10-00240

ITEM NO. 1 PART NUMBER 50-00425 DESCRIPTION QTY. 1 2 50-00024 3 30-00008 Wire, 2C BC, 22 AWG, UL2468, 300V, 80C, 3.6 mm, PVC, 87A 1 4 24-00023 Overmold, PVC, black 1 5 24-00043 Overmold, PVC, black 1 6 Label 240 Adhesive, flag, 15x65 mm 1 Connector, plug, USB A Connector, dc plug, 5.5x2.1xL23 mm, molding style, spring contacts NOTES 1 1830 ±50 12 ±0.50 20 ±5 12 ±0.50 4 9. 3 2.1 3.6 5. 5 1 1 4 3 6 5 2 65 Electical requirement: 1 A, 5 Vdc A Date: 11/10/2009 Description: Prepared: 2016.02.15 GL Initial release Verified: 15:22:23 -08'00' A1 3/16/2010 Added label drawing LA A2 9/06/2011 Updated specifications A3 8/08/2012 Added label specs, updated wire part number Dimensions are in millimeters. Tolerances: 0.5 mm X: X.X: 0.3 mm X.XX: 0.05 mm 5 1 2 3 4 P/N 10-00240 LABEL Hi-Pot test: 600 Vac, 0.5 mA, 1 second Revision: 50-00425 TENSILITY tensility.com Made in China 15 Notes: Wiring diagram 4 Digitally signed by LA DN: cn=LA, o=Tensility, ou=Engineering, email=QA002@Tensility.com, c=US Date: 2016.02.15 15:33:05 -08'00' Wire Color 50-00024 Black with stripe N.C. N.C. Black Center Sleeve Notes: RoHS compliant Function test: no open, no short circuit, no intermittent tel fax Description: Cable, 1830 mm, USB A plug to 5.5x2.1x12 mm 5000024 plug, center pos, 22 AWG, UL2468, 30-00008 wire 3 2 1.541.323.3228 1.541.323.4202 Size: Part number: A 10-00240 Scale: 800 web 877.670.7118 tensility.com Sheet 1 of 1 1:1 1
