I N D U C T O R S April 2018 Inductors for power circuits Multilayer ferrite MLP series MLP2520 type MLP2520 2520 [1008 inch]* * Dimensions Code JIS[EIA] Caution The products in this catalog is not recommended to a new design (2/20) I N D U C T O R S Products in this catalog are in preparation for mass production. Part No. MLP2520H1R0ST0S1 MLP2520H2R2ST0S1 MLP2520H4R7ST0S1 MLP2520VR47MT0S1 Status Not recommended Not recommended Not recommended Not recommended to a new design to a new design to a new design to a new design Please refer to our Web site about replacement information. 20180426 / inductor_commercial_power_mlp2520_en.fm (3/20) I N D U C T O R S REMINDERS FOR USING THESE PRODUCTS Before using these products, be sure to request the delivery specifications. SAFETY REMINDERS Please pay sufficient attention to the warnings for safe designing when using these products. REMINDERS The storage period is less than 12 months. Be sure to follow the storage conditions (Temperature: 5 to 40°C, Humidity: 10 to 75% RH or less). If the storage period elapses, the soldering of the terminal electrodes may deteriorate. Do not use or store in locations where there are conditions such as gas corrosion (salt, acid, alkali, etc.). Before soldering, be sure to preheat components. The preheating temperature should be set so that the temperature difference between the solder temperature and chip temperature does not exceed 150°C. Soldering corrections after mounting should be within the range of the conditions determined in the specifications. If overheated, a short circuit, performance deterioration, or lifespan shortening may occur. When embedding a printed circuit board where a chip is mounted to a set, be sure that residual stress is not given to the chip due to the overall distortion of the printed circuit board and partial distortion such as at screw tightening portions. Self heating (temperature increase) occurs when the power is turned ON, so the tolerance should be sufficient for the set thermal design. Carefully lay out the coil for the circuit board design of the non-magnetic shield type. A malfunction may occur due to magnetic interference. Use a wrist band to discharge static electricity in your body through the grounding wire. Do not expose the products to magnets or magnetic fields. Do not use for a purpose outside of the contents regulated in the delivery specifications. The products listed on this catalog are intended for use in general electronic equipment (AV equipment, telecommunications equipment, home appliances, amusement equipment, computer equipment, personal equipment, office equipment, measurement equipment, industrial robots) under a normal operation and use condition. The products are not designed or warranted to meet the requirements of the applications listed below, whose performance and/or quality require a more stringent level of safety or reliability, or whose failure, malfunction or trouble could cause serious damage to society, person or property. If you intend to use the products in the applications listed below or if you have special requirements exceeding the range or conditions set forth in the each catalog, please contact us. (1) Aerospace/Aviation equipment (2) Transportation equipment (cars, electric trains, ships, etc.) (3) Medical equipment (4) Power-generation control equipment (5) Atomic energy-related equipment (6) Seabed equipment (7) Transportation control equipment (8) Public information-processing equipment (9) Military equipment (10) Electric heating apparatus, burning equipment (11) Disaster prevention/crime prevention equipment (12) Safety equipment (13) Other applications that are not considered general-purpose applications When designing your equipment even for general-purpose applications, you are kindly requested to take into consideration securing protection circuit/device or providing backup circuits in your equipment. 