MECHATRO N I C D R I V E S W I T H S T E P P E R M O T O R
P A Nd r i ves
P D- 0 13 - 4 2
42mm / N EMA1 7 Step per Moto r wi th Step / D irec tion Dri ver
1 0 mm
M A IN CH A R AC T ER IS T IC S
INFO
The PD-013-42 is a full mechatronic solution including a 42 mm flange motor. It joins a convenient controller electronic with a range of different motor torques. The PD-013-42 offers three motor torques options and can be controlled via an optical isolated Step / Direction interface. The power supply, interface and the multi purpose I/Os can be connected with small JST connectors. The firmware of the module can be updated via the serial interface. With the integrated stallGuard™ feature it is possible to detect overload and stall of the motor.
ELECTRICAL D ATA MOTOR TYPES
• 7V to 30V supply voltage • motor length: 53 mm / 59 mm / 69 mm: max. torque 0.27Nm / 0.35Nm / 0.49Nm • Step / Direction input (5 – 24V signal) with up to 350kHz microstep frequency • driver disable input • RS485 host interface (optional use / use for parameterization) • 2 local inputs for reference switches • optically isolated inputs for step, direction and disable • up to 256 times adjustable microstep resolution • adjustable standby current • reference move and turn CW / CCW via RS-485 • stallGuard™ for reference search • ASCII protocol controlled using simple terminal software • pluggable connectors for all signals / cable included • RoHS compliant
INTERFACE
FEATURES
SOFTWARE
PD-013-42
RS-485
OTHER
Step/Dir
Opto isolation
Sequencer
programmable
Driver
TMC246
Step Motor
REFSwitches
7..30V DC
5V Power Supply
2
OR DE R C O DE
D E S C RI P T I ON
PD1-013-42 P D2-013-42 P D3-013-42
PANdrive 0.27 Nm with QSH4218-35-10-027 motor and step / direction PANdrive 0.35 Nm with QSH4218-41-10-035 motor and step / direction PANdrive 0.49 Nm with QSH4218-51-10-049 motor and step / direction
www.trinamic.com – for detailed information and datasheets
