automotive powertrain control system, train control system, and ship control system, etc.) (2) Traffic signal equipment (3) Disaster prevention equipment, crime prevention equipment (4) Medical devices classified as GHTF Class C (Japan Class III) (5) H i g h l y p u b l i c i n f o r m a t i o n n e t wo r k e q u i p m e n t , d a t a processing equipment (telephone exchange, and base station, etc.) (6) Any other equipment requiring high levels of quality and/or reliability equal to the equipment listed above 3. Equipment Prohibited for Use Please do not incorporate our products into the following equipment requiring extremely high levels of safety and/or reliability. (1) Aerospace equipment (artificial satellite, rocket, etc.) (2) Aviation equipment *1 (3) Medical devices classified as GHTF Class D (Japan Class IV), implantable medical devices *2 4. Limitation of Liability Please note that unless you obtain prior written consent of TAIYO YUDEN, TAIYO YUDEN shall not be in any way responsible for any damages incurred by you or third parties arising from use of the products listed in this catalog for any equipment that is not intended for use by TAIYO YUDEN, or any equipment requiring inquiry to TAIYO YUDEN or prohibited for use by TAIYO YUDEN as described above. ■ Safety Design When using our products for high safety and/or reliability-required equipment or circuits, please fully perform safety and/or reliability evaluation. In addition, please install (i) systems equipped with a protection circuit and a protection device and/or (ii) systems equipped with a redundant circuit or other system to prevent an unsafe status in the event of a single fault for a failsafe design to ensure safety. ■ Intellectual Property Rights Information contained in this catalog is intended to convey examples of typical performances and/or applications of our products and is not intended to make any warranty with respect to the intellectual property rights or any other related rights of TAIYO YUDEN or any third parties nor grant any license under such rights. ■ Limited Warranty Please note that the scope of warranty for our products is limited to the delivered our products themselves and TAIYO YUDEN shall not be in any way responsible for any damages resulting from a failure or defect in our products. Notwithstanding the foregoing, if there is a written agreement (e.g., supply and purchase agreement, quality assurance agreement) signed by TAIYO YUDEN and your company, TAIYO YUDEN will warrant our products in accordance with such agreement. ■ TAIYO YUDEN’s Official Sales Channel The contents of this catalog are applicable to our products which are purchased from our sales offices or authorized distributors (hereinafter “TAIYO YUDEN’ s official sales channel”). Please note that the contents of this catalog are not applicable to our products purchased from any seller other than TAIYO YUDEN’ s official sales channel. ■ Caution for Export Some of our products listed in this catalog may require specific procedures for export according to“U.S. Export Administration Regulations”,“Foreign Exchange and Foreign Trade Control Law” of Japan, and other applicable regulations. Should you have any questions on this matter, please contact our sales staff. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) . 2 21 for General Electronic Equipment WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES） WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES） REFLOW ■PARTS NUMBER B R ① * Operating Temp.