CBC3225T220KR

Notice for TAIYO YUDEN Products [ For General Electronic Equipment ] Please read this notice before using the TAIYO YUDEN products. REMINDERS ■ Product information in this catalog is as of October 2018. All of the contents specified herein are subject to change without notice due to technical improvements, etc. Therefore, please check for the latest information carefully before practical application or use of our products. Please note that TAIYO YUDEN shall not be in any way responsible for any damages and defects in products or equipment incorporating our products, which are caused under the conditions other than those specified in this catalog or individual product specification sheets. ■ Please contact TAIYO YUDEN for further details of product specifications as the individual product specification sheets are available. ■ Please conduct validation and verification of our products in actual condition of mounting and operating environment before using our products. ■ The products listed in this catalog are intended for use in general electronic equipment (e.g., AV equipment, OA equipment, home electric appliances, office equipment, information and communication equipment including, without limitation, mobile phone, and PC) and medical equipment classified as Class I or II by IMDRF. Please be sure to contact TAIYO YUDEN for further information before using the products for any equipment which may directly cause loss of human life or bodily injury (e.g., transportation equipment including, without limitation, automotive powertrain control system, train control system, and ship control system, traffic signal equipment, disaster prevention equipment, medical equipment classified as Class III by IMDRF, highly public information network equipment including, without limitation, telephone exchange, and base station). Please do not incorporate our products into any equipment requiring high levels of safety and/or reliability (e.g., aerospace equipment, aviation equipment*, medical equipment classified as Class IV by IMDRF, nuclear control equipment, undersea equipment, military equipment). *Note: There is a possibility that our products can be used only for aviation equipment that does not directly affect the safe operation of aircraft (e.g., in-flight entertainment, cabin light, electric seat, cooking equipment) if such use meets requirements specified separately by TAIYO YUDEN. Please be sure to contact TAIYO YUDEN for further information before using our products for such aviation equipment. When our products are used even for high safety and/or reliability-required devices or circuits of general electronic equipment, it is strongly recommended to perform a thorough safety evaluation prior to use of our products and to install a protection circuit as necessary. Please note that unless you obtain prior written consent of TAIYO YUDEN, TAIYO YUDEN shall not be in any way responsible for any damages incurred by you or third parties arising from use of the products listed in this catalog for any equipment requiring inquiry to TAIYO YUDEN or prohibited for use by TAIYO YUDEN as described above. ■ Information contained in this catalog is intended to convey examples of typical performances and/or applications of our products and is not intended to make any warranty with respect to the intellectual property rights or any other related rights of TAIYO YUDEN or any third parties nor grant any license under such rights. ■ Please note that the scope of warranty for our products is limited to the delivered our products themselves and TAIYO YUDEN shall not be in any way responsible for any damages resulting from