for General Electronic Equipment
WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES）
WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES）
REFLOW
■PARTS NUMBER
B
R
①
* Operating Temp.：-40～+105℃（Including self-generated heat）
△ L
②
2
5
1
③
T
④
2
R 2
⑤
M △ △ △
⑥
⑦
④Packaging
Code
T
Series name
Wire-Wound chip power inductor
⑤Nominal inductance
Code
（example）
R20
1R0
100
101
※R＝Decimal point
Characteristics
Low profile
High current
③Dimensions（L×W）
Code
Type（inch）
1608
2012
2016
2518
3225
1608（0603）
2012（0805）
2016（0806）
2518（1007）
3225（1210）
Packaging
Taping
Dimensions
（L×W）［mm］
1.6×0.8
2.0×1.25
2.0×1.6
2.5×1.8
3.2×2.5
⑥Inductance tolerance
Code
K
M
Nominal inductance［μH］
0.2
1.0
10
100
Inductance tolerance
±10％
±20％
⑦Internal code
■STANDARD EXTERNAL DIMENSIONS / STANDARD QUANTITY
Recommended Land Patterns
Surface Mounting
・Mounting and soldering conditions should be checked beforehand.
L
W
・Applicable soldering process to these products is reflow soldering
Type
A
1608
0.55
T
C
2012
0.60
2016
0.60
e
2518
0.60
B
A
A
3225
0.85
Type
BR L1608
BR C1608
BR L2012
BR C2012
BR C2016
BRFL2518
BR L2518
BRHL2518
BR C2518
BR L3225
POWER INDUCTORS
②Characteristics
Code
FL
△L
HL
△C
△＝Blank space
INDUCTORS
①Series name
Code
BR
8
only.
B
0.70
1.00
1.00
1.50
1.70
C
1.00
1.45
1.80
2.00
2.70
Unit：mm
Standard quantity［pcs］
Paper tape
Embossed tape
L
W
T
e
1.6±0.2
（0.063±0.008）
1.6±0.2
（0.063±0.008）
2.0±0.2
（0.079±0.008）
2.0±0.2
（0.079±0.008）
2.0±0.2
（0.079±0.008）
2.5±0.2
（0.098±0.008）
2.5±0.2
（0.098±0.008）
2.5±0.2
（0.098±0.008）
2.5±0.2
（0.098±0.008）
3.2±0.2
（0.126±0.008）
0.8±0.2
（0.031±0.008）
0.8±0.2
（0.031±0.008）
1.25±0.2
（0.049±0.008）
1.25±0.2
（0.049±0.008）
1.6±0.2
（0.063±0.008）
1.8±0.2
（0.071±0.008）
1.8±0.2
（0.071±0.008）
1.8±0.2
（0.071±0.008）
1.8±0.2
（0.071±0.008）
2.5±0.2
（0.098±0.008）
0.7 max
（0.028 max）
0.8±0.2
（0.031±0.008）
1.0 max
（0.040 max）
1.4 max
（0.056 max）
1.6±0.2
（0.063±0.008）
1.0 max
（0.040 max）
1.2 max
（0.048 max）
1.5 max
（0.060 max）
1.8±0.2
（0.071±0.008）
1.7 max
（0.068 max）
0.45±0.15
（0.016±0.006）
0.45±0.15
（0.016±0.006）
0.5±0.2
（0.020±0.008）
0.5±0.2
（0.020±0.008）
0.5±0.2
（0.020±0.008）
0.5±0.2
（0.020±0.008）
0.5±0.2
（0.020±0.008）
0.5±0.2
（0.020±0.008）
0.5±0.2
（0.020±0.008）
0.75±0.2
（0.03±0.008）
－
3000
－
3000
－
3000
－
2000
－
2000
－
3000
－
3000
－
2000
－
2000
－
2000
Unit：mm（inch）
i_wound_BR_e-E08R01.doc
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) .