：-40～+105℃（Including self-generated heat） △ L ② 2 5 1 ③ T ④ 2 R 2 ⑤ M △ △ △ ⑥ ⑦ ④Packaging Code T Series name Wire-Wound chip power inductor ⑤Nominal inductance Code （example） R20 1R0 100 101 ※R＝Decimal point Characteristics Low profile High current ③Dimensions（L×W） Code Type（inch） 1608 2012 2016 2518 3225 1608（0603） 2012（0805） 2016（0806） 2518（1007） 3225（1210） Packaging Taping Dimensions （L×W）［mm］ 1.6×0.8 2.0×1.25 2.0×1.6 2.5×1.8 3.2×2.5 ⑥Inductance tolerance Code K M Nominal inductance［μH］ 0.2 1.0 10 100 Inductance tolerance ±10％ ±20％ ⑦Internal code ■STANDARD EXTERNAL DIMENSIONS / STANDARD QUANTITY Recommended Land Patterns Surface Mounting ・Mounting and soldering conditions should be checked beforehand. L W ・Applicable soldering process to these products is reflow soldering Type A 1608 0.55 T C 2012 0.60 2016 0.60 e 2518 0.60 B A A 3225 0.85 Type BR L1608 BR C1608 BR L2012 BR C2012 BR C2016 BRFL2518 BR L2518 BRHL2518 BR C2518 BR L3225 POWER INDUCTORS ②Characteristics Code FL △L HL △C △＝Blank space INDUCTORS ①Series name Code BR 8 only. B 0.70 1.00 1.00 1.50 1.70 C 1.00 1.45 1.80 2.00 2.70 Unit：mm Standard quantity［pcs］ Paper tape Embossed tape L W T e 1.6±0.2 （0.063±0.008） 1.6±0.2 （0.063±0.008） 2.0±0.2 （0.079±0.008） 2.0±0.2 （0.079±0.008） 2.0±0.2 （0.079±0.008） 2.5±0.2 （0.098±0.008） 2.5±0.2 （0.098±0.008） 2.5±0.2 （0.098±0.008） 2.5±0.2 （0.098±0.008） 3.2±0.2 （0.126±0.008） 0.8±0.2 （0.031±0.008） 0.8±0.2 （0.031±0.008） 1.25±0.2 （0.049±0.008） 1.25±0.2 （0.049±0.008） 1.6±0.2 （0.063±0.008） 1.8±0.2 （0.071±0.008） 1.8±0.2 （0.071±0.008） 1.8±0.2 （0.071±0.008） 1.8±0.2 （0.071±0.008） 2.5±0.2 （0.098±0.008） 0.7 max （0.028 max） 0.8±0.2 （0.031±0.008） 1.0 max （0.040 max） 1.4 max （0.056 max） 1.6±0.2 （0.063±0.008） 1.0 max （0.040 max） 1.2 max （0.048 max） 1.5 max （0.060 max） 1.8±0.2 （0.071±0.008） 1.7 max （0.068 max） 0.45±0.15 （0.016±0.006） 0.45±0.15 （0.016±0.006） 0.5±0.2 （0.020±0.008） 0.5±0.2 （0.020±0.008） 0.5±0.2 （0.020±0.008） 0.5±0.2 （0.020±0.008） 0.5±0.2 （0.020±0.008） 0.5±0.2 （0.020±0.008） 0.5±0.2 （0.020±0.008） 0.75±0.2 （0.03±0.008） － 3000 － 3000 － 3000 － 2000 － 2000 － 3000 － 3000 － 2000 － 2000 － 2000 Unit：mm（inch） i_wound_BR_e-E08R01.doc ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) . 21 67 for General Electronic Equipment ■PARTS NUMBER ●1608（0603）type EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS 1.0 1.5 2.2 3.3 4.7 6.8 10 15 ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ 700 600 400 300 150 100 45 32 0.230 0.280 0.400 0.650 1.00 1.64 2.00 2.56 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） 6 6 6 6 6 6 RoHS RoHS RoHS RoHS RoHS RoHS 0.43 0.50 0.60 0.72 0.82 1.0 ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ 740 710 630 600 560 550 0.082 0.090 0.099 0.144 0.176 0.188 Parts number EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS 0.20 0.35 0.45 0.56 0.77 1.0 1.5 2.2 ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ 400 300 200 170 150 140 120 100 0.060 0.080 0.090 0.095 0.110 0.180 0.300 0.550 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS 0.47 1.0 2.2 ±20％ ±20％ ±20％ 500 400 250 0.048 0.108 0.184 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS 0.47 1.0 1.5 2.2 3.3 4.7 6.8 10 15 22 33 47 68 100 ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ 350 300 250 200 190 150 60 30 15 13 8.0 7.0 6.5 6.0 0.090 0.135 0.180 0.300 0.500 0.550 0.750 0.850 1.00 1.30 2.00 3.50 5.80 7.70 Parts number EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） C2012T1R0M C2012T1R5MD C2012T2R2MD C2012T3R3MD C2012T4R7MD RoHS RoHS RoHS RoHS RoHS 1.0 1.5 2.2 3.3 4.7 ±20％ ±20％ ±20％ ±20％ ±20％ 490 390 350 300 250 0.060 0.090 0.110 0.170 0.265 Parts number BR L1608T1R0M BR L1608T1R5M BR L1608T2R2M BR L1608T3R3M BR L1608T4R7M BR L1608T6R8M BR L1608T100M BR L1608T150M INDUCTORS Parts number BR C1608TR43M BR C1608TR50M BR C1608TR60M BR C1608TR72M BR C1608TR82M BR C1608T1R0M POWER INDUCTORS BR C1608TR20M BR C1608TR35M