20180426 / inductor_commercial_power_mlp2520_en.fm (4/20) I N D U C T O R S Product compatible with RoHS directive Halogen-free Compatible with lead-free solders Inductors for power circuits Multilayer ferrite Overview of MLP2520 type FEATURES A low-loss magnetic material is used so that a low-loss inductor for the power supply circuit can be achieved. In addition to the inductance value, product types with various features are available so that they can be compatible with different usages. W Type: Products with low DC resistance and large current. H Type: This product uses a low-loss material and has low DC resistance. * Optimal for when heavy load power efficiency is important. V Type: As with the H type, this product with a low-loss magnetic material and that has good DC superimposition type characteristics. * Optimal for when light load power efficiency is important. S Type: STD product lineup that includes a wide L value and various sizes. APPLICATION Smart phones, tablet terminals, digital cameras, video cameras, HDDs, power supply modules, etc. PART NUMBER CONSTRUCTION MLP 2520 W R47 M T 0S1 Series name L×W Dimensions (mm) Characteristic type Inductance (µH) Height (mm max.) Packaging style Internal code T 2520 2.5×2.0 W Large current, low resistance H Low core loss (Emphasized DC resistance) V Low core loss (Emphasized DC bias characteristics) S STD product R47 0.47 M 1.0 1R0 1.0 S 1.2 100 Taping 0S1 10 OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT Temperature range Type Operating temperature （°C） Package quantity Individual weight (pieces/reel) （mg） 15 25 Storage temperature （°C） t=1.0 –40 to +125 –40 to +85 t=1.2 Operating temperature range includes self-temperature rise. The Storage temperature range is for after the circuit board is mounted. MLP2520 3,000 RoHS Directive Compliant Product: See the following for more details.https://product.tdk.com/info/en/environment/rohs/index.html Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (5/20) I N D U C T O R S MLP2520 type RECOMMENDED REFLOW PROFILE Preheating Soldering Natural cooling Peak T: Temperature T4 T3 T2 T3 t3 T1 t1 t2 t: Time Preheating Temp. T1 T2 150°C 180°C Time t1 60 to 120s Soldering Temp. Time T3 t2 230°C 30 to 60s Peak Temp. T4 250 to 260°C Time t3 10s max. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (6/20) I N D U C T O R S MLP2520 type 2.00±0.15 SHAPE & DIMENSIONS 0.50±0.30 0.50±0.30 T 2.50±0.15 T 0.85±0.15 1.10±0.10 Dimensions in mm RECOMMENDED LAND PATTERN 1.4 0.7 2.0 0.7 Dimensions in mm Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (7/20) I N D U C T O R S MLP2520 type ELECTRICAL CHARACTERISTICS CHARACTERISTICS SPECIFICATION TABLE Type Large current Low resistance Emphasized low resistance Low core loss Emphasized DC bias characteristics STD product Thickness L T (mm)max. 