17
金属磁芯 SMD 功率电感器
（MCOILTM MD 系列）
METAL CORE SMD POWER INDUCTORS（MCOILTM MD SERIES）
回流焊
REFLOW
※使用温度范围：
-40 ～+125℃（包含产品本身发热）
*Operating
Temp.：-40～+125℃（Including
self-generated heat）
■PARTS
NUMBER
型号标示法
M D
①
K
K
1
6
②
①Series name
①类型
Code
代码
MD
6
T
④
1
R 0
⑤
M M △
⑥ ⑦ ⑧
电感器／功率电感器
Dimensions（H）［mm］
尺寸（H）
［mm］
0.95
1.0
1.2
1.4
2.0
⑥电感量公差
⑥Inductance tolerance
Code
代码
M
N
标称电感值
［μH］
Nominal
inductance［μH］
0.47
1.0
4.7
电感量公差
Inductance
tolerance
±20％
±30％
⑦个别规格
⑦Special code
Code
代码
F
M
尺寸（L×W ）
［mm］
Dimensions（L×W）［mm］
1.6×1.6
2.0×2.0
3.0×3.0
4.0×4.0
4.9×4.9
④包装
④Packaging
Code
代码
T
空格 space
△＝Blank
⑤标称电感值
⑤Nominal inductance
Code
代码
（例）
（example）
R47
1R0
4R7
※R＝Decimal
小数点 point
Series
name
类型
Metal 基本金属线圈规格
base coil specification
②Dimensions（H）
②尺寸（
H）
Code
代码
JE
KK
MK
PK
WK
③尺寸（L×W）
③Dimensions（L×W）
Code
代码
1616
2020
3030
4040
5050
1
③
Special
code
个别规格
Ferrite coating
铁氧体外塗品
Metal coating
金属外塗品
⑧Internal code
⑧本公司管理记号
Packaging
包装
Taping
卷盘带装
标准外型尺寸／标准数量
■STANDARD
EXTERNAL DIMENSIONS / STANDARD QUANTITY
推荐焊盘图案
Recommended
Land Patterns
B
e
f
L
C
e
W
MDKK1616
MDJE2020
MDKK2020
MDMK2020
MDKK3030
MDMK3030
MDJE4040
MDMK4040
MDWK4040
MDPK5050
A
0.5
0.65
0.8
1.2
1.5
H
A
Type
Type
1616
2020
3030
4040
5050
B
1.10
1.35
2.2
2.8
3.6
C
1.65
2.0
2.7
3.7
4.2
Unit：mm
单位：
mm
A
L
W
H
e
f
1.64±0.1
(0.065±0.004)
2.0±0.15
(0.079±0.006)
2.0±0.15
(0.079±0.006)
2.0±0.15
(0.079±0.006)
3.0±0.1
(0.118±0.004)
3.0±0.1
(0.118±0.004)
4.0±0.2
(0.157±0.008)
4.0±0.2
(0.157±0.008)
4.0±0.2
(0.157±0.008)
4.9±0.2
(0.193±0.008)
1.64±0.1
(0.065±0.004)
2.0±0.15
(0.079±0.006)
2.0±0.15
(0.079±0.006)
2.0±0.15
(0.079±0.006)
3.0±0.1
(0.118±0.004)
3.0±0.1
(0.118±0.004)
4.0±0.2
(0.157±0.008)
4.0±0.2
(0.157±0.008)
4.0±0.2
(0.157±0.008)
4.9±0.2
(0.193±0.008)
1.0 max
(0.039 max)
0.95 max
(0.0374 max)
1.0 max
(0.039 max)
1.2 max
(0.047 max)
1.0 max
(0.039 max)
1.2 max
(0.047 max)
0.95 max
(0.0374 max)
1.2 max
(0.047 max)
2.0 max
(0.0787 max)
1.4 max
(0.055 max)
0.40 ＋0.2/－0.1
(0.016 +0.008/-0.004)
0.50±0.2
(0.02±0.008)
0.50±0.2
(0.02±0.008)
0.50±0.2
(0.02±0.008)
0.90±0.2
(0.035±0.008)
0.90±0.2
(0.035±0.008)
1.1±0.2
(0.043±0.008)
1.1±0.2
(0.043±0.008)
1.1±0.2
(0.043±0.008)
1.20±0.2
(0.047±0.008)
1.0±0.2
(0.039±0.008)
1.25±0.2
(0.049±0.008)
1.25±0.2
(0.049±0.008)
1.25±0.2
(0.049±0.008)
1.9±0.2
(0.075±0.008)
1.9±0.2
(0.075±0.008)
2.5±0.2
(0.098±0.008)
2.5±0.2
(0.098±0.008)
2.5±0.2
(0.098±0.008)
3.3±0.2
(0.130±0.008)
Standard
标准数量quantity
[pcs]
卷盘带装
［pcs］
Taping
2500
2500
2500
2500
2000
2000
1000
1000
700
1000
单位：mm
（inch）
Unit：mm（inch）
i_smd_MD_e-E05R01
▶ 由于篇幅有限，本产品目录中只记载了有代表性的产品规格，若考虑使用弊司产品时，请确认交货规格说明书中的详细规格。
另外，有关各产品的详细信息
（特性图、可靠性信息、使用时的注意事项等），请参阅弊司网站
（http://www.ty-top.com/ ）。
38
17
型号一览
■PARTS
NUMBER
MDKK1616 型 type
●MDKK1616
【厚度:1.0mm
max.】
【Thickness：1.0mm
Parts
number