BR C1608TR45M BR C1608TR56M BR C1608TR77M BR C1608T1R0M BR C1608T1R5M BR C1608T2R2M Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 510 650 1.0 440 590 1.0 360 500 1.0 290 390 1.0 240 310 1.0 200 250 1.0 170 220 1.0 150 200 1.0 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,400 1,100 6.0 1,200 1,050 6.0 1,100 940 6.0 1,000 810 6.0 950 730 6.0 890 680 6.0 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,750 980 7.96 1,400 810 7.96 1,250 800 7.96 1,150 760 7.96 1,000 660 7.96 850 520 7.96 700 410 7.96 550 280 7.96 ●2012（0805）type Parts number BR L2012TR47M 6 BR L2012T1R0M 6 BR L2012T2R2MD6 Parts number BR L2012TR47M BR L2012T1R0M BR L2012T1R5M BR L2012T2R2M BR L2012T3R3M BR L2012T4R7M BR L2012T6R8M BR L2012T100M BR L2012T150M BR L2012T220M BR L2012T330M BR L2012T470M BR L2012T680M BR L2012T101M BR BR BR BR BR Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,500 1,900 6.0 1,050 1,230 6.0 680 950 6.0 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,100 1,050 7.96 850 850 7.96 700 750 7.96 600 550 7.96 490 440 7.96 340 400 7.96 290 350 7.96 270 330 2.52 220 300 2.52 190 270 2.52 150 220 2.52 125 160 2.52 100 110 2.52 85 85 0.796 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,500 1,400 1.0 1,200 1,100 1.0 1,100 1,000 1.0 800 870 1.0 700 600 1.0 ※）The saturation current value (Idc1) is the DC current value having inductance decrease down to 30%. (at 20℃) ※）The temperature rise current value (Idc2) is the DC current value having temperature increase by 40℃. (at 20℃) ※）The rated current value is following either Idc1 or Idc2, which is the lower one. i_wound_BR_e-E08R01.xls ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) . 68 21 for General Electronic Equipment ■PARTS NUMBER ●2016（0806）type Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS 1.0 1.5 2.2 3.3 4.7 6.8 10 15 22 33 47 68 100 ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 450 370 250 140 78 39 35 28 24 13 11 8 7 0.085 0.150 0.180 0.220 0.270 0.330 0.400 0.600 1.00 1.70 2.20 2.80 3.40 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS 1.0 1.5 2.2 3.3 4.7 ±20％ ±20％ ±20％ ±20％ ±20％ 130 100 80 70 60 0.090 0.110 0.130 0.220 0.330 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS 1.0 1.5 2.2 3.3 4.7 ±20％ ±20％ ±20％ ±20％ ±20％ 130 100 80 70 60 0.080 0.100 0.135 0.300 0.400 Parts number EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） BRHL2518T1R0M BRHL2518T1R5M BRHL2518T2R2M BRHL2518T3R3MD BRHL2518T4R7MD RoHS RoHS RoHS RoHS RoHS 1.0 1.5 2.2 3.3 4.7 ±20％ ±20％ ±20％ ±20％ ±20％ 400 350 300 200 150 0.055 0.085 0.115 0.165 0.245 Parts number EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 280 230 200 150 100 45 20 13 10 8 6.5 5.5 4.5 0.050 0.080 0.120 0.175 0.230 0.280 0.350 0.430 0.560 0.850 1.45 2.40 3.60 BR BR BR BR BR BR BR BR BR BR BR BR BR C2016T1R0M C2016T1R5M C2016T2R2M C2016T3R3M C2016T4R7M C2016T6R8M C2016T100[] C2016T150[] C2016T220[] C2016T330[] C2016T470[] C2016T680[] C2016T101[] Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,350 1,100 0.10 1,100 820 0.10 910 760 0.10 740 680 0.10 660 610 0.10 550 560 0.10 450 520 0.10 400 410 0.10 310 310 0.10 270 240 0.10 210 210 0.10 200 190 0.10 140 170 0.10 ●2518（1007）type Parts number BRFL2518T1R0M BRFL2518T1R5M BRFL2518T2R2M BRFL2518T3R3M BRFL2518T4R7M Parts number BR BR BR BR BR L2518T1R0M L2518T1R5M L2518T2R2M L2518T3R3M L2518T4R7M BR C2518T1R0M RoHS 1.0 BR C2518T1R5M RoHS 1.5 BR C2518T2R2M RoHS 2.2 BR C2518T3R3M RoHS 3.3 BR C2518T4R7M RoHS 4.7 BR C2518T6R8M RoHS 6.8 BR C2518T100[] RoHS 10 BR C2518T150[] RoHS 15 BR C2518T220[] RoHS 22 BR C2518T330[] RoHS 33 BR C2518T470[] RoHS 47 BR C2518T680[] RoHS 68 BR C2518T101[] RoHS 100 ・ [] Please specify the inductance tolerance