a fault or defect in our products. Notwithstanding the foregoing, if there is a written agreement (e.g., supply and purchase agreement, quality assurance agreement) signed by TAIYO YUDEN and your company, TAIYO YUDEN will warrant our products in accordance with such agreement. ■ The contents of this catalog are applicable to our products which are purchased from our sales offices or authorized distributors (hereinafter“TAIYO YUDEN’ s official sales channel”). Please note that the contents of this catalog are not applicable to our products purchased from any seller other than TAIYO YUDEN’ s official sales channel. ■ Caution for Export Some of our products listed in this catalog may require specific procedures for export according to“U.S. Export Administration Regulations” ,“Foreign Exchange and Foreign Trade Control Law”of Japan, and other applicable regulations. Should you have any questions on this matter, please contact our sales staff. 19 WIRE-WOUND CHIP POWER INDUCTORS(CB SERIES) WIRE-WOUND CHIP POWER INDUCTORS（CB SERIES） REFLOW REFLOW ■PARTS NUMBER C B ① * Operating Temp.：-40～+105℃（Including self-generated heat） △ △ ② 2 0 1 ③ ①Series name Code CB 2 T ④ 1 0 0 ⑤ M △ △ △ △ ⑥ ⑦ ⑧ ④Packaging Code T Series name Wound chip power inductor Packaging Taping ⑤Nominal inductance Code （example） 1R0 100 101 ※R＝Decimal point Characteristics Standard High current Low profile Low loss Nominal inductance［μH］ ／ POWER INDUCTORS INDUCTORS ②Characteristics Code △△ △C △L MF △＝Blank space 1.0 10 100 ③Dimensions（L×W） Code Type（inch） 1608 2012 2016 2518 3225 1608（0603） 2012（0805） 2016（0806） 2518（1007） 3225（1210） ⑥Inductance tolerance Code K M Dimensions （L×W）［mm］ 1.6×0.8 2.0×1.25 2.0×1.6 2.5×1.8 3.2×2.5 Inductance tolerance ±10％ ±20％ ⑦Special code Code △ R Special code Standard Low Rdc type ⑧Internal code ■STANDARD EXTERNAL DIMENSIONS / STANDARD QUANTITY Recommended Land Patterns Surface Mounting ・Mounting and soldering conditions should be checked beforehand. W ・Applicable soldering process to these products is reflow soldering L Type A T MF1608 0.55 C 2012 0.60 e 2016 0.60 2518 0.60 3225 0.85 A B A Type CBMF1608 CB L2012 CB 2012 CB C2012 CB 2016 CB C2016 CB 2518 CB C2518 CB C3225 only. B 0.7 1.0 1.0 1.5 1.7 C 1.0 1.45 1.8 2.0 2.7 Unit：mm Standard quantity［pcs］ Paper tape Embossed tape L W T e 1.6±0.2 （0.063±0.008） 2.0±0.2 （0.079±0.008） 2.0±0.2 （0.079±0.008） 2.0±0.2 （0.079±0.008） 2.5±0.2 （0.098±0.008） 3.2±0.2 （0.126±0.008） 0.8±0.2 （0.031±0.008） 1.25±0.2 （0.049±0.008） 1.25±0.2 （0.049±0.008） 1.6±0.2 （0.063±0.008） 1.8±0.2 （0.071±0.008） 2.5±0.2 （0.098±0.008） 0.8±0.2 （0.031±0.008） 0.9±0.1 （0.035±0.004） 1.25±0.2 （0.049±0.008） 1.6±0.2 （0.063±0.008） 1.8±0.2 （0.071±0.008） 2.5±0.2 （0.098±0.008） 0.45±0.15 （0.016±0.006） 0.5±0.2 （0.020±0.008） 0.5±0.2 （0.020±0.008） 0.5±0.2 （0.020±0.008） 0.5±0.2 （0.020±0.008） 0.6±0.3 （0.024±0.012） － 3000 4000 － － 3000 － 2000 － 2000 － 1000 Unit：mm（inch） i_wound_CB_e-E05R01 ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) . 19 83 ■PARTS NUMBER ●1608（0603）type Parts number CBMF1608T1R0M CBMF1608T2R2M CBMF1608T3R3M CBMF1608T4R7M CBMF1608T100[] CBMF1608T220[] CBMF1608T470[] EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS RoHS 1.0 2.2 3.3 4.7 10 22 47 ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 100 80 60 45 32 16 11 0.09 0.17 0.22 0.24 0.36 1.0 2.5 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS 1.0 2.2 3.3 4.7 6.8 10 10 15 22 47 68 100 ±20％ ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 100 80 55 45 38 32 32 28 16 11 10 8 0.15 0.23 0.30 0.40 0.47 0.70 0.50 1.3 1.7 3.7 6.0 7.0 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS 1.0 2.2 4.7 10 22 47 ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 100 70 45 40 16 11 0.19 0.33 0.50 1.2 3.7 5.8 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS 1.0 2.2 4.7 10 22 47 ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ 100 80 45 32 23 11 0.15 0.39 0.66 1.0 2.1 4.2 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 100 80 70 55 45 38 32 28 16 14 11 10 8 0.09 0.11 0.13 0.20 0.25 0.35 0.50 0.70 1.0 1.7 2.4 3.0 4.5 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 290 770 7.96 190 560 7.96 170 500 7.96 145 470 7.96 115 380 2.52 70 230 2.52 50 140 2.52 ●2012（0805）type Parts number ／ POWER INDUCTORS INDUCTORS CB CB CB CB CB CB CB CB CB CB CB CB 2012T1R0M 2012T2R2M 2012T3R3M 2012T4R7M 2012T6R8M 2012T100[] 2012T100[]R 2012T150[] 2012T220[] 2012T470[] 2012T680[] 2012T101[] Parts number CB CB CB CB CB CB C2012T1R0M C2012T2R2M C2012T4R7M C2012T100[] C2012T220[] C2012T470[] Parts number CB CB CB CB CB CB L2012T1R0M L2012T2R2M L2012T4R7M L2012T100M L2012T220M L2012T470M Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 500 900 7.96 410 770 7.96 330 650 7.96 300 580 7.96 250 540 7.96 190 440 2.52 200 520 2.52 170 320 2.52 135 280 2.52 90 190 2.52 70 140 2.52 60 130 0.796 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 700 840 7.96 530 640 7.96 360 520 7.96 240 340 2.52 170 190 2.52 120 150 2.52 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 620 950 0.1 440 590 0.1 275 490 0.1 205 370 0.1 150 250 0.1 100 140 0.1 ●2016（0806）type Parts number CB CB CB CB CB CB CB CB CB CB CB CB CB ・ [] 2016T1R0M RoHS 1.0 2016T1R5M RoHS 1.5 2016T2R2M RoHS 2.2 2016T3R3M RoHS 3.3 2016T4R7M RoHS 4.7 2016T6R8M RoHS 6.8 2016T100[] RoHS 10 2016T150[] RoHS 15 2016T220[] RoHS 22 2016T330[] RoHS 33 2016T470[] RoHS 47 2016T680[] RoHS 68 2016T101[] RoHS 100 Please specify the Inductance tolerance code（Ｋor Ｍ） Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 600 1,100 7.96 550 1,000 7.96 510 1,000 7.96 400 800 7.96 340 740 7.96 300 600 7.96 250 520 2.52 210 440 2.52 165 370 2.52 130 270 2.52 110 240 2.52 90 210 2.52 70 170 0.796 ※）The saturation current value（Idc1） is the DC current value having inductance decrease down to 30%.（ at 20℃） ※）The temperature rise current value（Idc2） is the DC current value having temperature increase by 40℃.（ at 20℃） ※）The rated current value is following either Idc1 or Idc2, which is the lower one. i_wound_CB_e-E05R01 ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) . 84 19 ■PARTS NUMBER Parts number CB CB CB CB CB CB CB CB CB CB CB CB CB C2016T1R0M C2016T1R5M C2016T2R2M C2016T3R3M C2016T4R7M C2016T6R8M C2016T100[] C2016T150[] C2016T220[] C2016T330[] C2016T470[] C2016T680[] C2016T101[] EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS 1.0 1.5 2.2 3.3 4.7 6.8 10 15 22 33 47 68 100 ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 100 80 70 55 45 38 32 28 16 14 11 10 8 0.10 0.15 0.20 0.27 0.37 0.59 0.82 1.2 1.8 2.8 4.3 7.0 8.0 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS RoHS 1.0 1.5 2.2 3.3 4.7 4.7 6.8 10 15 22 33 47 68 100 150 220 330 470 680 1000 ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 100 80 68 54 46 46 38 30 23 19 15 12 9.5 9.0 7.0 5.5 4.5 3.5 3.0 2.4 0.06 0.07 0.09 0.11 0.10 0.13 0.15 0.25 0.32 0.50 0.70 0.95 1.5 2.1 3.2 4.5 7.0 10 17 24 EHS Nominal inductance ［μH］ Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 100 80 68 54 41 38 30 23 19 15 12 9.5 9.0 7.0 5.5 4.5 3.5 3.0 0.08 0.11 0.13 0.16 0.20 0.30 0.36 0.65 0.77 1.5 1.9 2.8 3.7 6.1 8.4 12.3 22 28 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,100 1,100 7.96 1,000 1,000 7.96 750 720 7.96 600 610 7.96 550 530 7.96 450 450 7.96 380 350 2.52 300 300 2.52 250 240 2.52 220 220 2.52 150 150 2.52 130 130 2.52 