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.2 1.2 1.2 1.0 1.0 1.0 1.0 1.0 1.0 1.2 1.2 1.2 1.2 1.0 1.0 1.0 1.0 1.0 1.0 1.2 1.2 1.2 1.2 1.2 (µH) 0.47 0.68 1.0 1.5 2.2 3.3 4.7 0.47 1.0 2.2 3.3 4.7 1.0 2.2 4.7 0.47 1.0 1.5 2.2 3.3 4.7 1.0 1.5 2.2 4.7 1.0 1.5 2.2 3.3 4.7 10.0 1.2 2.5 3.3 4.7 10.0 tolerance ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% ±20% Measuring frequency DC resistance Rated current Part No. (MHz) 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 ()±30% 0.033 0.040 0.048 0.075 0.16 0.16 0.15 0.044 0.075 0.09 0.13 0.13 0.07 0.08 0.13 0.06 0.10 0.10 0.12 0.20 0.24 0.10 0.10 0.12 0.22 0.085 0.09 0.09 0.13 0.13 0.28 0.08 0.11 0.11 0.11 0.28 MLP2520WR47MT0S1 MLP2520WR68MT0S1 MLP2520W1R0MT0S1 MLP2520W1R5MT0S1 MLP2520W2R2MT0S1 MLP2520W3R3MT0S1 MLP2520W4R7MT0S1 MLP2520HR47MT0S1 MLP2520H1R0MT0S1 MLP2520H2R2MT0S1 MLP2520H3R3MT0S1 MLP2520H4R7MT0S1 MLP2520H1R0ST0S1 MLP2520H2R2ST0S1 MLP2520H4R7ST0S1 MLP2520VR47MT0S1 MLP2520V1R0MT0S1 MLP2520V1R5MT0S1 MLP2520V2R2MT0S1 MLP2520V3R3MT0S1 MLP2520V4R7MT0S1 MLP2520V1R0ST0S1 MLP2520V1R5ST0S1 MLP2520V2R2ST0S1 MLP2520V4R7ST0S1 MLP2520S1R0MT0S1 MLP2520S1R5MT0S1 MLP2520S2R2MT0S1 MLP2520S3R3MT0S1 MLP2520S4R7MT0S1 MLP2520S100MT0S1 MLP2520S1R0ST0S1 MLP2520S2R2ST0S1 MLP2520S3R3ST0S1 MLP2520S4R7ST0S1 MLP2520S100ST0S1 (mA)max. 2900 2800 2300 1800 1200 1200 1200 2100 1500 1300 1100 1000 1600 1500 1000 1700 1300 1400 1100 900 800 1300 1400 1100 800 1500 1200 1200 1000 1000 700 1500 1200 1000 1000 700 Background yellow: The product which is not recommended to a new design.  Rated current: Current assumed when temperature has risen to 40°C max. ○ Measurement equipment Measurement item Product No. L 4294A+16034G DC resistance Type-7561 ＊ Equivalent measurement equipment may be used. Manufacturer Keysight Technologies Yokogawa Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (8/20) I N D U C T O R S MLP2520 type (W characteristic product, T dimension of the product 1.0mm max.) ELECTRICAL CHARACTERISTICS L FREQUENCY CHARACTERISTICS GRAPH 10.0 9.0 8.0 Inductance(µH) 7.0 6.0 4.7µH 5.0 4.0 3.3µH 3.0 2.2µH 2.0 1.0µH 1.5µH 1.0 0.68µH 0.47µH 0.0 0.1 1 10 100 Frequency(MHz) ○ Measurement equipment Product No. Manufacturer 4294A+16034G Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (9/20) I N D U C T O R S MLP2520 type (W characteristic product, T dimension of the product 1.0mm max.) ELECTRICAL CHARACTERISTICS INDUCTANCE VS. DC BIAS CHARACTERISTICS GRAPH 6.0 Inductance(µH) 5.0 4.7µH 4.0 3.3µH 3.0 2.2µH 2.0 1.5µH 1.0 1.0µH 0.68µH 0.47µH 0.0 0.0 1.0 2.0 3.0 DC current(A) ○ Measurement equipment Product No. Manufacturer 4285A+42841A+42842C+42851-61100 Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (10/20) I N D U C T O R S MLP2520 type (H characteristic product, T dimension of the product 1.0mm max.) ELECTRICAL CHARACTERISTICS L FREQUENCY CHARACTERISTICS GRAPH 12.0 Inductance(µH) 10.0 8.0 6.0 4.7µH 4.0 3.3µH 2.0 2.2µH 1.0µH 0.47µH 0.0 0.1 1 10 100 Frequency(MHz) ○ Measurement equipment Product No. Manufacturer 4294A+16034G Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (11/20) I N D U C T O R S MLP2520 type (H characteristic product, T dimension of the product 1.0mm max.) ELECTRICAL CHARACTERISTICS INDUCTANCE VS. DC BIAS CHARACTERISTICS GRAPH 6.0 5.0 4.0 3.0 2.0 1.0 0.0 0 200 400 600 DC current(mA) 800 1000 1200 ○ Measurement equipment Product No. Manufacturer 4285A+42841A+42842C+42851-61100 Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (12/20) I N D U C T O R S MLP2520 type (V characteristic product, T dimension of the product 1.0mm max.) ELECTRICAL CHARACTERISTICS L FREQUENCY CHARACTERISTICS GRAPH 12.0 Inductance(µH) 10.0 8.0 6.0 4.7µH 4.0 3.3µH 1.0µH 2.2µH 2.0 1.5µH 0.47µH 