21
67
for General Electronic Equipment
■PARTS NUMBER
●1608（0603）type
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
1.0
1.5
2.2
3.3
4.7
6.8
10
15
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
700
600
400
300
150
100
45
32
0.230
0.280
0.400
0.650
1.00
1.64
2.00
2.56
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
6
6
6
6
6
6
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
0.43
0.50
0.60
0.72
0.82
1.0
±20％
±20％
±20％
±20％
±20％
±20％
740
710
630
600
560
550
0.082
0.090
0.099
0.144
0.176
0.188
Parts number
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
0.20
0.35
0.45
0.56
0.77
1.0
1.5
2.2
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
400
300
200
170
150
140
120
100
0.060
0.080
0.090
0.095
0.110
0.180
0.300
0.550
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
RoHS
RoHS
RoHS
0.47
1.0
2.2
±20％
±20％
±20％
500
400
250
0.048
0.108
0.184
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
0.47
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
350
300
250
200
190
150
60
30
15
13
8.0
7.0
6.5
6.0
0.090
0.135
0.180
0.300
0.500
0.550
0.750
0.850
1.00
1.30
2.00
3.50
5.80
7.70
Parts number
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
C2012T1R0M
C2012T1R5MD
C2012T2R2MD
C2012T3R3MD
C2012T4R7MD
RoHS
RoHS
RoHS
RoHS
RoHS
1.0
1.5
2.2
3.3
4.7
±20％
±20％
±20％
±20％
±20％
490
390
350
300
250
0.060
0.090
0.110
0.170
0.265
Parts number
BR L1608T1R0M
BR L1608T1R5M
BR L1608T2R2M
BR L1608T3R3M
BR L1608T4R7M
BR L1608T6R8M
BR L1608T100M
BR L1608T150M
INDUCTORS
Parts number
BR C1608TR43M
BR C1608TR50M
BR C1608TR60M
BR C1608TR72M
BR C1608TR82M
BR C1608T1R0M
POWER INDUCTORS
BR C1608TR20M
BR C1608TR35M
BR C1608TR45M
BR C1608TR56M
BR C1608TR77M
BR C1608T1R0M
BR C1608T1R5M
BR C1608T2R2M
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
510
650
1.0
440
590
1.0
360
500
1.0
290
390
1.0
240
310
1.0
200
250
1.0
170
220
1.0
150
200
1.0
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
1,400
1,100
6.0
1,200
1,050
6.0
1,100
940
6.0
1,000
810
6.0
950
730
6.0
890
680
6.0
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
1,750
980
7.96
1,400
810
7.96
1,250
800
7.96
1,150
760
7.96
1,000
660
7.96
850
520
7.96
700
410
7.96
550
280
7.96
●2012（0805）type
Parts number
BR L2012TR47M 6
BR L2012T1R0M 6
BR L2012T2R2MD6
Parts number
BR L2012TR47M
BR L2012T1R0M
BR L2012T1R5M
BR L2012T2R2M
BR L2012T3R3M
BR L2012T4R7M
BR L2012T6R8M
BR L2012T100M
BR L2012T150M
BR L2012T220M
BR L2012T330M
BR L2012T470M
BR L2012T680M
BR L2012T101M
BR
BR
BR
BR
BR
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
1,500
1,900
6.0
1,050
1,230
6.0
680
950
6.0
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
1,100
1,050
7.96
850
850
7.96
700
750
7.96
600
550
7.96
490
440
7.96
340
400
7.96
290
350
7.96
270
330
2.52
220
300
2.52
190
270
2.52
150
220
2.52
125
160
2.52
100
110
2.52
85
85
0.796
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
1,500
1,400
1.0
1,200
1,100
1.0
1,100
1,000
1.0
800
870
1.0
700
600
1.0
※）The saturation current value (Idc1) is the DC current value having inductance decrease down to 30%. (at 20℃)
※）The temperature rise current value (Idc2) is the DC current value having temperature increase by 40℃. (at 20℃)
※）The rated current value is following either Idc1 or Idc2, which is the lower one.
i_wound_BR_e-E08R01.xls
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) .