110 110 0.796 ●2518（1007）type CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB CB 2518T1R0M 2518T1R5M 2518T2R2M 2518T3R3M 2518T4R7MR 2518T4R7M 2518T6R8M 2518T100[] 2518T150[] 2518T220[] 2518T330[] 2518T470[] 2518T680[] 2518T101[] 2518T151[] 2518T221[] 2518T331[] 2518T471[] 2518T681[] 2518T102[] Parts number CB C2518T1R0M RoHS 1.0 CB C2518T1R5M RoHS 1.5 CB C2518T2R2M RoHS 2.2 CB C2518T3R3M RoHS 3.3 CB C2518T4R7M RoHS 4.7 CB C2518T6R8M RoHS 6.8 CB C2518T100[] RoHS 10 CB C2518T150[] RoHS 15 CB C2518T220[] RoHS 22 CB C2518T330[] RoHS 33 CB C2518T470[] RoHS 47 CB C2518T680[] RoHS 68 CB C2518T101[] RoHS 100 CB C2518T151[] RoHS 150 CB C2518T221[] RoHS 220 CB C2518T331[] RoHS 330 CB C2518T471[] RoHS 470 CB C2518T681[] RoHS 680 ・ [] Please specify the Inductance tolerance code（Ｋor Ｍ） Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,200 1,500 7.96 650 1,400 7.96 510 1,300 7.96 440 1,200 7.96 310 1,200 7.96 340 1,100 7.96 270 930 7.96 250 820 2.52 180 650 2.52 165 580 2.52 130 460 2.52 110 420 2.52 70 310 2.52 60 260 0.796 55 210 0.796 50 180 0.796 40 140 0.796 35 120 0.796 30 90 0.796 25 75 0.252 ／ POWER INDUCTORS INDUCTORS Parts number Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 1,000 1,200 7.96 950 1,190 7.96 890 1,100 7.96 730 1,020 7.96 680 920 7.96 550 740 7.96 480 680 2.52 350 500 2.52 320 460 2.52 270 320 2.52 240 290 2.52 200 200 2.52 160 170 0.796 140 130 0.796 115 110 0.796 100 90 0.796 80 70 0.796 65 60 0.796 ※）The saturation current value（Idc1） is the DC current value having inductance decrease down to 30%.（ at 20℃） ※）The temperature rise current value（Idc2） is the DC current value having temperature increase by 40℃.（ at 20℃） ※）The rated current value is following either Idc1 or Idc2, which is the lower one. i_wound_CB_e-E05R01 ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) . 19 85 ■PARTS NUMBER ●3225（1210）type Parts number EHS Nominal inductance ［μH］ ／ POWER INDUCTORS INDUCTORS CB C3225T1R0MR RoHS 1.0 CB C3225T1R5MR RoHS 1.5 CB C3225T2R2MR RoHS 2.2 CB C3225T3R3MR RoHS 3.3 CB C3225T4R7MR RoHS 4.7 CB C3225T6R8MR RoHS 6.8 CB C3225T100[]R RoHS 10 CB C3225T150[]R RoHS 15 CB C3225T220[]R RoHS 22 CB C3225T330[]R RoHS 33 CB C3225T470[]R RoHS 47 CB C3225T680[]R RoHS 68 CB C3225T101[]R RoHS 100 CB C3225T221[]R RoHS 220 CB C3225T821[]R RoHS 820 CB C3225T102[]R RoHS 1000 ・ [] Please specify the Inductance tolerance code（Ｋor Ｍ） Inductance tolerance Self-resonant frequency ［MHｚ］（min.） DC Resistance ［Ω］（±30％） ±20％ ±20％ ±20％ ±20％ ±20％ ±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ ±10％，±20％ 250 220 190 160 70 50 23 20 17 13 10 8.0 6.0 3.0 1.8 1.6 0.055 0.060 0.080 0.095 0.100 0.120 0.133 0.195 0.27 0.41 0.67 1.0 1.4 2.5 12 13 Rated current　※）　［ｍA］ Measuring Saturation current Temperature rise current frequency［MHz］ Idc2 Idc1 2,000 1,440 0.1 2,000 1,310 0.1 2,000 1,130 0.1 2,000 1,040 0.1 1,250 1,010 0.1 950 940 0.1 900 900 0.1 730 850 0.1 620 780 0.1 500 570 0.1 390 480 0.1 320 410 0.1 270 340 0.1 190 190 0.1 110 110 0.1 100 100 0.1 ※）The saturation current value（Idc1） is the DC current value having inductance decrease down to 30%.（ at 20℃） ※）The temperature rise current value（Idc2） is the DC current value having temperature increase by 40℃.（ at 20℃） ※）The rated current value is following either Idc1 or Idc2, which is the lower one. i_wound_CB_e-E05R01 ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our product specification sheets. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our website (http://www.ty-top.com/) . 