code. (M or K) Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,200 1,200 1.0 1,100 1,000 1.0 850 950 1.0 700 700 1.0 650 650 1.0 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,600 1,000 7.96 1,200 920 7.96 1,000 850 7.96 800 580 7.96 700 470 7.96 POWER INDUCTORS Nominal inductance ［μH］ INDUCTORS EHS Parts number Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 2,000 1,400 1.0 1,700 1,100 1.0 1,500 1,000 1.0 1,200 800 1.0 1,100 750 1.0 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 2,550 1,650 1.0 2,100 1,300 1.0 1,800 1,000 1.0 1,450 860 1.0 1,250 750 1.0 1,050 680 1.0 890 610 1.0 760 550 1.0 640 490 1.0 560 390 1.0 410 300 1.0 340 230 1.0 300 190 1.0 ※）The saturation current value (Idc1) is the DC current value having inductance decrease down to 30%. (at 20℃) ※）The temperature rise current value (Idc2) is the DC current value having temperature increase by 40℃. (at 20℃) ※）The rated current value is following either Idc1 or Idc2, which is the lower one. i_wound_BR_e-E08R01.xls ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) . 21 69 for General Electronic Equipment ■PARTS NUMBER ●3225（1210）type Parts number BR L3225TR27M BR L3225TR36M BR L3225TR51M Parts number INDUCTORS POWER INDUCTORS EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS 0.27 0.36 0.51 ±20％ ±20％ ±20％ 390 350 270 0.022 0.025 0.029 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±20％） ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 220 170 150 140 120 90 70 20 13 9 7 6 5 0.043 0.045 0.065 0.120 0.180 0.270 0.350 0.570 0.690 0.840 1.00 1.40 2.50 BR L3225T1R0M RoHS 1.0 BR L3225T1R5M RoHS 1.5 BR L3225T2R2M RoHS 2.2 BR L3225T3R3M RoHS 3.3 BR L3225T4R7M RoHS 4.7 BR L3225T6R8M RoHS 6.8 BR L3225T100[] RoHS 10 BR L3225T150[] RoHS 15 BR L3225T220[] RoHS 22 BR L3225T330[] RoHS 33 BR L3225T470[] RoHS 47 BR L3225T680[] RoHS 68 BR L3225T101[] RoHS 100 ・ [] Please specify the inductance tolerance code. (M or K) Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 4,500 2,850 7.96 4,300 2,750 7.96 3,600 2,550 7.96 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 2,400 2,200 0.1 2,200 1,750 0.1 1,850 1,600 0.1 1,450 1,200 0.1 1,300 1,000 0.1 1,050 770 0.1 900 700 0.1 700 530 0.1 550 470 0.1 470 420 0.1 420 390 0.1 330 300 0.1 270 250 0.1 ※）The saturation current value (Idc1) is the DC current value having inductance decrease down to 30%. (at 20℃) ※）The temperature rise current value (Idc2) is the DC current value having temperature increase by 40℃. (at 20℃) ※）The rated current value is following either Idc1 or Idc2, which is the lower one. i_wound_BR_e-E08R01.xls ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) . 70 21 WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES） ■PACKAGING ①Minimum Quantity Standard Quantity [pcs] Paper Tape Embossed Tape － 3,000 － 3,000 － 3,000 － 2,000 － 2,000 － 2,000 － 2,000 － 3,000 － 3,000 － 2,000 Type BR C1608 BR L1608 BR L2012 BR C2012 BR C2016 BR C2518 BRHL2518 BR L2518 BRFL2518 BR L3225 ②Tape Material ●Embossed tape Top tape Sprocket hole Base tape Chip cavity Chip Filled Chip ③Taping dimensions ●Embossed Tape 8mm wide (0.315 inches wide) A B F 1.75±0.1 (0.069±0.004） 8.0±0.2 (0.315±0.008) φ1.5＋0.1/－0 (φ0.059＋0.004/-0) 3.5±0.05 (0.138±0.002) Sprocket hole 4.0±0.1 (0.157±0.004) 2.0±0.05 (0.079±0.002) ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_BR_pack_e-E05R01 Type BR L1608 BR C1608 BR L2012 BR C2012 BR C2016 BRFL2518 BR L2518 BRHL2518 BR C2518 BR L3225 Chip cavity A B 1.1±0.1 1.9±0.1 (0.043±0.004) (0.075±0.004) 1.1±0.1 1.9±0.1 (0.043±0.004) (0.075±0.004) 1.45±0.1 2.2±0.1 (0.057±0.004) (0.087±0.004) 1.45±0.1 2.37±0.1 (0.057±0.004) (0.093±0.004) 1.75±0.1 2.1±0.1 (0.069±0.004) (0.083±0.004) 2.3±0.1 