型号
EHS
Nominal
inductance
标称电感值
［μH］
［μ
H］
Inductance
tolerance
电感量公差
自共振频率
frequency
（min.）
［［MHｚ］（min.）
MHｚ］
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
0.47
1.0
1.5
2.2
3.3
4.7
6.8
10
15
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
-
MDKK1616TR47MM
MDKK1616T1R0MM
MDKK1616T1R5MM
MDKK1616T2R2MM
MDKK1616T3R3MM
MDKK1616T4R7MM
MDKK1616T6R8MM
MDKK1616T100MM
MDKK1616T150MM
MDJE2020 型 type
●MDJE2020
max.】
Self-resonant
【厚度:0.95mm
max.】
【Thickness：0.95mm
EHS
MDJE2020T1R0MM
MDJE2020T2R2MM
MDJE2020T3R3MM
MDJE2020T4R7MM
MDJE2020T6R8MM
MDJE2020T100MM
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
Self-resonant
Inductance
tolerance
电感量公差
1.0
2.2
3.3
4.7
6.8
10
±20％
±20％
±20％
±20％
±20％
±20％
【厚度:1.0mm
max.】
【Thickness：1.0mm
Parts型号
number
Nominal
inductance
标称电感值
［μH］
［μ
H］
电感量公差
Inductance
tolerance
0.47
0.68
1.0
1.5
2.2
3.3
4.7
10
15
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
MDKK2020TR47MM
MDKK2020TR68MM
MDKK2020T1R0MM
MDKK2020T1R5MM
MDKK2020T2R2MM
MDKK2020T3R3MM
MDKK2020T4R7MM
MDKK2020T100MM
MDKK2020T150MM
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
Parts
number
型号
Nominal
inductance
标称电感值
［μH］
［μ
H］
电感量公差
Inductance
tolerance
0.47
0.68
1.0
1.5
2.2
3.3
4.7
±20％
±20％
±20％
±20％
±20％
±20％
±20％
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
自共振频率
frequency
（min.）
［MHｚ］
［MHｚ］（min.）
-
Self-resonant
【厚度:1.2mm
max.】
【Thickness：1.2mm
MDMK2020TR47MM
MDMK2020TR68MM
MDMK2020T1R0MM
MDMK2020T1R5MM
MDMK2020T2R2MM
MDMK2020T3R3MM
MDMK2020T4R7MM
自共振频率
frequency
（min.）
［［MHｚ］（min.）
MHｚ］
-
Self-resonant
自共振频率
frequency
［MHｚ］
（min.）
［MHｚ］（min.）
-
【厚度:1.0mm
max.】
【Thickness：1.0mm
Parts
number
型号
EHS
Nominal
inductance
标称电感值
［μH］
［μ
H］
Inductance
tolerance
电感量公差
自共振频率
frequency
［［MHｚ］（min.）
（min.）
MHｚ］
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
0.47
1.0
1.5
2.2
3.3
4.7
6.8
10
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
-
Self-resonant
【厚度:1.2mm
max.】
【Thickness：1.2mm
Parts
number
型号
Nominal
inductance
标称电感值
［μH］
［μ
H］
电感量公差
Inductance
tolerance
0.30
0.33
0.47
1.0
1.5
2.2
3.3
4.7
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
MDMK3030TR30MM
MDMK3030TR33MM
MDMK3030TR47MM
MDMK3030T1R0MM
MDMK3030T1R5MM
MDMK3030T2R2MM
MDMK3030T3R3MM
MDMK3030T4R7MM
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
Max.
1,500
1,200
1,100
950
650
550
520
450
400
Typ.
1,780
1,490
1,330
1,110
730
630
600
500
440
1
1
1
1
1
1
1
1
1
DC直流电阻
Resistance［Ω］
［Ω］
Max.
0.121
0.266
0.340
0.475
0.630
1.040
Typ.
0.106
0.230
0.290
0.410
0.550
0.910
Rated
current ※） ［ｍA］
额定电流 ※）
［ｍA］
Measuring
测试频率
Saturation current::Idc1
Idc1 Temperature
rise current:
直流重叠允许电流
温度上升允许电流
:Idc2Idc2 frequency［kHz］
［kHz］
Max.
3,100
1,550
1,350
1,200
800
700
Typ.
3,800
1,900
1,600
1,550
1,100
900
Max.
1,550
1,050
950
850
750
550
Typ.