68
21
for General Electronic Equipment
■PARTS NUMBER
●2016（0806）type
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
±20％
±20％
±20％
±20％
±20％
±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
450
370
250
140
78
39
35
28
24
13
11
8
7
0.085
0.150
0.180
0.220
0.270
0.330
0.400
0.600
1.00
1.70
2.20
2.80
3.40
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
RoHS
RoHS
RoHS
RoHS
RoHS
1.0
1.5
2.2
3.3
4.7
±20％
±20％
±20％
±20％
±20％
130
100
80
70
60
0.090
0.110
0.130
0.220
0.330
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
RoHS
RoHS
RoHS
RoHS
RoHS
1.0
1.5
2.2
3.3
4.7
±20％
±20％
±20％
±20％
±20％
130
100
80
70
60
0.080
0.100
0.135
0.300
0.400
Parts number
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
BRHL2518T1R0M
BRHL2518T1R5M
BRHL2518T2R2M
BRHL2518T3R3MD
BRHL2518T4R7MD
RoHS
RoHS
RoHS
RoHS
RoHS
1.0
1.5
2.2
3.3
4.7
±20％
±20％
±20％
±20％
±20％
400
350
300
200
150
0.055
0.085
0.115
0.165
0.245
Parts number
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
±20％
±20％
±20％
±20％
±20％
±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
280
230
200
150
100
45
20
13
10
8
6.5
5.5
4.5
0.050
0.080
0.120
0.175
0.230
0.280
0.350
0.430
0.560
0.850
1.45
2.40
3.60
BR
BR
BR
BR
BR
BR
BR
BR
BR
BR
BR
BR
BR
C2016T1R0M
C2016T1R5M
C2016T2R2M
C2016T3R3M
C2016T4R7M
C2016T6R8M
C2016T100[]
C2016T150[]
C2016T220[]
C2016T330[]
C2016T470[]
C2016T680[]
C2016T101[]
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
1,350
1,100
0.10
1,100
820
0.10
910
760
0.10
740
680
0.10
660
610
0.10
550
560
0.10
450
520
0.10
400
410
0.10
310
310
0.10
270
240
0.10
210
210
0.10
200
190
0.10
140
170
0.10
●2518（1007）type
Parts number
BRFL2518T1R0M
BRFL2518T1R5M
BRFL2518T2R2M
BRFL2518T3R3M
BRFL2518T4R7M
Parts number
BR
BR
BR
BR
BR
L2518T1R0M
L2518T1R5M
L2518T2R2M
L2518T3R3M
L2518T4R7M
BR C2518T1R0M
RoHS
1.0
BR C2518T1R5M
RoHS
1.5
BR C2518T2R2M
RoHS
2.2
BR C2518T3R3M
RoHS
3.3
BR C2518T4R7M
RoHS
4.7
BR C2518T6R8M
RoHS
6.8
BR C2518T100[]
RoHS
10
BR C2518T150[]
RoHS
15
BR C2518T220[]
RoHS
22
BR C2518T330[]
RoHS
33
BR C2518T470[]
RoHS
47
BR C2518T680[]
RoHS
68
BR C2518T101[]
RoHS
100
・ [] Please specify the inductance tolerance code. (M or K)
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
1,200
1,200
1.0
1,100
1,000
1.0
850
950
1.0
700
700
1.0
650
650
1.0
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
1,600
1,000
7.96
1,200
920
7.96
1,000
850
7.96
800
580
7.96
700
470
7.96
POWER INDUCTORS
Nominal inductance
［μH］
INDUCTORS
EHS
Parts number
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
2,000
1,400
1.0
1,700
1,100
1.0
1,500
1,000
1.0
1,200
800
1.0
1,100
750
1.0
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
2,550
1,650
1.0
2,100
1,300
1.0
1,800
1,000
1.0
1,450
860
1.0
1,250
750
1.0
1,050
680
1.0
890
610
1.0
760
550
1.0
640
490
1.0
560
390
1.0
410
300
1.0
340
230
1.0
300
190
1.0
※）The saturation current value (Idc1) is the DC current value having inductance decrease down to 30%. (at 20℃)
※）The temperature rise current value (Idc2) is the DC current value having temperature increase by 40℃. (at 20℃)
※）The rated current value is following either Idc1 or Idc2, which is the lower one.
i_wound_BR_e-E08R01.xls
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) .