2.8±0.1 (0.091±0.004) (0.110±0.004) 2.3±0.1 2.8±0.1 (0.091±0.004) (0.110±0.004) 2.1±0.1 2.8±0.1 (0.083±0.004) (0.110±0.004) 2.15±0.1 2.7±0.1 (0.085±0.004) (0.106±0.004) 2.8±0.1 3.5±0.1 (0.110±0.004) (0.138±0.004) Insertion pitch F 4.0±0.1 (0.157±0.004) 4.0±0.1 (0.157±0.004) 4.0±0.1 (0.157±0.004) 4.0±0.1 (0.157±0.004) 4.0±0.1 (0.157±0.004) 4.0±0.1 (0.157±0.004) 4.0±0.1 (0.157±0.004) 4.0±0.1 (0.157±0.004) 4.0±0.1 (0.157±0.004) 4.0±0.1 (0.157±0.004) Tape thickness T K 0.2±0.05 0.9 max (0.008±0.002) (0.035 max) 0.25±0.05 1.2 max (0.010±0.002) (0.047 max) 0.25±0.05 1.2 max (0.010±0.002) (0.047 max) 0.25±0.05 1.59 max (0.010±0.002) (0.063 max) 0.3±0.05 1.9 max (0.012±0.002) (0.075 max) 0.25±0.05 1.3 max (0.010±0.002) (0.051 max) 0.3±0.05 1.45 max (0.012±0.002) (0.057 max) 0.3±0.05 1.7 max (0.012±0.002) (0.067 max) 0.3±0.05 2.2 max (0.012±0.002) (0.087 max) 0.25±0.05 1.9 max (0.010±0.002) (0.075 max) Unit：mm（inch） ④Leader and Blank portion ⑤Reel size ⑥Top Tape Strength The top tape requires a peel-off force of 0.2 to 0.7N in the direction of the arrow as illustrated below. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_BR_pack_e-E05R01 WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES） ■RELIABILITY DATA 1. Operating Temperature Range Specified Value BR series Test Methods and Remarks Including self-generated heat －40～＋105℃ 2. Storage Temperature Range（after soldering） Specified Value BR series Test Methods and Remarks －40～＋85℃ Please refer the term of "7.Storage conditions" in Precautions. 3. Rated current Specified Value BR series Within the specified tolerance 4. Inductance Specified Value BR series Test Methods and Remarks Measuring equipment Measuring frequency Within the specified tolerance : LCR Meter （HP 4285A or equivalent） : Specified frequency 5. DC Resistance Specified Value BR series Test Methods and Remarks Measuring equipment Within the specified tolerance : DC ohmmeter （HIOKI 3227 or equivalent） 6. Self resonance frequency Specified Value BR series Test Methods and Remarks Measuring equipment Within the specified tolerance : Impedance analyzer/material analyzer （HP4291A or equivalent HP4191A, 4192A or equivalent） 7. Temperature characteristic Specified Value BR series Test Methods and Remarks Inductance change : Within ±15% Based on the inductance at 20℃ and Measured at the ambient of －40℃～＋85℃. 8. Resistance to the bendability Specified Value BR series Test Methods and Remarks The given sample is soldered on the board and then the back side of the board is pushed until it bends 2mm like the figure. Dimension of the board : 100×40×1.0mm (0.8mm thickness for 1608(0603) inductors) Material of the board : Glass epoxy-resin Thickness of soldering paste : 0.12mm No damage. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_BR_reli_e-E05R01 9. Body strength Specified Value BR series Test Methods and Remarks 2012～ Applied orce Duration 1608 size Applied force Duration No damage. 10N : 10sec. : 5N : 10sec. 10. Adhesion of terminal electrodes Specified Value BR series Test Methods and Remarks The given sample is soldered to the board and then it is kept for 5sec with 10N stress (5N for 1608(0603) inductors) like the figure. Not to removed from the board. 11. Resistance to vibration Inductance change : Within ±10% No significant abnormality in appearance. Specified Value BR series Test Methods and Remarks The given sample is soldered to the board and then it is tested depending on the conditions of the following table. Vibration Frequency 10～55Hz Total Amplitude 1.5mm (May not exceed acceleration 196m/s2) Sweeping Method 10Hz to 55Hz to 10Hz for 1min. X Time Y For 2 hours on each X, Y, and Z axis. Z Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48hrs. 12. Solderability Specified Value BR series Test Methods and Remarks Test Method and Remarks】 The given sample is dipped into the flux and then it is tested depending on the conditions of the following table. Flux : Methanol solution containing rosin 25%. Solder Temperature 245±5℃ Time 5±0.5 sec. At least 90% area of the electrodes is covered by new solder. 