86 19 WIRE-WOUND CHIP INDUCTORS (LB SERIES)， WIRE-WOUND CHIP POWER INDUCTORS (CB SERIES)， WIRE-WOUND CHIP INDUCTORS FOR SIGNAL LINES (LB SERIES M TYPE) ■PACKAGING ①Minimum Quantity Standard Quantity ［pcs］ Paper Tape Embossed Tape Type LB C3225 CB C3225 LB 3218 LB R2518 LB C2518 LB 2518 CB 2518 CB C2518 LBM2016 LB C2016 LB 2016 CB 2016 CB C2016 LB 2012 LB C2012 LB R2012 CB 2012 CB C2012 CB L2012 LB 1608 LBMF1608 CBMF1608 － 1000 － 2000 － 2000 － 2000 － 3000 4000 4000 － － － 3000 ②Tape material ●Embossed tape Top tape Chip Filled Sprocket hole Base tape Chip cavity Chip ●Card board carrier tape Top tape Base tape Chip Filled Sprocket hole Bottom tape Chip cavity Chip ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_CB_LB_pack_e-E05R01 ③Taping Dimensions ●Embossed Tape （0.315 inches wide） A B F Type LBM2016 LB C3225 CB C3225 LB 3218 LB 2518 CB 2518 LB C2518 CB C2518 LB R2518 LB 2016 CB 2016 LB C2016 CB C2016 LB 2012 CB 2012 LB C2012 CB C2012 LB R2012 LBMF1608 CBMF1608 1.75±0.1 (0.069±0.004） 8.0±0.3 (0.315±0.012) φ1.5＋0.1/－0 (φ0.059＋0.004/-0) 3.5±0.05 (0.138±0.002) Sprocket hole 4.0±0.1 (0.157±0.004) 2.0±0.1 (0.079±0.004) Chip cavity A B 1.75±0.1 2.1±0.1 （0.069±0.004） （0.083±0.004） 2.8±0.1 3.5±0.1 （0.110±0.004） （0.138±0.004） 2.1±0.1 3.5±0.1 （0.083±0.004） （0.138±0.004） Insertion pitch F 4.0±0.1 （0.157±0.004） 4.0±0.1 （0.157±0.004） 4.0±0.1 （0.157±0.004） Tape thickness T K 0.3±0.05 1.9max. （0.012±0.002） （0.075max.） 0.3±0.05 4.0max. （0.012±0.002） （0.157max.） 0.3±0.05 2.2max. （0.012±0.002） （0.087max.） 2.15±0.1 （0.085±0.004） 2.7±0.1 （0.106±0.004） 4.0±0.1 （0.157±0.004） 0.3±0.05 （0.012±0.002） 2.2max. （0.087max.） 1.75±0.1 （0.069±0.004） 2.1±0.1 （0.083±0.004） 4.0±0.1 （0.157±0.004） 0.3±0.05 （0.012±0.002） 1.9max. （0.075max.） 1.45±0.1 （0.057±0.004） 2.25±0.1 （0.089±0.004） 4.0±0.1 （0.157±0.004） 0.25±0.05 （0.010±0.002） 1.45max. （0.057max.） 1.1±0.1 （0.043±0.004） 1.9±0.1 （0.075±0.004） 4.0±0.1 （0.157±0.004） 0.25±0.05 （0.010±0.002） 1.2max. （0.047max.） Unit：mm（inch） Insertion pitch F 4.0±0.1 （0.157±0.004） 4.0±0.1 （0.157±0.004） Tape thickness T 1.1max. （0.043max.） 1.1max. （0.043max.） Unit：mm（inch） ●Card board carrier tape（0.315 inches wide） A B F Type CB L2012 LB 1608 1.75±0.1 (0.069±0.004） T 8.0±0.3 (0.315±0.012) φ1.5＋0.1/－0 (φ0.059＋0.004/-0) 3.5±0.05 (0.138±0.002) Sprocket hole 4.0±0.1 (0.157±0.004) 2.0±0.1 (0.079±0.004) Chip cavity A B 1.55±0.1 2.3±0.1 （0.061±0.004） （0.091±0.004） 1.0±0.1 1.8±0.1 （0.039±0.004） （0.071±0.004） ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_CB_LB_pack_e-E05R01 ④Leader and Blank Portion ⑤Reel Size ⑥Top Tape Strength The top tape requires a peel-off force 0.2 to 0.7N in the direction of the arrow as illustrated below. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_CB_LB_pack_e-E05R01 WIRE-WOUND CHIP INDUCTORS (LB SERIES), WIRE-WOUND CHIP POWER INDUCTORS (CB SERIES), WIRE-WOUND CHIP INDUCTORS FOR SIGNAL LINES (LB SERIES M TYPE) ■RELIABILITY DATA 1.Operating temperature Range LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series －40～＋105℃（Including self-generated heat） LBM Series 2. Storage Temperature Range（after soldering） LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series －40～＋85℃ LBM Series Test Methods and Remarks LB, CB Series： Please refer the term of "7. storage conditions" in precautions. 