50PF-80

50PF(R) Series STANDARD RECOVERY DIODE VRRM = 400-1200V, IF(AV) = 50Amp. Symbol A K Cathode to Stud Shown (Anode to Stud add Suffix R) MAXIMUM RATINGS Parameter (Tj = 25 C unless stated otherwise) 50PF(R) -40 50PF(R) -80 50PF(R) -120 Symbol VRRM IF(AV) IFSM I2T T(STG) Tj Unit Volt Amp Amp Repetitive Peak Reverse Voltage Maximum Average On-State Current Peak Forward Surge Current 8.3mS Maximum I 2T for Fusing 8.3ms Maximum Storage Temperature Range Maximum Junction Temperature Range 400 800 O 1200 50 at TC= 140 C 700 2050 -55 to +180 -55 to +180 A2/S O C C O ELECTRICAL CHARACTERISICS at Parameter Tj = 25 C Maximum. Unless stated Otherwise Condition Symbol Min IFM =125 Amps TP = 400µS rect. wave VR = VRRM, tj= 150 C O Value Typ Max 1.40 9.0 0.51 3.4 15.8 Unit Volt mA O Maximum Forward Voltage Repetitive Peak Reverse Current Thermal Resistance (Junction to Case) Mounting Torque Weight VFM IRRM RTH (J-c) MT Wt C/W NM grms Mechanical Outline 0.90 (0.03) 17.25 (0.68) 0 4.0 (0.16) Min 7.0 (0.27) max 6.1 (0.84) min 10.20 (0.401) min 11.4 (0.45) max 14.86 (0.585) Max 12.80 (0.0.503) Min C L 4.0 (0.16) min 25.4 (1.00) max 10.6 (0.42) min 11.4 (0.46) max 1/4" 28 UNF - 2A Metric M6 x 1 Case: DO-203AB (DO-5) Case: Metal/ Glass to Metal Seal All Dimensions in Millimeters (Inches)
