ATB322524-0110-T000

T R A N S F O R M E R S September 2013 Step-up Transformers Wound SMD ATB series ATB3225 [1210inch]* * Dimensions Code JIS[EIA] (2/7) T R A N S F O R M E R S REMINDERS FOR USING THESE PRODUCTS Before using these products, be sure to request the delivery specifications. SAFETY REMINDERS Please pay sufficient attention to the warnings for safe designing when using these products. REMINDERS The storage period is less than 6 months. Be sure to follow the storage conditions (Temperature: 5 to 40°C, Humidity: 10 to 75% RH or less). If the storage period elapses, the soldering of the terminal electrodes may deteriorate. Do not use or store in locations where there are conditions such as gas corrosion (salt, acid, alkali, etc.). Before soldering, be sure to preheat components. The preheating temperature should be set so that the temperature difference between the solder temperature and chip temperature does not exceed 150°C. Soldering corrections after mounting should be within the range of the conditions determined in the specifications. If overheated, a short circuit, performance deterioration, or lifespan shortening may occur. When embedding a printed circuit board where a chip is mounted to a set, be sure that residual stress is not given to the chip due to the overall distortion of the printed circuit board and partial distortion such as at screw tightening portions. Self heating (temperature increase) occurs when the power is turned ON, so the tolerance should be sufficient for the set thermal design. Carefully lay out the coil for the circuit board design of the non-magnetic shield type. A malfunction may occur due to magnetic interference. Use a wrist band to discharge static electricity in your body through the grounding wire. Do not expose the products to magnets or magnetic fields. Do not use for a purpose outside of the contents regulated in the delivery specifications. The products listed on this catalog are intended for use in general electronic equipment (AV equipment, telecommunications equipment, home appliances, amusement equipment, computer equipment, personal equipment, office equipment, measurement equipment, industrial robots) under a normal operation and use condition. The products are not designed or warranted to meet the requirements of the applications listed below, whose performance and/or quality require a more stringent level of safety or reliability, or whose failure, malfunction or trouble could cause serious damage to society, person or property. If you intend to use the products in the applications listed below or if you have special requirements exceeding the range or conditions set forth in the each catalog, please contact us. (1) Aerospace/Aviation equipment (2) Transportation equipment (cars, electric trains, ships, etc.) (3) Medical equipment (4) Power-generation control equipment (5) Atomic energy-related equipment (6) Seabed equipment (7) Transportation control equipment (8) Public information-processing equipment (9) Military equipment (10) Electric heating apparatus, burning equipment (11) Disaster prevention/crime prevention equipment (12) Safety equipment (13) Other applications that are not considered general-purpose applications When designing your equipment even for general-purpose applications, you are kindly requested to take into consideration securing protection circuit/device or providing backup circuits in your equipment. 