3.Rated Current LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series Within the specified tolerance LBM Series 4.Inductance LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series Within the specified tolerance LBM Series Test Methods and Remarks LB・LBC・LBR・CB・CBC・CBL・LBMF・CBMF・LBM Series Measuring equipment ：LCR Mater（HP4285A or its equivalent） Measuring frequency : Specified frequency 5.Q LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series LBM Series Test Methods and Remarks LBM Series Measuring equipment Measuring frequency － Within the specified tolerance : LCR Mater（HP4285A or its equivalent） : Specified frequency 6.DC Resisitance LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series Within the specified tolerance LBM Series Test Methods and Remarks Measuring equipment : DC Ohmmeter （HIOKI 3227 or its equivalent） 7.Self-Resonant Frequency LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series Within the specified tolerance LBM Series Test Methods and Remarks Measuring equipment : Impedance analyzer （HP4291A or its equivalent） ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_CB_LB_reli_e-E05R01 8.Temperature Characteristic LBM2016 Specified Value Test Methods and Remarks Inductance change : Within±5％ LB1608 LB2012 LBR2012 CB2012 CBL2012 LB2016 CB2016 LB2518 LBR2518 CB2518 LBC3225 CBC3225 LBMF1608 CBMF1608 LBC2016 CBC2016 LBC2518 CBC2518 LB3218 LBC2012 CBC2012 Inductance change : Within±20％ Inductance change : Within±25％ Inductance change : Within±35％ Based on the inductance at 20℃ and Measured at the ambient of －40℃～＋85℃. 9.Rasistance to Flexure of Substrate LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series No damage. LBM Series Warp : 2mm（LB・LBC・LBR・CB・CBC・CBL・LBM・LBMF・CBMF Series） Test substrate : Glass epoxy-resin substrate Thickness : 0.8mm（LB1608・LBMF1608・CBMF1608） : 1.0mm（Others） Test Methods and Remarks 10.Body Strength LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series No damage. LBM Series Test Methods and Remarks LB・LBC・LBR・CB・CBC・CBL・LBM Applied force : 10N Duration : 10sec. LB1608・LBMF1608・CBMF1608 Applied force : 5N Duration : 10sec. 11.Adhesion of terminal electrode LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series No abnormality. LBM Series Test Methods and Remarks LB・LBC・LBR・CB・CBC・CBL・LBM・LBMF・CBMF Applied force : 10N to X and Y directions Duration : 5 sec. Test substrate : Printed board LB1608・CBMF1608・LBMF1608 Applied force : 5N to X and Y directions Duration : 5 sec. Test substrate : Printed board ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_CB_LB_reli_e-E05R01 12.Resistance to vibration LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series Inductance change : Within±5％ No significant abnormality in appearance. LBM Series Test Methods and Remarks Inductance change : Within±10％ No significant abnormality in appearance. LB・LBR・LBC・CB・CBC・CBL・LBM・LBMF・CBMF： The given sample is soldered to the board and then it is tested depending on the conditions of the following table. Vibration Frequency 10～55Hz Total Amplitude 1.5mm (May not exceed acceleration 196m/s2) Sweeping Method 10Hz to 55Hz to 10Hz for 1min. X Time Y For 2 hours on each X, Y, and Z axis. Z Recovery : At least 2 hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 13.Drop test LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series － LBM Series 14.Solderability LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series At least 90％ of surface of terminal electrode is covered by new LBM Series Test Methods and Remarks LB・LBC・LBR・CB・CBC・CBL・LBM・LBMF・CBMF： Solder temperature : 245±5℃ Duration : 5±0.5sec Flux : Methanol solution with 25％ of colophony 15.Resistance to soldering LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series LBM Series Test Methods and Remarks Inductance change : Within±10％ Inductance change : Within±5％ LB・LBC・LBR・CB・CBC・CBL・LBM・LBMF・CBMF： 3 times of reflow oven at 230℃ MIN for 40sec. with peak temperature at 260 ℃ for 5sec. Recovery : At least 2 hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 16.Resisitance to solvent LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series － LBM Series Test Methods and Remarks Solvent temperature Type of solvent Cleaning conditions : Room temperature : Isopropyl alcohol : 90s. Immersion and cleaning. 