1,800
1,200
1,100
950
850
600
1
1
1
1
1
1
DC直流电阻
Resistance［Ω］
［Ω］
Max.
0.046
0.060
0.085
0.133
0.165
0.275
0.435
0.690
1.180
额定电流 ※）
［ｍA］
Rated
current ※） ［ｍA］
Saturation current::Idc1
Idc1 Temperature
rise current:
直流重叠允许电流
温度上升允许电流
:Idc2Idc2
Typ.
0.040
0.052
0.074
0.115
0.139
0.240
0.375
0.600
1.020
Max.
3,500
3,200
2,900
1,900
1,650
1,300
1,050
750
550
Typ.
4,150
3,650
3,400
2,250
1,950
1,550
1,250
900
750
Max.
2,200
2,000
1,700
1,350
1,200
940
750
630
480
Typ.
2,500
2,100
1,900
1,500
1,350
1,050
850
680
550
Measuring
测试频率
frequency［kHz］
［kHz］
1
1
1
1
1
1
1
1
1
DC直流电阻
Resistance［Ω］
［Ω］
Max.
0.046
0.058
0.064
0.086
0.109
0.178
0.242
Typ.
0.040
0.050
0.056
0.075
0.095
0.155
0.210
额定电流 ※）
［ｍA］
Rated
current ※） ［ｍA］
Measuring
测试频率
Saturation current::Idc1
Idc1 Temperature
rise current:
直流重叠允许电流
温度上升允许电流
:Idc2Idc2 frequency［kHz］
［kHz］
Max.
4,200
3,500
2,550
2,000
1,750
1,350
1,150
Typ.
4,800
4,100
2,900
2,300
2,000
1,550
1,300
Max.
2,300
2,000
1,900
1,650
1,450
1,150
950
Typ.
2,450
2,200
2,050
1,750
1,550
1,200
1,050
1
1
1
1
1
1
1
max.】
MDMK3030 型 type
●MDMK3030
EHS
Typ.
4,100
2,750
2,200
1,800
1,450
1,200
880
800
640
max.】
MDKK3030 型 type
●MDKK3030
MDKK3030TR47MM
MDKK3030T1R0MM
MDKK3030T1R5MM
MDKK3030T2R2MM
MDKK3030T3R3MM
MDKK3030T4R7MM
MDKK3030T6R8MM
MDKK3030T100MM
Max.
3,300
2,200
1,750
1,500
1,150
950
630
550
460
max.】
MDMK2020 型 type
●MDMK2020
EHS
Typ.
0.080
0.120
0.160
0.215
0.450
0.550
0.710
0.970
1.600
max.】
Nominal
inductance
标称电感值
［μH］
［μ
H］
MDKK2020 型 type
●MDKK2020
EHS
Max.
0.095
0.140
0.185
0.250
0.515
0.640
0.820
1.120
1.800
Rated
current ※） ［ｍA］
额定电流 ※）
［ｍA］
Measuring
测试频率
Saturation current::Idc1
Idc1 Temperature
rise current:
直流重叠允许电流
温度上升允许电流
:Idc2Idc2 frequency［kHz］
［kHz］
电感器／功率电感器
Parts型号
number
DC直流电阻
Resistance［Ω］
［Ω］
DC
Resistance［Ω］
直流电阻
［Ω］
Max.
0.039
0.086
0.100
0.144
0.248
0.345
0.437
0.575
Typ.
0.033
0.074
0.087
0.125
0.215
0.300
0.380
0.500
Rated
current ※） ［ｍA］
额定电流 ※）
［ｍA］
Measuring
测试频率
Saturation current::Idc1
Idc1 Temperature
rise current:
温度上升允许电流
:Idc2Idc2 frequency［kHz］
直流重叠允许电流
［kHz］
Max.
5,400
4,400
3,000
2,500
2,000
1,700
1,400
1,100
Typ.
6,500
5,200
3,500
3,000
2,400
2,000
1,700
1,300
Max.
3,900
2,400
2,100
1,900
1,350
1,150
1,000
850
Typ.
4,500
2,800
2,400
2,200
1,500
1,300
1,150
1,000
1
1
1
1
1
1
1
1
max.】
Self-resonant
自共振频率
frequency
（min.）
［MHｚ］
［MHｚ］（min.）
-
DC直流电阻
Resistance［Ω］
［Ω］
Max.
0.020
0.020
0.027
0.050
0.074
0.112
0.167
0.263
Typ.
0.017
0.017
0.023
0.043
0.064
0.097
0.145
0.228
额定电流 ※）
［ｍA］
Rated
current ※） ［ｍA］
Measuring
测试频率
Saturation current::Idc1
Idc1 Temperature
rise current:
温度上升允许电流
直流重叠允许电流
:Idc2Idc2 frequency［kHz］
［kHz］
Max.
7,600
6,400
6,300
4,300
3,400
2,800
2,100
1,800
Typ.