21
69
for General Electronic Equipment
■PARTS NUMBER
●3225（1210）type
Parts number
BR L3225TR27M
BR L3225TR36M
BR L3225TR51M
Parts number
INDUCTORS
POWER INDUCTORS
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±30％）
RoHS
RoHS
RoHS
0.27
0.36
0.51
±20％
±20％
±20％
390
350
270
0.022
0.025
0.029
EHS
Nominal inductance
［μH］
Inductance tolerance
Self-resonant
frequency
［MHｚ］（min.）
DC Resistance
［Ω］（±20％）
±20％
±20％
±20％
±20％
±20％
±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
±10％，±20％
220
170
150
140
120
90
70
20
13
9
7
6
5
0.043
0.045
0.065
0.120
0.180
0.270
0.350
0.570
0.690
0.840
1.00
1.40
2.50
BR L3225T1R0M
RoHS
1.0
BR L3225T1R5M
RoHS
1.5
BR L3225T2R2M
RoHS
2.2
BR L3225T3R3M
RoHS
3.3
BR L3225T4R7M
RoHS
4.7
BR L3225T6R8M
RoHS
6.8
BR L3225T100[]
RoHS
10
BR L3225T150[]
RoHS
15
BR L3225T220[]
RoHS
22
BR L3225T330[]
RoHS
33
BR L3225T470[]
RoHS
47
BR L3225T680[]
RoHS
68
BR L3225T101[]
RoHS
100
・ [] Please specify the inductance tolerance code. (M or K)
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
4,500
2,850
7.96
4,300
2,750
7.96
3,600
2,550
7.96
Rated current ※） ［ｍA］
Measuring
Saturation current
Temperature rise current frequency［MHz］
Idc2
Idc1
2,400
2,200
0.1
2,200
1,750
0.1
1,850
1,600
0.1
1,450
1,200
0.1
1,300
1,000
0.1
1,050
770
0.1
900
700
0.1
700
530
0.1
550
470
0.1
470
420
0.1
420
390
0.1
330
300
0.1
270
250
0.1
※）The saturation current value (Idc1) is the DC current value having inductance decrease down to 30%. (at 20℃)
※）The temperature rise current value (Idc2) is the DC current value having temperature increase by 40℃. (at 20℃)
※）The rated current value is following either Idc1 or Idc2, which is the lower one.
i_wound_BR_e-E08R01.xls
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) .