0.0 0.1 1 10 100 Frequency(MHz) ○ Measurement equipment Product No. Manufacturer 4294A+16034G Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (13/20) I N D U C T O R S MLP2520 type (V characteristic product, T dimension of the product 1.0mm max.) ELECTRICAL CHARACTERISTICS INDUCTANCE VS. DC BIAS CHARACTERISTICS GRAPH 6.0 5.0 4.0 3.0 2.0 1.0 0.0 0 200 400 600 DC current(mA) 800 1000 1200 ○ Measurement equipment Product No. Manufacturer 4285A+42841A+42842C+42851-61100 Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (14/20) I N D U C T O R S MLP2520 type (V characteristic product, T dimension of the product 1.2mm max.) ELECTRICAL CHARACTERISTICS L FREQUENCY CHARACTERISTICS GRAPH 12.0 Inductance(µH) 10.0 8.0 6.0 4.7µH 4.0 2.2µH 2.0 1.5µH 1.0µH 0.0 0.1 1 10 100 Frequency(MHz) ○ Measurement equipment Product No. Manufacturer 4294A+16034G Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (15/20) I N D U C T O R S MLP2520 type (V characteristic product, T dimension of the product 1.2mm max.) ELECTRICAL CHARACTERISTICS INDUCTANCE VS. DC BIAS CHARACTERISTICS GRAPH 6.0 5.0 Inductance(µH) 4.7µH 4.0 3.0 2.2µH 2.0 1.5µH 1.0µH 1.0 0.0 0 250 500 750 DC current(mA) 1000 1250 1500 ○ Measurement equipment Product No. Manufacturer 4285A+42841A+42842C+42851-61100 Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (16/20) I N D U C T O R S MLP2520 type (S characteristic product, T dimension of the product 1.0mm max.) ELECTRICAL CHARACTERISTICS L FREQUENCY CHARACTERISTICS GRAPH 14.0 12.0 10µH Inductance(µH) 10.0 8.0 6.0 4.7µH 4.0 3.3µH 1.5µH 2.0 2.2µH 1.0µH 0.0 0.1 1 10 100 Frequency(MHz) ○ Measurement equipment Product No. Manufacturer 4294A+16034G Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (17/20) I N D U C T O R S MLP2520 type (S characteristic product, T dimension of the product 1.0mm max.) ELECTRICAL CHARACTERISTICS INDUCTANCE VS. DC BIAS CHARACTERISTICS GRAPH 14.0 12.0 10.0 8.0 6.0 4.0 2.0 0.0 0 200 400 600 DC current(mA) 800 1000 1200 ○ Measurement equipment Product No. Manufacturer 4285A+42841A+42842C+42851-61100 Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (18/20) I N D U C T O R S MLP2520 type (S characteristic product, T dimension of the product 1.2mm max.) ELECTRICAL CHARACTERISTICS L FREQUENCY CHARACTERISTICS GRAPH 14.0 12.0 10µH Inductance(µH) 10.0 8.0 6.0 4.7µH 4.0 3.3µH 2.2µH 2.0 1.0µH 0.0 0.1 1 10 100 Frequency(MHz) ○ Measurement equipment Product No. Manufacturer 4294A+16034G Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (19/20) I N D U C T O R S MLP2520 type (S characteristic product, T dimension of the product 1.2mm max.) ELECTRICAL CHARACTERISTICS INDUCTANCE VS. DC BIAS CHARACTERISTICS GRAPH 14.0 12.0 10.0 8.0 6.0 4.0 2.0 0.0 0 200 400 600 DC current(mA) 800 1000 1200 ○ Measurement equipment Product No. Manufacturer 4285A+42841A+42842C+42851-61100 Keysight Technologies ＊ Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm (20/20) I N D U C T O R S MLP2520 type PACKAGING STYLE REEL DIMENSIONS ø60min. 1.0 2.0±0.5 8.4 +2.0 –0.0 ø13±0.2 14.4max. ø21±0.8 ø180±2.0 Dimensions in mm Cavity 3.5±0.05 1.5 +0.1 –0.0 Type MLP2520 A 2.7±0.1 B 2.3±0.2 K 1.5max. A 8.0±0.3 Sprocket hole 1.75±0.1 TAPE DIMENSIONS K B 4.0±0.1 2.0±0.05 160min. Drawing direction Taping 2.0±0.05 200min. 300min. Dimensions in mm Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. Please note that the contents may change without any prior notice due to reasons such as upgrading. 20180426 / inductor_commercial_power_mlp2520_en.fm