17.Thermal shock LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series Inductance change : Within±10％ No significant abnormality in appearance. LBM Series Test Methods and Remarks LB・LBC・LBR・CB・CBC・CBL・LBM・LBMF・CBMF： The given sample is soldered to the board and then its Inductance is measured after 100cycles of the following conditions. Conditions of 1 cycle Step Temperature (℃) Duration (min) 1 －40±3 30±3 2 Room temperature Within 3 3 ＋85±2 30±3 4 Room temperature Within 3 Recovery : At least 2 hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_CB_LB_reli_e-E05R01 18.Damp heat life test LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series Inductance change : Within±10％ No significant abnormality in appearance. LBM Series Test Methods and Remarks Temperature Humidity Duration Recovery : 60±2℃ : 90～95％RH : 1000 hrs : At least 2 hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 19.Loading under damp heat life test LB, LBC, LBR, LBMF Series CB, CBC, CBL, CBMF Series Specified Value Test Methods and Remarks Inductance change : Within±10％ No significant abnormality in appearance. LBM Series Temperature Humidity Duration Applied current Recovery : 60±2℃ : 90～95％RH : 1000 hrs : Rated current : At least 2 hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 20.High temperature life test Specified Value LB, LBC, LBR, LBMF Series － CB, CBC, CBL, CBMF Series Inductance change : Within±10％ No significant abnormality in appearance. LBM Series Test Methods and Remarks Temperature Duration Recovery : 85±2℃ : 1000 hrs : At least 2 hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 21.Loading at high temperature life test LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series LBM Series Test Methods and Remarks Temperature Duration Applied current Recovery Inductance change : Within±10％ （LBC3225 Series : Within±20％） No significant abnormality in appearance. － : 85±2℃ : 1000 hrs : Rated current : At least 2 hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 22.Low temperature life test LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series Inductance change : Within±10％ No significant abnormality in appearance. LBM Series Test Methods and Remarks Temperature Duration Recovery : －40±2℃ : 1000 hrs : At least 2 hrs of recovery under the standard condition after the test, followed by the measurement within 48 hrs. 23.Standard condition LB, LBC, LBR, LBMF Series Specified Value CB, CBC, CBL, CBMF Series LBM Series Standard test conditions Unless specified, Ambient temperature is 20±15℃ and the Relative humidity is 65±20％. If there is any doubt about the test results, further measurement shall be had within the following limits: Ambient Temperature: 20±2℃ Relative humidity: 65±5％ Inductance value is based on our standard measurement systems. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_CB_LB_reli_e-E05R01 WIRE-WOUND CHIP INDUCTORS (LB SERIES)， WIRE-WOUND CHIP POWER INDUCTORS (CB SERIES)， WIRE-WOUND CHIP INDUCTORS FOR SIGNAL LINES (LB SERIES M TYPE) ■PRECAUTIONS 1．Circuit Design Precautions ◆Operating environment 1. The products described in this specification are intended for use in general electronic equipment, (office supply equipment, telecommunications systems, measuring equipment, and household equipment). They are not intended for use in mission-critical equipment or systems requiring special quality and high reliability (traffic systems, safety equipment, aerospace systems, nuclear control systems and medical equipment including life-support systems,) where product failure might result in loss of life, injury or damage. For such uses, contact TAIYO YUDEN Sales Department in advance. 