70
21
WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES）
■PACKAGING
①Minimum Quantity
Standard Quantity [pcs]
Paper Tape
Embossed Tape
－
3,000
－
3,000
－
3,000
－
2,000
－
2,000
－
2,000
－
2,000
－
3,000
－
3,000
－
2,000
Type
BR C1608
BR L1608
BR L2012
BR C2012
BR C2016
BR C2518
BRHL2518
BR L2518
BRFL2518
BR L3225
②Tape Material
●Embossed tape
Top tape
Sprocket hole
Base tape
Chip cavity
Chip Filled
Chip
③Taping dimensions
●Embossed Tape 8mm wide (0.315 inches wide)
A
B
F
1.75±0.1
(0.069±0.004）
8.0±0.2
(0.315±0.008)
φ1.5＋0.1/－0
(φ0.059＋0.004/-0)
3.5±0.05
(0.138±0.002)
Sprocket hole
4.0±0.1
(0.157±0.004)
2.0±0.05
(0.079±0.002)
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_wound_BR_pack_e-E05R01
Type
BR L1608
BR C1608
BR L2012
BR C2012
BR C2016
BRFL2518
BR L2518
BRHL2518
BR C2518
BR L3225
Chip cavity
A
B
1.1±0.1
1.9±0.1
(0.043±0.004)
(0.075±0.004)
1.1±0.1
1.9±0.1
(0.043±0.004)
(0.075±0.004)
1.45±0.1
2.2±0.1
(0.057±0.004)
(0.087±0.004)
1.45±0.1
2.37±0.1
(0.057±0.004)
(0.093±0.004)
1.75±0.1
2.1±0.1
(0.069±0.004)
(0.083±0.004)
2.3±0.1
2.8±0.1
(0.091±0.004)
(0.110±0.004)
2.3±0.1
2.8±0.1
(0.091±0.004)
(0.110±0.004)
2.1±0.1
2.8±0.1
(0.083±0.004)
(0.110±0.004)
2.15±0.1
2.7±0.1
(0.085±0.004)
(0.106±0.004)
2.8±0.1
3.5±0.1
(0.110±0.004)
(0.138±0.004)
Insertion pitch
F
4.0±0.1
(0.157±0.004)
4.0±0.1
(0.157±0.004)
4.0±0.1
(0.157±0.004)
4.0±0.1
(0.157±0.004)
4.0±0.1
(0.157±0.004)
4.0±0.1
(0.157±0.004)
4.0±0.1
(0.157±0.004)
4.0±0.1
(0.157±0.004)
4.0±0.1
(0.157±0.004)
4.0±0.1
(0.157±0.004)
Tape thickness
T
K
0.2±0.05
0.9 max
(0.008±0.002)
(0.035 max)
0.25±0.05
1.2 max
(0.010±0.002)
(0.047 max)
0.25±0.05
1.2 max
(0.010±0.002)
(0.047 max)
0.25±0.05
1.59 max
(0.010±0.002)
(0.063 max)
0.3±0.05
1.9 max
(0.012±0.002)
(0.075 max)
0.25±0.05
1.3 max
(0.010±0.002)
(0.051 max)
0.3±0.05
1.45 max
(0.012±0.002)
(0.057 max)
0.3±0.05
1.7 max
(0.012±0.002)
(0.067 max)
0.3±0.05
2.2 max
(0.012±0.002)
(0.087 max)
0.25±0.05
1.9 max
(0.010±0.002)
(0.075 max)
Unit：mm（inch）
④Leader and Blank portion
⑤Reel size
⑥Top Tape Strength
The top tape requires a peel-off force of 0.2 to 0.7N in the direction of the arrow as illustrated below.
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_wound_BR_pack_e-E05R01
WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES）
■RELIABILITY DATA
1. Operating Temperature Range
Specified Value
BR series
Test Methods and
Remarks
Including self-generated heat
－40～＋105℃
2. Storage Temperature Range（after soldering）
Specified Value
BR series
Test Methods and
Remarks
－40～＋85℃
Please refer the term of "7.Storage conditions" in Precautions.
3. Rated current
Specified Value
BR series
Within the specified tolerance
4. Inductance
Specified Value
BR series
Test Methods and
Remarks
Measuring equipment
Measuring frequency
Within the specified tolerance
: LCR Meter （HP 4285A or equivalent）
: Specified frequency
5. DC Resistance
Specified Value
BR series
Test Methods and
Remarks
Measuring equipment
Within the specified tolerance
: DC ohmmeter （HIOKI 3227 or equivalent）
6. Self resonance frequency
Specified Value
BR series
Test Methods and
Remarks
Measuring equipment
Within the specified tolerance
: Impedance analyzer/material analyzer
（HP4291A or equivalent HP4191A, 4192A or equivalent）
7. Temperature characteristic
Specified Value
BR series
Test Methods and
Remarks
Inductance change : Within ±15%
Based on the inductance at 20℃ and Measured at the ambient of －40℃～＋85℃.