13. Resistance to soldering heat Inductance change : Within ±10% No significant abnormality in appearance. Specified Value BR series Test Methods and Remarks 3 times reflow having the temperature profile of 5sec of 260＋0/－5 ℃ and 40sec of more than 230℃. Test board thickness : 1.0mm Test board material : Glass epoxy-resin Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48hrs. 14. Thermal shock Specified Value Test Methods and Remarks BR series Inductance change : Within ±10% No significant abnormality in appearance. The given sample is soldered to the board and then its Inductance is measured after 100cycles of the following conditions. Conditions of 1 cycle Step Temperature (℃) Duration (min) 1 －40±3 30±3 2 Room temperature Within 3 3 ＋85±2 30±3 4 Room temperature Within 3 Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_BR_reli_e-E05R01 15. Damp heat Inductance change : Within ±10% No significant abnormality in appearance. Specified Value BR series Test Methods and Remarks The given sample is soldered to the board and then it is kept at the following conditions. Temperature 60±2℃ Humidity 90～95%RH Time 1000 hours. Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 16. Loading under damp heat Inductance change : Within ±10% No significant abnormality in appearance. Specified Value BR series Test Methods and Remarks The given sample is soldered to the board and then it is kept at the following conditions. Temperature 60±2℃ Humidity 90～95％RH Applied current Rated current Time 1000hours. Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 17. Low temperature life test Inductance change : Within ±10% No significant abnormality in appearance. Specified Value BR series Test Methods and Remarks The given sample is soldered to the board and then it is kept at the following conditions. Temperature －40±2℃ Duration 1000hours Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 18. High temperature life test Inductance change : Within ±10% No significant abnormality in appearance. Specified Value BR series Test Methods and Remarks The given sample is soldered to the board and then it is kept at the following conditions. Temperature 85±2℃ Duration 1000hours Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 19. Standard conditions Specified Value BR series Standard test condition : Unless otherwise specified, temperature is 20±15℃ and 65±20％of relative humidity. When there is any question concerning measurement result: In order to provide correlation data, the test shall be condition of 20±2℃ of temperature, 65±5% relative humidity. Inductance is in accordance with our measured value. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_BR_reli_e-E05R01 WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES） ■PRECAUTIONS 1. Circuit Design Precautions ◆Operating Ambient The products are premised on the usage for the general equipments like the office supply equipment, the telecommunications systems, the measuring equipment, the household equipment and so on. Please ask to TAIYO YUDEN's sales person in advance, if you need to apply them to the equipments or the systems which might have any influences for the human body, the property, like the traffic systems, the safety equipment, the aerospace systems, the nuclear control systems, the medical equipment and soon. 2. PCB Design Precautions Technical considerations ◆Land pattern design 1. Please refer to a recommended land pattern. ◆Land pattern design Surface Mounting 1. The conditions of the picking and placing should be checked in advance. 