16F-100

16F(R) SERIES STANDARD RECOVERY DIODE VRRM = 100-1200V, IF(AV) = 16A ,VF = 1.23 Volt. Symbol A Cathode to Stud Shown (Anode to Stud add Suffix R) K MAXIMUM RATINGS (Tj = 25 C unless stated otherwise) O Add Prefix"A" for avalanche 400-1200V 16F(R) -10 100 16F(R) -20 200 16F(R) -40 400 16F(R) -60 600 16F(R) -80 800 O Symbol Parameter Repetitive Peak Reverse Voltage Maximum Average On-State Current Peak Forward Surge Current 8.3mS Maximum I 2T for Fusing 8.3ms Maximum Storage Temperature Range Maximum Junction Temperature Range VRRM IF(AV) IFSM I2T T(STG) Tj 16F(R) -100 1000 16F(R) -120 1200 Unit Volt Amp Amp 16.0 at tc = 140 C 310 395 -65 to +200 -65 to +175 A2/S O C C O ELECTRICAL CHARACTERISICS at Parameter Maximum Forward Voltage Repetitive Peak Reverse Current Tj = 25 C Maximum. Unless stated Otherwise Condition Symbol VFM IRRM PR RTH (J-c) MT Wt IFM = 50 Amps VR = VRRM. tJ=175OC tp= 10µs rect wave at tj Max Value Min Typ Max 1.23 12.0 12.0 15 1.6 1.2 7.0 Unit Volt mA kW O Maximum non-repetitive peak reverse power (Avalanche Version) Thermal Resistance (Junction to Case) Mounting Torque Weight C/W NM grms a b c Dim a b c d e f g j h j k m DIMENSIONS Millimetres Inches Min Max Min Max 12.82 0.505 0.020 0.424 0.065 0.437 0.310 0.413 0.100 0.51 1.65 10.77 11.20 7.87 10.49 2.54 4.44 20.82 11.50 10.29 e d f 0.060 0.075 1.53 Polarity Symbol g 0.175 1.91 10 -32 UNF3A 0.600 0.820 15.24 0.453 10.72 0.405 0.422 m k h MetalCase DO-4