8. Resistance to the bendability
Specified Value
BR series
Test Methods and
Remarks
The given sample is soldered on the board and then the back side of the board is pushed until it bends 2mm like the figure.
Dimension of the board
: 100×40×1.0mm (0.8mm thickness for 1608(0603) inductors)
Material of the board
: Glass epoxy-resin
Thickness of soldering paste
: 0.12mm
No damage.
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_wound_BR_reli_e-E05R01
9. Body strength
Specified Value
BR series
Test Methods and
Remarks
2012～
Applied orce
Duration
1608 size
Applied force
Duration
No damage.
10N
: 10sec.
: 5N
: 10sec.
10. Adhesion of terminal electrodes
Specified Value
BR series
Test Methods and
Remarks
The given sample is soldered to the board and then it is kept for 5sec with 10N stress (5N for 1608(0603) inductors) like the figure.
Not to removed from the board.
11. Resistance to vibration
Inductance change : Within ±10%
No significant abnormality in appearance.
Specified Value
BR series
Test Methods and
Remarks
The given sample is soldered to the board and then it is tested depending on the conditions of the following table.
Vibration Frequency
10～55Hz
Total Amplitude
1.5mm (May not exceed acceleration 196m/s2)
Sweeping Method
10Hz to 55Hz to 10Hz for 1min.
X
Time
Y
For 2 hours on each X, Y, and Z axis.
Z
Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48hrs.
12. Solderability
Specified Value
BR series
Test Methods and
Remarks
Test Method and Remarks】
The given sample is dipped into the flux and then it is tested depending on the conditions of the following table.
Flux : Methanol solution containing rosin 25%.
Solder Temperature
245±5℃
Time
5±0.5 sec.
At least 90% area of the electrodes is covered by new solder.
13. Resistance to soldering heat
Inductance change : Within ±10%
No significant abnormality in appearance.
Specified Value
BR series
Test Methods and
Remarks
3 times reflow having the temperature profile of 5sec of 260＋0/－5 ℃ and 40sec of more than 230℃.
Test board thickness
: 1.0mm
Test board material
: Glass epoxy-resin
Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48hrs.
14. Thermal shock
Specified Value
Test Methods and
Remarks
BR series
Inductance change : Within ±10%
No significant abnormality in appearance.
The given sample is soldered to the board and then its Inductance is measured after 100cycles of the following conditions.
Conditions of 1 cycle
Step
Temperature (℃)
Duration (min)
1
－40±3
30±3
2
Room temperature
Within 3
3
＋85±2
30±3
4
Room temperature
Within 3
Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs.
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_wound_BR_reli_e-E05R01
15. Damp heat
Inductance change : Within ±10%
No significant abnormality in appearance.
Specified Value
BR series
Test Methods and
Remarks
The given sample is soldered to the board and then it is kept at the following conditions.
Temperature
60±2℃
Humidity
90～95%RH
Time
1000 hours.
Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs.
16. Loading under damp heat
Inductance change : Within ±10%
No significant abnormality in appearance.
Specified Value
BR series
Test Methods and
Remarks
The given sample is soldered to the board and then it is kept at the following conditions.
Temperature
60±2℃
Humidity
90～95％RH
Applied current
Rated current
Time
1000hours.
Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs.
17. Low temperature life test
Inductance change : Within ±10%
No significant abnormality in appearance.
Specified Value
BR series
Test Methods and
Remarks
The given sample is soldered to the board and then it is kept at the following conditions.
Temperature
－40±2℃
Duration
1000hours
Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs.
18. High temperature life test
Inductance change : Within ±10%
No significant abnormality in appearance.
Specified Value
BR series
Test Methods and
Remarks
The given sample is soldered to the board and then it is kept at the following conditions.
Temperature
85±2℃
Duration
1000hours
Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs.
19. Standard conditions
Specified Value
BR series
Standard test condition :
Unless otherwise specified, temperature is 20±15℃ and 65±20％of relative humidity.