9,200
8,700
7,500
5,100
4,100
3,600
2,700
2,300
Max.
5,500
5,500
4,700
3,300
2,500
2,100
1,650
1,350
Typ.
6,400
6,400
5,500
3,900
3,000
2,400
1,900
1,550
1
1
1
1
1
1
1
1
i_smd_MD_e-E05R01
▶ 由于篇幅有限，本产品目录中只记载了有代表性的产品规格，若考虑使用弊司产品时，请确认交货规格说明书中的详细规格。
另外，有关各产品的详细信息
（特性图、可靠性信息、使用时的注意事项等），请参阅弊司网站
（http://www.ty-top.com/ ）。
17
39
■PARTS
NUMBER
型号一览
【厚度:0.95mm
max.】
【Thickness：0.95mm
MDJE4040 型 type
●MDJE4040
Parts型号
number
EHS
Nominal
inductance
标称电感值
［μH］
［μ
H］
MDJE4040TR47MM
MDJE4040T1R0MM
MDJE4040T1R5MM
MDJE4040T2R2MM
MDJE4040T3R3MM
MDJE4040T4R7MM
MDJE4040T6R8MM
MDJE4040T100MM
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
0.47
1.0
1.5
2.2
3.3
4.7
6.8
10
MDMK4040F 型 type
●MDMK4040F
电感器／功率电感器
MDMK4040TR47MF
MDMK4040T1R0MF
MDMK4040T1R2MF
MDMK4040T1R5MF
MDMK4040T2R2MF
EHS
RoHS
RoHS
RoHS
RoHS
RoHS
MDMK4040M 型 type
●MDMK4040M
MDWK4040TR33NM
MDWK4040TR47NM
MDWK4040TR68MM
MDWK4040T1R0MM
MDWK4040T1R5MM
MDWK4040T2R2MM
MDWK4040T3R3MM
MDWK4040T4R7MM
MDWK4040T6R8MM
MDWK4040T100MM
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
-
电感量公差
Inductance
tolerance
0.47
1.0
1.2
1.5
2.2
±20％
±20％
±20％
±20％
±20％
Self-resonant
自共振频率
frequency
［［MHｚ］（min.）
MHｚ］（min.）
-
电感量公差
Inductance
tolerance
Self-resonant
自共振频率
frequency
［［MHｚ］（min.）
MHｚ］（min.）
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
-
Typ.
0.035
0.060
0.073
0.100
0.175
0.220
0.320
0.440
［Ω］
DC直流电阻
Resistance［Ω］
Max.
0.029
0.047
0.047
0.065
0.092
Typ.
0.025
0.041
0.041
0.056
0.080
Rated
current ※） ［ｍA］
额定电流 ※）
［ｍA］
测试频率
Measuring
Saturation current::Idc1
Idc1 Temperature
rise current:
直流重叠允许电流
温度上升允许电流
:Idc2Idc2 frequency［kHz］
［kHz］
Max.
Typ.
Max.
Typ.
7,500
10,000
4,600
5,400
100
5,200
7,500
3,500
4,200
100
4,200
6,200
3,500
4,200
100
3,700
5,400
3,300
3,600
100
3,200
4,500
2,500
2,900
100
［Ω］
DC直流电阻
Resistance［Ω］
Max.
0.029
0.036
0.065
0.079
0.130
0.160
0.230
0.330
Typ.
0.025
0.031
0.056
0.069
0.113
0.140
0.200
0.280
Rated
current ※） ［ｍA］
额定电流 ※）
［ｍA］
Measuring
测试频率
Saturation current::Idc1
Idc1 Temperature
rise current:
直流重叠允许电流
温度上升允许电流
:Idc2Idc2 frequency［kHz］
［kHz］
Max.
Typ.
Max.
Typ.
6,700
7,800
5,000
5,700
1
5,000
6,200
4,500
5,100
1
4,500
5,600
3,200
3,600
1
3,800
4,500
2,800
3,200
1
3,200
4,000
2,200
2,500
1
2,500
3,000
1,900
2,200
1
1,900
2,200
1,600
1,800
1
1,700
2,000
1,400
1,600
1
max.】
EHS
Nominal
inductance
标称电感值
［μH］
［μ
H］
Inductance
tolerance
电感量公差
Self-resonant
自共振频率
frequency
（min.）
［MHｚ］
［MHｚ］（min.）
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
±30％
±30％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
±20％
-
●MDPK5050
MDPK5050 型 type
【厚度:1.4mm
max.】
【Thickness：1.4mm
Parts
number
型号
EHS
Nominal
inductance
标称电感值
［μH］
［μ
H］
Inductance
tolerance
电感量公差
Self-resonant
自共振频率
frequency
（min.）
［［MHｚ］（min.）
MHｚ］
RoHS
RoHS
RoHS
RoHS
RoHS
RoHS
1.0
2.2
3.3
4.7
6.8
10
±20％
±20％
±20％
±20％
±20％
±20％
-
MDPK5050T1R0MM
MDPK5050T2R2MM
MDPK5050T3R3MM
MDPK5050T4R7MM
MDPK5050T6R8MM
MDPK5050T100MM
Max.
