3F-24-150

TRUMPower D E S C R IP T IO N T he 3F/3RF is a series of fan-less AC/DC switching power adapters with 150 watts of continuous output power. The units are enclosed in a 94V-1 rated polyphenylene-oxide case with an IEC 320/C14 or IEC320/C6 AC inlet to mate with interchangeable cord for world-wide use. All model meet CISPR 22 and FCC class B emission limits, and comply with UL, CSA, IEC and CE requirements. 150 WATT POWER ADAPTERS 3F/3RF SERIES RoHS F E AT U R E S ‧ High efficiency ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ Low ripple & noise O v e r v o l ta g e p r o t e c t i o n Short-circuit protection Overpow er protection Over temperature protection 100% burn-in at full rated load S ta n d b y c o n s u m p t i o n l e s s t h a n 1 W C o m p l i a n t w i t h R o H S r e q u i r e m e n ts S a f e t y Sta n d a r d A p p r o va l s ： UL 60950-1 CSA C22.2 No. 60950-1 I N P U T S P E C I F I C AT I O N S I n p u t v o l ta g e ： Input frequency： Input current： Earth leakage current: 9 0 t o 2 6 4 VA C 47 to 63 Hz 2 . 0 A （ r m s ） f o r 11 5 VA C 1 . 0 A （ r m s ） f o r 2 3 0 VA C 1 5 0 µ A m a x . @ 11 5 VA C , 6 0 H z 2 5 0 µ A m a x . @ 2 3 0 VA C , 5 0 H z Nemko EN60950: 2000 G ENERAL SPECIFICATIONS H old-up time: 3 m sec minimum at 100VAC Turn on delay time: 5 seconds maximum at 100VAC P ower factor: 0 .95 typical E fficiency: L ine regulation: I nrush current: Withstand voltage: M TBF: 8 8% min. ± 0.5% maximum at full load 6 0A @ 115VAC or 100A @ 230VAC, at 25ºC cold star 3 000VAC from input to output 1500VAC from input to ground 1 50,000 hours at full load at 25ºC ambient, calculated per MIL-HDBK- 217F O UTPUT SPECIFICATIONS O utput voltage/current: Total output power: R ipple and noise: O vervoltage protection: O vercurrent protection: Temperature coefficient: Transient response: S ee rating chart S ee rating chart 3 80mV peak to peak maximum S et at 110-140% of its nominal output voltage A ll models protected to short circuit conditions A ll outputs ±0.04%/ºC maximum M aximum excursion of 4% or better on all models, recovering to 1% of final value within 500µs after a 25% step load change E MC Performance (EN55024) EN55022: FCC: VCCI: EN61000-3-2: EN61000-3-3: EN61000-4-2: EN61000-4-3: EN61000-4-4: EN61000-4-5: EN61000-4-6: EN61000-4-8: E N 6 1 0 0 0 - 4 - 11 : C lass B conducted, Class B radiated C lass B conducted, Class B radiated C lass B conducted, Class B radiated H armonic distortion, Class D Line flicker ESD, ±8KV air and ±4KV contact R a d i a t e d i m m u n i t y, 3 V / m Fast transient/burst, ±1KV Surge, ±1KV diff, ±2KV com. C o n d u c t e d i m m u n i t y, 3 Vr m s M a g n e t i c f i e l d i m m u n i t y, 1 A / m Vo l t a g e d i p s , 3 0 % r e d u c t i o n f o r 500ms and >95% reduction for 10ms E N V I R O N M E N TA L S P E C I F I C AT I O N S Operating temperature: 0ºC to +40ºC Storage temperature: -20ºC to +80ºC Relative humidity: 10% to 90% non-condensing Tumbler Technologies + TRUMPower 3350 Scott Blvd., Bldg. 13, Santa Clara, California 95054, USA Phone: 408-988-6616 ● Fax: 408-988-6622 ● email: sales@trumpower.com ● Website: www.TRUMPower.com UNIVERSAL INPUT OUTPUT VOLTAGE/CURRENT RATING CHART Product No. IEC 320/C14 Inlet 3F-12-150 3F-15-150 3F-19-150 3F-20-150 3F-24-150 N OTE: IEC 320/C6 Inlet 3RF-12-150 3RF-15-150 3RF-19-150 3RF-20-150 3RF-24-150 Vnom. 12V 15V 19V 20V 24V Output Imax. 12.5A 10.0A 7.89A 7.5A 6.25A Imin. 0A 0A 0A 0A 0A 3F & 3RF SERIES Maximum Tol. 5% 5% 5% 5% 5% Output Power 150W 150W 150W 150W 150W Ripple and noise: Peak-to-peak with 20MHz bandwidth and 47µF tantalum capacitor in parallel with a 0.1µF ceramic capacitor at rated line voltage and load ranges. M ECHANICAL SPECIFICATIONS or IEC 320/C6 INLET (3 round pins) NOTES: 1. Dimensions shown in inch [mm] 2. Tolerance 0.02 [0.5] maximum 3. Weight: 800 grams approx. 4. Standard output connector is a 4-pin power DIN. Please consult TRUMPower for other connector options. 5. The length of the output cable on 3F-12-150 and 3RF-12-150 is 37.4″ (950.0mm). P IN CHART 1 2 3 4 S hell of connector Output +V Output +V Return Return DC Return & AC Ground Tumbler Technologies + TRUMPower 3350 Scott Blvd., Bldg. 13, Santa Clara, California 95054, USA Phone: 408-988-6616 ● Fax: 408-988-6622 ● email: sales@trumpower.com ● Website: www.TRUMPower.com