When there is any question concerning measurement result: In order to provide
correlation data, the test shall be condition of 20±2℃ of temperature, 65±5% relative
humidity.
Inductance is in accordance with our measured value.
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_wound_BR_reli_e-E05R01
WIRE-WOUND CHIP POWER INDUCTORS（BR SERIES）
■PRECAUTIONS
1. Circuit Design
Precautions
◆Operating Ambient
The products are premised on the usage for the general equipments like the office supply equipment, the telecommunications systems, the
measuring equipment, the household equipment and so on.
Please ask to TAIYO YUDEN's sales person in advance, if you need to apply them to the equipments or the systems which might have any
influences for the human body, the property, like the traffic systems, the safety equipment, the aerospace systems, the nuclear control
systems, the medical equipment and soon.
2. PCB Design
Precautions
Technical
considerations
◆Land pattern design
1. Please refer to a recommended land pattern.
◆Land pattern design
Surface Mounting
1. The conditions of the picking and placing should be checked in advance.
2. The products are only for reflow soldering.
3. Considerations for automatic placement
Precautions
Technical
considerations
◆Adjustment of mounting machine
1. Excessive physical impact should not be imposed on the products for picking and placing onto the PC boards.
2. Mounting and soldering conditions should be checked in advance.
◆Adjustment of mounting machine
The products might be broken if too much stress is given for the picking and placing.
4. Soldering
Precautions
◆Reflow soldering
1. Please apply our recommended soldering conditions on the specification as much as possible.
2. The products are only for reflow soldering.
3. Please do not give any stress to a product until it returns in room temperature after reflow soldering.
◆Recommended conditions for using a soldering iron. （Excluding 1608 type）
Touch a soldering iron to the land pattern not to the product directly.
The temperature of a soldering iron is less than 350degC.
The soldering is for 3 seconds or less.
◆Reflow soldering
1. The product might break or might make the tombstoning, if the soldering conditions are too far from our recommended conditions.
Technical
considerations
5. Cleaning
Precautions
Technical
considerations
◆Cleaning conditions
1. Please don't wash by the ultra-sonic waves.
◆Cleaning conditions
1. Washing by the ultra-sonic waves might break the product.
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_wound_BR_prec_e-E06R01
6. Handling
Precautions
Technical
considerations
◆Handling
1. Keep the product away from any magnets.
◆Cutting the PC boards
1. Please don't give any stress of the bending or the twisting for the cutting process of PC boards.
2. Please don't give any shock and stress to the products in transportation.
◆Mechanical considerations
1. Please don't give too much shock to the product.
2. Please don't give any shock and stress to the products in transportation.
◆The stress for picking and placing
1. Please don't give any shock into an exposed ferrite core.
◆Packing
1. Please don't pile the packing boxes up as much as possible.
◆Handling
1. There is a case that a characteristic varies with magnetic influence.
◆Cutting the PC boards
1. Please don't give the bending stress or the twisting stress to the products because they might break in such cases.
◆Mechanical considerations
1. The mechanical shock might break the products.
2. The products might break depending on the handling in transportation.
◆Pick-up pressure
1. The electrical characteristics of the products might be shifted by too much physical shock and stress.
◆Packing
1. The products and the tape might break, if the packing boxes are piled up.
7. Storage conditions
Precautions
Technical
considerations
◆Storage
1. To maintain the solderability of terminal electrodes and to keep the packing material in good condition, temperature and humidity in the
storage area should be controlled.
・ Recommended conditions
Ambient temperature : 0～40℃
Humidity : Below 70% RH
・ The ambient temperature must be kept below 30℃. Even under ideal storage conditions, solderability of products electrodes may
decrease as time passes.
For this reason, product should be used within 6 months from the time of delivery.
In case of storage over 6 months, solderability shall be checked before actual usage.
◆Storage
1. The ambient of high temperature or high humidity might accelerate to make the solderability and the tape worse.
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_wound_BR_prec_e-E06R01
工商网监
湘ICP备2023018690号