0.040
0.069
0.084
0.115
0.200
0.250
0.370
0.510
Rated
current ※） ［ｍA］
额定电流 ※）
［ｍA］
Measuring
测试频率
Saturation current::Idc1
Idc1 Temperature
rise current:
Idc2 frequency［kHz］
直流重叠允许电流
温度上升允许电流
:Idc2
［kHz］
Max.
Typ.
Max.
Typ.
6,000
7,900
4,000
4,500
1
4,700
5,700
3,000
3,500
1
3,000
4,000
2,700
3,100
1
2,400
3,100
2,400
2,700
1
2,000
2,600
1,800
2,000
1
1,900
2,300
1,600
1,900
1
1,500
1,800
1,300
1,500
1
1,400
1,700
1,100
1,300
1
max.】
EHS
【厚度:2.0mm
max.】
【Thickness：2.0mm
DC直流电阻
Resistance［Ω］
［Ω］
max.】
标称电感值
Nominal
inductance
［μH］
［μ
H］
【厚度:1.2mm
max.】
【Thickness：1.2mm
MDWK4040M 型 type
●MDWK4040M
Parts型号
number
Self-resonant
自共振频率
frequency
（min.）
［MHｚ］
［MHｚ］（min.）
标称电感值
Nominal
inductance
［μH］
［μ
H］
Parts
number
型号
MDMK4040TR68MM
MDMK4040T1R0MM
MDMK4040T1R5MM
MDMK4040T2R2MM
MDMK4040T3R3MM
MDMK4040T4R7MM
MDMK4040T6R8MM
MDMK4040T100MM
Inductance
tolerance
电感量公差
【厚度:1.2mm
max.】
【Thickness：1.2mm
Parts型号
number
max.】
［Ω］
DC直流电阻
Resistance［Ω］
Max.
0.013
0.013
0.016
0.027
0.041
0.054
0.075
0.107
0.158
0.194
Typ.
0.011
0.011
0.014
0.023
0.035
0.047
0.066
0.093
0.138
0.169
额定电流 ※）
［ｍA］
Rated
current ※） ［ｍA］
测试频率
Measuring
直流重叠允许电流
温度上升允许电流
Saturation current::Idc1
Idc1 Temperature
rise current:
:Idc2Idc2 frequency［kHz］
［kHz］
Max.
Typ.
Max.
Typ.
16,000
21,000
7,800
8,800
1
10,000
15,000
7,800
8,800
1
8,000
12,000
7,300
8,300
1
7,000
9,400
5,100
5,800
1
7,000
9,400
4,100
4,700
1
5,400
7,500
3,500
4,000
1
3,700
5,200
3,000
3,300
1
3,500
5,000
2,500
2,800
1
2,900
4,000
2,000
2,300
1
2,200
3,100
1,600
1,900
1
max.】
DC
Resistance［Ω］
直流电阻
［Ω］
Max.
0.040
0.055
0.086
0.102
0.138
0.225
Typ.
0.034
0.047
0.073
0.088
0.12
0.19
额定电流 ※）
［ｍA］
Rated
current ※） ［ｍA］
Measuring
测试频率
Saturation current::Idc1
Idc1 Temperature
rise current:
温度上升允许电流
:Idc2Idc2 frequency［kHz］
直流重叠允许电流
［kHz］
Max.
Typ.
Max.
Typ.
8,500
10,000
4,300
4,700
1
4,100
5,000
3,600
4,200
1
3,800
4,500
2,900
3,400
1
3,500
4,200
2,500
3,000
1
2,700
3,200
2,200
2,500
1
2,200
2,600
1,700
2,000
1
※）
（Idc1）
为直流重叠带来的电感值下降，范围在30％以内的直流电感值
（at
20℃）
※）直流重叠允许电流
The saturation current
value
(Idc1) is the DC current value having inductance decrease
down
to 30%. (at 20℃)
※）
为温度上升到40℃时的直流电感值
（at
20℃）
※）温度上升允许电流
The temperature（Idc2）
rise current
value（Idc2) is the DC current
value
having temperature increase up to 40℃. (at 20℃)
※）最大额定电流值为能够满足直流重叠允许电流和温度上升允许电流的直流电流值
※） The rated current is the DC current value that satisfies both of current value saturation current value and temperature rise current value.