001-01 / 20130910 / e6813_atb3225.fm (3/7) T R A N S F O R M E R S Step-up Transformers Halogen-free Compatible with lead-free solders Wound SMD Overview of the ATB Series FEATURES Compact step-up transformer developed for Xenon circuits. ATB3225 is smaller than conventional step-up transformers, which makes it possible to minimize the mounting area. Auto winding allows for stable winding so that stable charging characteristics can be acquired. Automated processing results in highly reliable products. APPLICATION Xenon Flash, HAPTICS PART NUMBER CONSTRUCTION ATB Series name 322515 L×W×T Dimensions (mm) 322515 3.2×2.5×1.5 322524 3.2×2.5×2.4 - 0110 - Turns ratio 0110 1:10 T T 000 Packaging style Internal code ø180mm reel OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT Temperature range Operating Storage Type temperature temperature （°C） （°C） ATB322515 –40 to +85°C –40 to +85°C ATB322524 –40 to +85°C –40 to +85°C Operating temperature range includes self-temperature rise. The Storage temperature range is for after the circuit board is mounted. Package quantity Individual weight （pieces/reel） 1,000 1,000 （mg） 50 80 Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm. • All specifications are subject to change without notice. 001-01 / 20130910 / e6813_atb3225.fm (4/7) T R A N S F O R M E R S Overview of the ATB Series RECOMMENDED REFLOW PROFILE Preheating Soldering Natural cooling Peak T: Temperature T4 T3 T2 T3 t3 T1 t1 t2 t: Time Preheating Temp. T1 T2 150°C 180°C Time t1 60 to 120s Soldering Temp. Time T3 t2 230°C 10 to 30s Peak Temp. T4 245°C Time t3 5s max. • All specifications are subject to change without notice. 001-01 / 20130910 / e6813_atb3225.fm (5/7) T R A N S F O R M E R S ATB series ATB3225 Type SHAPE & DIMENSIONS T 3.2±0.3 1.37 2.5±0.3 0.45 0.50 T 1.55max. 2.4max. Dimensions in mm RECOMMENDED LAND PATTERN 2.0 1.0 2 3 1 4 0.55 1.2 0.55 1.0 CIRCUIT DIAGRAM Dimensions in mm • All specifications are subject to change without notice. 001-01 / 20130910 / e6813_atb3225.fm (6/7) T R A N S F O R M E R S ATB series ATB3225 Type ELECTRICAL CHARACTERISTICS CHARACTERISTICS SPECIFICATION TABLE Turns ratio 1:10 1:10.2 Inductance (μH)[at100kHz] 7.0±20% 7.0±20% DC resistance (: ) Primary Secondary 0.5max. 60max. 0.5max. 60max. ○ Measurement equipment Measurement item Product No. Inductance 4284A DC resistance 4338A Leakage inductance 4284A Withstanding voltage 4339A ＊ Equivalent measurement equipment may be used. Leakage inductance (μH)[at100kHz] 0.4max. 0.4max. Withstanding voltage 500V rms 500V rms Rated current Part No. 0.6A rms 0.7A rms ATB322515-0110-T000 ATB322524-0110-T000 Manufacturer Agilent Technologies Agilent Technologies Agilent Technologies Agilent Technologies INDUCTANCE VS. DC BIAS CHARACTERISTICS 10 9 Inductance primary (μH) 8 7 6 ATB322524 5 4 ATB322515 3 2 1 0 0 100 200 300 400 500 600 700 800 900 DC current (mA) 1000 1100 1200 1300 1400 1500 ○ Measurement equipment Product No. Manufacturer 4284A Agilent Technologies ＊ Equivalent measurement equipment may be used. • All specifications are subject to change without notice. 001-01 / 20130910 / e6813_atb3225.fm (7/7) T R A N S F O R M E R S ATB series Packaging style REEL DIMENSIONS 2.0±0.5 E A W1 ø180+0/–1.5 9+1/–0 ø180+0/–1.5 9+1/–0 W2 13±1 13±1 N 60+1/–0 60+1/–0 E 2 typ. 2 typ. N Type ATB322515 ATB322524 1.0 ø13.0±0.2 W1 ø21.0±0.8 W2 A Dimensions in mm TAPE DIMENSIONS P2 P0 W B F E øD0 A K P1 Dimensions in mm Type ATB322515 ATB322524 A 2.9±0.1 2.9±0.1 B 3.6±0.1 3.6±0.1 øD0 1.5+0.1/0 1.5+0.1/0 E F 1.75±0.1 3.5±0.05 1.75±0.1 3.5±0.05 P0 4.0±0.1 4.0±0.1 P1 4.0±0.1 4.0±0.1 P2 2.0±0.05 2.0±0.05 W 8.0±0.2 8.0±0.2 K 1.6±0.05 2.5±0.05 500 to 560min. 160min. Taping 440min. Drawing direction Dimensions in mm • All specifications are subject to change without notice. 001-01 / 20130910 / e6813_atb3225.fm