2. The products are only for reflow soldering. 3. Considerations for automatic placement Precautions Technical considerations ◆Adjustment of mounting machine 1. Excessive physical impact should not be imposed on the products for picking and placing onto the PC boards. 2. Mounting and soldering conditions should be checked in advance. ◆Adjustment of mounting machine The products might be broken if too much stress is given for the picking and placing. 4. Soldering Precautions ◆Reflow soldering 1. Please apply our recommended soldering conditions on the specification as much as possible. 2. The products are only for reflow soldering. 3. Please do not give any stress to a product until it returns in room temperature after reflow soldering. ◆Recommended conditions for using a soldering iron. （Excluding 1608 type） Touch a soldering iron to the land pattern not to the product directly. The temperature of a soldering iron is less than 350degC. The soldering is for 3 seconds or less. ◆Reflow soldering 1. The product might break or might make the tombstoning, if the soldering conditions are too far from our recommended conditions. Technical considerations 5. Cleaning Precautions Technical considerations ◆Cleaning conditions 1. Please don't wash by the ultra-sonic waves. ◆Cleaning conditions 1. Washing by the ultra-sonic waves might break the product. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_BR_prec_e-E06R01 6. Handling Precautions Technical considerations ◆Handling 1. Keep the product away from any magnets. ◆Cutting the PC boards 1. Please don't give any stress of the bending or the twisting for the cutting process of PC boards. 2. Please don't give any shock and stress to the products in transportation. ◆Mechanical considerations 1. Please don't give too much shock to the product. 2. Please don't give any shock and stress to the products in transportation. ◆The stress for picking and placing 1. Please don't give any shock into an exposed ferrite core. ◆Packing 1. Please don't pile the packing boxes up as much as possible. ◆Handling 1. There is a case that a characteristic varies with magnetic influence. ◆Cutting the PC boards 1. Please don't give the bending stress or the twisting stress to the products because they might break in such cases. ◆Mechanical considerations 1. The mechanical shock might break the products. 2. The products might break depending on the handling in transportation. ◆Pick-up pressure 1. The electrical characteristics of the products might be shifted by too much physical shock and stress. ◆Packing 1. The products and the tape might break, if the packing boxes are piled up. 7. Storage conditions Precautions Technical considerations ◆Storage 1. To maintain the solderability of terminal electrodes and to keep the packing material in good condition, temperature and humidity in the storage area should be controlled. ・ Recommended conditions Ambient temperature : 0～40℃ Humidity : Below 70% RH ・ The ambient temperature must be kept below 30℃. Even under ideal storage conditions, solderability of products electrodes may decrease as time passes. For this reason, product should be used within 6 months from the time of delivery. In case of storage over 6 months, solderability shall be checked before actual usage. ◆Storage 1. The ambient of high temperature or high humidity might accelerate to make the solderability and the tape worse. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_BR_prec_e-E06R01