2．PCB Design Precautions Technical considerations ◆Land pattern design 1. Please contact any of our offices for a land pattern, and refer to a recommended land pattern of a right figure or specifications. PRECAUTIONS 【Recommended Land Patterns】 Surface Mounting ・ Mounting and soldering conditions should be checked beforehand. ・ Applicable soldering process to those products is reflow soldering only. 3．Considerations for automatic placement Precautions Technical considerations ◆Adjustment of mounting machine 1. Excessive impact load should not be imposed on the products when mounting onto the PC boards. 2. Mounting and soldering conditions should be checked beforehand. 1. When installing products, care should be taken not to apply distortion stress as it may deform the products. 4．Soldering Precautions ◆Reflow soldering（ LB and CB Types） 1. For reflow soldering with either leaded or lead-free solder, the profile specified in "point for controlling" is recommended. ◆Recommended conditions for using a soldering iron 1. Put the soldering iron on the land-pattern. Soldering iron's temperature - Below 350℃ Duration-3 seconds or less. The soldering iron should not come in contact with inductor directly. ◆Reflow soldering（ LB and CB Types） 1. Reflow profile Technical considerations ◆Recommended conditions for using a soldering iron 1. Components can be damaged by excessive heat where soldering conditions exceed the specified range. 5．Cleaning Precautions Technical considerations ◆Cleaning conditions Washing by supersonic waves shall be avoided. ◆Cleaning conditions If washed by supersonic waves, the products might be broken. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_CB_LB_prec_e-E06R01 6．Handling Precautions Technical considerations ◆Handling 1. Keep the inductors away from all magnets and magnetic objects. ◆Breakaway PC boards（ splitting along perforations） 1. When splitting the PC board after mounting inductors, care should be taken not to give any stresses of deflection or twisting to the board. 2. Board separation should not be done manually, but by using the appropriate devices. ◆Mechanical considerations 1. Please do not give the inductors any excessive mechanical shocks. ◆Handling 1. There is a case that a characteristic varies with magnetic influence. ◆Breakaway PC boards（ splitting along perforations） 1. Planning pattern configurations and the position of products should be carefully performed to minimize stress. ◆Mechanical considerations 1. There is a case to be damaged by a mechanical shock. 7．Storage conditions Precautions ◆Storage 1. To maintain the solderability of terminal electrodes and to keep the packing material in good condition, temperature and humidity in the storage area should be controlled. ・ Recommended conditions Ambient temperature : 0～40℃ Humidity : Below 70% RH ・ The ambient temperature must be kept below 30℃. Even under ideal storage conditions, solderability of products electrodes may decrease as time passes. For this reason, product should be used within 6 months from the time of delivery. In case of storage over 6 months, solderability shall be checked before actual usage. Technical considerations ◆Storage 1. Under a high temperature and humidity environment, problems such as reduced solderability caused by oxidation of terminal electrodes and deterioration of taping/packaging materials may take place. ▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification. For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) . i_wound_CB_LB_prec_e-E06R01
