(1/2)
Chip Beads(SMD) For Power Line
MPZ Series MPZ1005 Type
FEATURES • TDK has manufactured MPZ1005 type as EMI countermeasure product for power line. • This type is the best for energy-saving in the low DC resistance. • No cross talk with closed magnetic circuit structural design. • It is a product conforming to RoHS directive. APPLICATIONS USB, cellular phones, HDDs, CD-ROMs, DVDs, DSCs, LCD panels, etc. PRODUCT IDENTIFICATION MPZ 1005 S 121 C T (1) (2) (3) (4) (5) (6) (1) Series name (2) Dimensions L× W (3) Material code (4) Nominal impedance [at 100MHz] (5) Characteristic type (6) Packaging style T:Taping(reel) RECOMMENDED SOLDERING CONDITION REFLOW SOLDERING
Conformity to RoHS Directive
SHAPES AND DIMENSIONS/RECOMMENDED PC BOARD PATTERN
1± 0.05 0.5 ± 0.05 0.5 0.1min. 0.5 ± 0.05 0.45 0.5 0.45 Weight: 1mg Dimensions in mm
TEMPERATURE RANGES
Operating/storage –40 to +85°C
PACKAGING STYLE AND QUANTITIES
Packaging style Taping Quantity 10000 pieces/reel
10s max. 250 to 260˚C 230˚C Natural cooling
180˚C 150˚C Preheating 60 to 120s Time(s) Soldering 30 to 60s
HANDLING AND PRECAUTIONS • Before soldering, be sure to preheat components. The preheating temperature should be set so that the temperature difference between the solder temperature and product temperature does not exceed 150°C. • After mounting components onto the printed circuit board, do not apply stress through board bending or mishandling. • The inductance value may change due to magnetic saturation if the current exceeds the rated maximum. • Do not expose the inductors to stray magnetic fields. • Avoid static electricity discharge during handling. • When hand soldering, apply the soldering iron to the printed circuit board only. Temperature of the iron tip should not exceed 350°C. Soldering time should not exceed 3 seconds.
ELECTRICAL CHARACTERISTICS
Part No. MPZ1005S100C MPZ1005S300C MPZ1005S600C MPZ1005S121C
∗
Impedance (Ω)[100MHz]∗ 10±5Ω 30±10Ω 60±25% 120±25%
DC resistance (Ω)max. 0.045 0.050 0.075 0.090
Rated current (A)max. 2.0 1.7 1.5 1.2
Test equipment: E4991A or equivalent Test tool: 16192A or equivalent
• Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications. • Please contact our Sales office when your application are considered the following: The device’s failure or malfunction may directly endanger human life (e.g. application for automobile/aircraft/medical/nuclear power devices, etc.)
• All specifications are subject to change without notice. 001-05 / 20061022 / e9413_mpz1005.fm
(2/2)
TYPICAL ELECTRICAL CHARACTERISTICS Z, X, R vs. FREQUENCY CHARACTERISTICS MPZ1005S100C MPZ1005S300C
20 18 16 14 12 10 8 6 4 2 0 60 50 Impedance (Ω) Z R 40 30 20 10 10000 0 1 10 X 100 1000 Frequency (MHz) 10000 Z R
MPZ1005S600C
100 90 80 70 60 50 40 30 20 10 0
Impedance (Ω)
Impedance (Ω)
Z
R
X 1 10 100 1000 Frequency (MHz)
X 1 10 100 1000 Frequency (MHz) 10000
MPZ1005S121C
200 180 160 140 120 100 80 60 40 20 0
Impedance (Ω)
Z R X
1
10
100 1000 Frequency (MHz)
10000
PACKAGING STYLES REEL DIMENSIONS
TAPE DIMENSIONS
Sprocket hole 1.5 +0.1 –0.0 Cavity 1.75±0.1 300min. Dimensions in mm 1.15±0.1 3.5±0.05 8.0±0.3 0.8max. 0.65± 0.1 4.0± 0.1 2.0± 0.05 2.0± 0.05 160min. Taping 200min.
1.0
2.0± 0.5 ø13± 0.5 ø21± 0.8 ø178± 2.0
9.0± 0.3 13.0± 1.4
ø60± 2.0 Dimensions in mm
Drawing direction
• All specifications are subject to change without notice. 001-05 / 20061022 / e9413_mpz1005.fm