i_smd_MD_e-E05R01
▶ 由于篇幅有限，本产品目录中只记载了有代表性的产品规格，若考虑使用弊司产品时，请确认交货规格说明书中的详细规格。
另外，有关各产品的详细信息
（特性图、可靠性信息、使用时的注意事项等），请参阅弊司网站
（http://www.ty-top.com/ ）。
40
17
METAL CORE SMD POWER INDUCTORS (MCOILTM MD SERIES）
■PACKAGING
①Minimum Quantity
Standard Quantity [pcs]
Tape ＆ Reel
2500
Type
MDKK1616
MDJE2020
MDKK2020
MDMK2020
MDKK3030
MDMK3030
MDJE4040
MDMK4040
MDWK4040
MDPK5050
2500
2000
1000
700
1000
②Tape Material
●Embossed Tape
Top tape
Chip Filled
Sprocket hole
Base tape
Chip cavity
Chip
③Taping dimensions
●Embossed tape 8mm wide (0.315 inches wide)
1.75±0.1
(0.069±0.004）
A
B
T
8.0±0.2
(0.315±0.008)
φ1.5＋0.1/－0
(φ0.059＋0.004/-0)
3.5±0.1
(0.138±0.004)
Sprocket hole
K
F
Type
MDKK1616
MDJE2020
MDKK2020
MDMK2020
MDKK3030
MDMK3030
4.0±0.1
(0.157±0.004)
2.0±0.05
(0.079±0.002)
Electrode（bottom view）
Chip cavity
A
B
1.79±0.1
1.79±0.1
(0.071±0.004)
(0.071±0.004)
Insertion pitch
F
4.0±0.1
(0.157±0.004)
Tape thickness
T
K
0.25±0.05
1.1±0.1
(0.010±0.002)
(0.043±0.004)
2.2±0.1
（0.102±0.004）
2.2±0.1
（0.102±0.004）
4.0±0.1
（0.157±0.004）
0.25±0.05
（0.009±0.002）
1.3±0.1
（0.051±0.004）
3.2±0.1
(0.126±0.004)
3.2±0.1
(0.126±0.004)
4.0±0.1
(0.157±0.004)
0.3±0.05
(0.012±0.002)
1.4±0.1
(0.055±0.004)
Unit：mm（inch）
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_smd_MD_pack_e-E05R01
●Embossed tape 12mm wide (0.47 inches wide)
1.75±0.1
(0.069±0.004）
A
B
T
12.0±0.3
(0.472±0.012)
φ1.5＋0.1/－0
(φ0.059＋0.004/-0)
5.5±0.1
(0.217±0.004)
Sprocket hole
K
F
2.0±0.1
(0.079±0.004)
4.0±0.1
(0.157±0.004)
Electrode（bottom view）
A
B
Insertion pitch
F
T
K
MDJE4040
MDMK4040
MDWK4040
4.3±0.1
（0.169±0.004）
4.3±0.1
（0.169±0.004）
8.0±0.1
（0.315±0.004）
0.3±0.1
（0.012±0.004）
1.6±0.1
（0.063±0.004）
MDPK5050
5.25±0.1
（0.207±0.004）
5.25±0.1
（0.207±0.004）
8.0±0.1
（0.315±0.004）
0.3±0.1
（0.012±0.004）
1.6±0.1
（0.063±0.004）
Type
Chip cavity
Tape thickness
Unit：mm（inch）
④Leader and Blank portion
⑤Reel size
Type
MDKK1616
MDJE2020
MDKK2020
MDMK2020
MDKK3030
MDMK3030
MDJE4040
MDMK4040
MDWK4040
MDPK5050
φD
Reel size (Reference values)
φd
W
180±0.5
（7.087±0.019）
60±1.0
（2.36±0.04）
10.0±1.5
（0.394±0.059）
180±3.0
（7.087±0.118）
60±2.0
（2.36±0.08）
14.0±1.5
（0.551±0.059）
Unit：mm（inch）
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_smd_MD_pack_e-E05R01
⑥Top Tape Strength
Top tape strength
Type
MDKK1616
MDJE2020
MDKK2020
MDMK2020
MDKK3030
MDMK3030
MDJE4040
MDMK4040
MDWK4040
MDPK5050
Peel-off strength
0.1N～1.0N
0.1N～1.3N
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_smd_MD_pack_e-E05R01
METAL CORE SMD POWER INDUCTORS (MCOILTM MD SERIES）
■RELIABILITY DATA
1. Operating Temperature Range
Specified Value
MD series
－40～＋125℃
Test Methods and
Remarks
Including self-generated heat
2. Storage Temperature Range
Specified Value
MD series
Test Methods and
Remarks
－40～＋85℃
－5 to 40℃ for the product with taping.
3. Rated current
Specified Value
MD series
Within the specified tolerance
4. Inductance
Specified Value
Test Methods and
Remarks
MD series
Measuring equipment
Measuring condition
Within the specified tolerance
: LCR Meter （HP 4285A or equivalent）
: Please see item list.
5. DC Resistance
Specified Value
MD series
Test Methods and
Remarks
Measuring equipment
Within the specified tolerance
: DC ohmmeter （HIOKI 3227 or equivalent）
6. Self resonance frequency
Specified Value
MD series
－
7. Temperature characteristic
Specified Value
MD series
Test Methods and
Remarks
Measurement of inductance shall be taken at temperature range within －40℃～＋125℃.
With reference to inductance value at ＋20℃., change rate shall be calculated.
