5103-05-01

(1/2) 3-terminal Filters(SIP) For Signal Line / Power Line ZJK, ZJKD Series FEATURES • These SIP type EMC filters provide superior attenuation capabilities from MF to VHF bands. They are particularly effective in the microcomputer frequency range, where they provide attenuation characteristics far superior to tantalum capacitors. • Its SIP type structure allows a wide variety of applications to IC substates. • The use of chip capacitors results in a high degree of miniaturization, enabling these parts to be used in high-density circuit board designs. • Transfer molding is used to strengthen types -00 and -05. APPLICATIONS OA equipment (Computers, terminal equipment, word processors, facsimiles, etc.) FA equipment (Robots, NC manufacturing machineries, process controllers, etc.) AE equipment (Automotive engine control units, etc.) HE equipment (Personal computers and micro computerized digital equipment) SHAPES AND DIMENSIONS ZJK-00-01 B Conformity to RoHS Directive CIRCUIT DIAGRAM ZJK-05-01 B ZJKD-15-01 B 1 A A 4 A C C 1 E F 23 4 C 1234 D 1234 D E FFF 2 3 E D FFF G F Dimensions in mm D 5+1, –2 5+0, –2 4.5±0.8 E 0.5× 0.25t 0.5× 0.25t 0.5× 0.3t F 5±0.3 2.5±0.3 2.5±0.3 G 2.5±0.3 — — Part No. A B C ZJK51R1-00-01, 51R5-00-01, 5103-00-01∗ 17±1 5±1 8±1 ZJK51R1-05-01, 51R5-05-01, 5103-05-01 12.5max. 4.5max. 8max. ZJKD51R1-15-01, 51R5-15-01, 5103-15-01 11.5max. 4.5max. 8max. ∗ The "-01" designation at the end of the product code indicates Lead-free compatible product. • -00 and -05 types:Transfer molding, -15 type: Dip molding ELECTRICAL CHARACTERISTICS Part No. Rated voltage Edc(V) max. Rated current(A) max. Withstand voltage Edc(V) [Between terminal No.1 to 2, No.3 to 4/5s] Insulation resistance(MΩ)min.[DC. 50V, 1 min] DC resistance(Ω)max.[Between terminal No.1 to 4] Operating temperature range(°C) 20dB Attenuation frequency range (MHz)[+5 to +35°C] 40dB Interchangeable with existing products ZJK51R1-00-01 ZJK51R5-00-01 ZJK5103-00-01 ZJK51R1-05-01 ZJKD51R1-15-01 50 50 50 50 0.1 0.5 3 0.1 125 100 11 –25 to +85 0.2 to 200 0.5 to 30 ZJK51R1-02 FP51R11 FP51R3 125 100 0.45 –25 to +85 1 to 200 2 to 30 ZJK51R5-01 ZJK51R5-02 125 100 0.02 –25 to +85 2 to 200 3 to 30 125 100 11 –25 to +85 0.7 to 300 1.5 to 80 ZJK51R5-05-01 ZJKD51R5-15-01 50 0.5 125 100 0.45 –25 to +85 4 to 300 7 to 80 ZJK5103-05-01 ZJKD5103-15-01 50 3 125 100 0.02 –25 to +85 7 to 300 15 to 80 • No application of this series component may exceed any of the above operational criteria. • Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications. • All specifications are subject to change without notice. 001-01 / 20060803 / e9644_zjk.fm (2/2) TYPICAL ELECTRICAL CHARACTERISTICS ATTENUATION vs. FREQUENCY CHARACTERISTICS ZJK-00-01 0 20 Attenuation (dB) 40 60 80 100 MEASURING CIRCUIT S.G. 1 50Ω 4 EMC filter L.M. 5103 51R5 51R1 2 3 Attenuation = 20 log10 0.1 0.3 1 3 10 30 Frequency (MHz) 100 300 1000 E2 ( ) dB E1 E 1: Set EMC filter in the circuit E 2: Leave EMC filter in the circuit 2, 3: GND terminals ZJK-05-01, ZJKD-15-01 0 20 Attenuation (dB) 40 60 80 100 51R1 51R5 PACKAGING QUANTITIES ZJK51R1-00-01 ZJK51R5-00-01 ZJK5103-00-01 ZJK51R1-05-01 ZJK51R5-05-01 ZJK5103-05-01 ZJKD51R1-15-01 ZJKD51R5-15-01 ZJKD5103-15-01 225 pieces 225 pieces 225 pieces 250 pieces 250 pieces 250 pieces 500 pieces 500 pieces 500 pieces 5103 0.1 0.3 1 3 10 30 Frequency (MHz) 100 300 1000 • All specifications are subject to change without notice. 001-01 / 20060803 / e9644_zjk.fm
