BT136-600

TIGER ELECTRONIC CO.,LTD BT136-600 GENERAL DESCRIPTION Passivated, sensitive gate triacs in a plastic envelope, intended for use in general purpose bidirectional switching and phase control applications, where high sensitivity is required in all four quadrants. ABSOLUTE MAXIMUM RATINGS ( Ta = 25 OC) Parameter Repetitive peak off-state voltages RMS on-state current Non-repetitive peak on-state current Max. Operating Junction Temperature Storage Temperature Symbol VDRM VRRM IT(RMS) ITSM Tj Tstg Typ 600 4.0 25 110 -45~150 Unit V A A o C C o TO-220 ELECTRICAL CHARACTERISTICS ( Ta = 25 C) Parameter Repetitive peak off-state voltages RMS on-state current On-state voltage Holding current T2+G+ Gate trigger current T2+GT2-GT2-G+ T2+G+ Latching current T2+GT2-GT2-G+ Gate trigger voltage VGT VD = 12 V; IT = 0.1 A IL VD = 12 V; IGT = 0.1 A IGT VD = 12 V; IT = 0.1 A Symbol VDRM VRRM IT(RMS) VT IH full sine wave; Tmb IT=5A VD = 12 V; IGT = 0.1 A 107 oC Test Conditions Min Typ 600 4 1.4 2.2 2.5 4.0 5.0 11 3.0 10 2.5 4.0 0.7 1.7 15 10 10 10 25 15 20 15 20 1.5 V mA mA Max Unit V A V mA O