Inductance change : Within ±10%
8. Resistance to flexure of substrate
Specified Value
Test Methods and
Remarks
MD series
No damage
The test samples shall be soldered to the test board by the reflow. As illustrated below, apply force in the direction of the arrow indicating
until deflection of the test board reaches to 2 mm.
Test board size
: 100×40×1.0 mm
Test board material
: Glass epoxy-resin
Solder cream thickness
: 0.10 mm
9. Insulation resistance : between wires
Specified Value
MD series
－
10. Insulation resistance : between wire and core
Specified Value
MD series
－
11. Withstanding voltage : between wire and core
Specified Value
MD series
－
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_smd_MD_reli_e-E04R01
12. Adhesion of terminal electrode
Specified Value
MD series
Test Methods and
Remarks
The test samples shall be soldered to the test board by the reflow.
Applied force
: 10N to X and Y directions.
Duration
: 5s.
Solder cream thickness
Shall not come off PC board
: 0.10mm.
13. Resistance to vibration
Inductance change : Within ±10%
No significant abnormality in appearance.
Specified Value
MD series
Test Methods and
Remarks
The test samples shall be soldered to the test board by the reflow.
Then it shall be submitted to below test conditions.
Frequency Range
10～55Hz
Total Amplitude
1.5mm (May not exceed acceleration 196m/s2)
Sweeping Method
10Hz to 55Hz to 10Hz for 1min.
X
Time
Y
For 2 hours on each X, Y, and Z axis.
Z
Recovery : At least 2hrs of recovery under the standard condition after the test, followed by the measurement within 48hrs.
14. Solderability
Specified Value
MD series
Test Methods and
Remarks
The test samples shall be dipped in flux, and then immersed in molten solder as shown in below table.
Flux : Methanol solution containing rosin 25%.
Solder Temperature
245±5℃
Time
5±1.0 sec.
※Immersion depth : All sides of mounting terminal shall be immersed.
At least 90％ of surface of terminal electrode is covered by new solder.
15. Resistance to soldering heat
Inductance change : Within ±10%
No significant abnormality in appearance.
Specified Value
MD series
Test Methods and
Remarks
The test sample shall be exposed to reflow oven at 230±5℃ for 40 seconds, with peak temperature at 260±5℃ for 5 seconds, 2 times.
Test board material
: Glass epoxy-resin
Test board thickness
: 1.0mm
16. Thermal shock
Inductance change : Within ±10%
No significant abnormality in appearance.
Specified Value
MD series
Test Methods and
Remarks
The test samples shall be soldered to the test board by the reflow. The test samples shall be placed at specified temperature for specified
time by step 1 to step 4 as shown in below table in sequence. The temperature cycle shall be repeated 100 cycles.
Conditions of 1 cycle
Step
Temperature (℃)
Duration (min)
1
－40±3
30±3
2
Room temperature
Within 3
3
＋85±2
30±3
4
Room temperature
Within 3
17. Damp heat
Specified Value
Test Methods and
Remarks
MD series
Inductance change : Within ±10%
No significant abnormality in appearance.
The test samples shall be soldered to the test board by the reflow.
The test samples shall be placed in thermostatic oven set at specified temperature and humidity as shown in below table.
Temperature
60±2℃
Humidity
90～95%RH
Time
500＋24/－0 hour
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_smd_MD_reli_e-E04R01
18. Loading under damp heat
Specified Value
Test Methods and
Remarks
MD series
Inductance change : Within ±10%
No significant abnormality in appearance.
The test samples shall be soldered to the test board by the reflow.
The test samples shall be placed in thermostatic oven set at specified temperature and humidity and applied the rated current
continuously as shown in below table.
Temperature
60±2℃
Humidity
90～95％RH
Applied current
Rated current
Time
500＋24/－0 hour
19. Low temperature life test
Specified Value
Test Methods and
Remarks
MD series
Inductance change : Within ±10%
No significant abnormality in appearance.
The test samples shall be soldered to the test board by the reflow. After that, the test samples shall be placed at test conditions as shown
in below table.
Temperature
－40±2℃
Time
500＋24/－0 hour
20. High temperature life test
Specified Value
MD series
－
21. Loading at high temperature life test
Specified Value
Test Methods and
Remarks
MD series
Inductance change : Within ±10%
No significant abnormality in appearance.
The test samples shall be soldered to the test board by the reflow.
The test samples shall be placed in thermostatic oven set at specified temperature and applied the rated current continuously as shown in
below table.
Temperature
85±2℃
Applied current
Rated current
Time
500＋24/－0 hour
22. Standard condition
Specified Value
MD series
Standard test condition :
Unless otherwise specified, temperature is 20±15℃ and 65±20％of relative humidity.
When there is any question concerning measurement result: In order to provide correlation
data, the test shall be condition of 20±2℃ of temperature, 65±5% relative humidity.
Inductance is in accordance with our measured value.
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_smd_MD_reli_e-E04R01
METAL CORE SMD POWER INDUCTORS (MCOILTM MD SERIES）
■PRECAUTIONS
1. Circuit Design
Precautions
◆Operating environment
1. The products described in this specification are intended for use in general electronic equipment,(office supply equipment,
telecommunications systems, measuring equipment, and household equipment). They are not intended for use in mission-critical
equipment or systems requiring special quality and high reliability (traffic systems, safety equipment, aerospace systems, nuclear
control systems and medical equipment including life-support systems,) where product failure might result in loss of life, injury or
damage. For such uses, contact TAIYO YUDEN Sales Department in advance.
2. PCB Design
Precautions
Technical
considerations
◆Land pattern design
1. Please refer to a recommended land pattern.
◆Land pattern design
Surface Mounting
・ Mounting and soldering conditions should be checked beforehand.
・ Applicable soldering process to this products is reflow soldering only.
3. Considerations for automatic placement
Precautions
Technical
considerations
◆Adjustment of mounting machine
1. Excessive impact load should not be imposed on the products when mounting onto the PC boards.
2. Mounting and soldering conditions should be checked beforehand.
◆Adjustment of mounting machine
1. When installing products, care should be taken not to apply distortion stress as it may deform the products.
4. Soldering
Precautions
◆Reflow soldering
1. Please contact any of our offices for a reflow soldering, and refer to the recommended condition specified.
2. The product shall be used reflow soldering only.
3. Please do not add any stress to a product until it returns in normal temperature after reflow soldering.
◆Lead free soldering
1. When using products with lead free soldering, we request to use them after confirming adhesion, temperature of resistance to soldering
heat, soldering etc sufficiently.
◆Recommended conditions for using a soldering iron (NR10050 Type)
・ Put the soldering iron on the land-pattern.
・ Soldering iron's temperature - Below 350℃
・ Duration - 3 seconds or less
・ The soldering iron should not directly touch the inductor.
◆Reflow soldering
1. If products are used beyond the range of the recommended conditions, heat stresses may deform the products, and consequently
degrade the reliability of the products.
・NR30/40/50/60/80, NRV20/30, NRH24/30, NRS20/40/50/60/80 Type, NR10050 Type, NS101/125 Type
Recommended reflow condition (Pb free solder)
Technical
considerations
5. Cleaning
Precautions
Technical
considerations
◆Cleaning conditions
1. Washing by supersonic waves shall be avoided.
◆Cleaning conditions
1. If washed by supersonic waves, the products might be broken.
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_smd_MD_prec_e-E02R01
6. Handling
Precautions
◆Handling
1. Keep the product away from all magnets and magnetic objects.
◆Breakaway PC boards (splitting along perforations)
1. When splitting the PC board after mounting product, care should be taken not to give any stresses of deflection or twisting to the board.
2. Board separation should not be done manually, but by using the appropriate devices.
◆Mechanical considerations
1. Please do not give the product any excessive mechanical shocks.
2. Please do not add any shock and power to a product in transportation.
◆Pick-up pressure
1. Please do not push to add any pressure to a winding part. Please do not give any shock and push into a ferrite core exposure part.
◆Packing
1. Please avoid accumulation of a packing box as much as possible.
◆Board mounting
1. There shall be no pattern or via between terminals at the bottom of product.
2. Components which are located in peripheral of product shall not make contact with surface (top, side) of product.
Technical
considerations
◆Handling
1. There is a case that a characteristic varies with magnetic influence.
◆Breakaway PC boards (splitting along perforations)
1. The position of the product on PCBs shall be carefully considered to minimize the stress caused from splitting of the PCBs.
◆Mechanical considerations
1. There is a case to be damaged by a mechanical shock.
2. There is a case to be broken by the handling in transportation.
◆Pick-up pressure
1. Damage and a characteristic can vary with an excessive shock or stress.
◆Packing
1. If packing boxes are accumulated, that could cause a deformation on packing tapes or a damage on the products.
◆Board mounting
1. If there is pattern or via between terminals at the bottom of product, it may cause characteristics change.
2. If components which are located in peripheral of product make contact with surface (top, side) of product, it may cause damage or
characteristics change.
7. Storage conditions
Precautions
◆Storage
1. To maintain the solderability of terminal electrodes and to keep the packing material in good condition, temperature and humidity in the
storage area should be controlled.
・ Recommended conditions
Ambient temperature : －5～40℃
Humidity : Below 70% RH
・ The ambient temperature must be kept below 30℃. Even under ideal storage conditions, solderability of products electrodes may
decrease as time passes.
For this reason, product should be used within 6 months from the time of delivery.
In case of storage over 6 months, solderability shall be checked before actual usage.
Technical
considerations
◆Storage
1. Under a high temperature and humidity environment, problems such as reduced solderability caused by oxidation of terminal electrodes
and deterioration of taping/packaging materials may take place.
▶ This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
i_smd_MD_prec_e-E02R01
工商网监
湘ICP备2023018690号
