3G-19-180

TRUMPower D E S C R IP T IO N T he 3G & 3RG series of AC/DC desktop power adapters are capable of delivering 180 watts continuous DC power. They are enclosed in a 94V-1 rated polyphenylene-oxide case with an IEC 320/C14 or IEC 320/C6 inlet to mate with interchangeable cord for world-wide use. All model meet CISPR 22 and FCC class B emission limits, and comply with UL, CSA, IEC and CE requirements. 180 WATT POWER ADAPTERS 3G & 3RG SERIES RoHS F E AT U R E S ‧ High Efficiency ‧ ‧ ‧ ‧ ‧ ‧ ‧ Low Ripple & Noise O v e r v o l ta g e p r o t e c t i o n Short-circuit protection Overpow er protection Over temperature protection 100% burn-in at full rated load C o m p l i a n t w i t h C E C a n d E n e r g y S ta r e f f i c i e n c y l e v e l I V r e q u i r e m e n ts ‧ No load power consumption less than 0.5W ‧ Av e r a g e a c t i v e e f f i c i e n c y ≥ 8 5 % ‧ C o m p l i a n t w i t h R o H S r e q u i r e m e n ts S a f e t y Sta n d a r d A p p r o va l s ： UL 60950 CSA C22.2 No. 60950 TÜV EN60950-1 I N P U T S P E C I F I C AT I O N S I n p u t v o l ta g e ： Input frequency： Input current： Earth leakage current: ( To u c h c u r r e n t ) 9 0 t o 2 6 4 VA C 47 to 63 Hz 2 . 5 A （ r m s ） f o r 11 5 VA C 1 . 2 5 A （ r m s ） f o r 2 3 0 VA C 1 5 0 µ A m a x . @ 11 5 VA C , 6 0 H z 2 5 0 µ A m a x . @ 2 3 0 VA C , 5 0 H z G ENERAL SPECIFICATIONS H old-up time ： Turn on delay time： Power Factor： E fficiency ： L ine regulation ： I nrush current ： 5 m sec minimum at 100VAC or 240VAC 3 sec maximum at 100VAC 0 .95 typical 8 7% minimum at 100VAC or 240VAC. ± 0.5% maximum at full load 1 20A max. @ 240VAC cold start O UTPUT SPECIFICATIONS O utput voltage/current ： Total output power ： R ipple and noise ： S ee rating chart S ee rating chart 3 80mV peak to peak maximum W ithstand voltage ： 3000VAC from input to output 1500VAC from input to ground M TBF ： 1 00,000 hours at full load at 25ºC ambient, calculated per MIL-HDBK- 217F E MC Performance (EN55024) EN55022: C lass B conducted, Class B radiated FCC: C lass B conducted, Class B radiated VCCI: C lass B conducted, Class B radiated EN61000-3-2: H armonic distortion, Class D EN61000-3-3: Line flicker EN61000-4-2: ESD, ±8KV air and ±4KV contact EN61000-4-3: R a d i a t e d i m m u n i t y, 3 V / m EN61000-4-4: Fast transient/burst, ±1KV EN61000-4-5: Surge, ±1KV diff, ±2KV com. EN61000-4-6: C o n d u c t e d i m m u n i t y, 3 Vr m s EN61000-4-8: M a g n e t i c f i e l d i m m u n i t y, 1 A / m E N 6 1 0 0 0 - 4 - 11 : Vo l t a g e d i p s , 3 0 % r e d u c t i o n f o r 500ms and >95% reduction for 10ms O v e r v o l ta g e p r o t e c t i o n ： S et at 110-140% of its nominal output voltage O v e r c u r r e n t p r o t e c t i o n ： A ll models protected to short circuit conditions Te m p e r a t u r e A ll outputs ±0.04%/ºC maximum coefficient： Tr a n s i e n t r e s p o n s e ： M aximum excursion of 4% or better on all models, recovering to 1% of final value within 500µs after a 25% step load change E N V I R O N M E N TA L S P E C I F I C AT I O N S O p e r a t i n g t e m p e r a t u r e ： 0ºC to +40ºC Storage temperature： -20ºC to +80ºC Relative humidity： 10% to 90% non-condensing Tumbler Technologies + TRUMPower 3350 Scott Blvd., Bldg. 13, Santa Clara, California 95054, USA Phone: 408-988-6616 ● Fax: 408-988-6622 ● email: sales@trumpower.com ● Website: www.TRUMPower.com UNIVERSAL INPUT OUTPUT VOLTAGE/CURRENT RATING CHART Product No. IEC 320/C14 Inlet 3G-18-180 3G-19-180 3G-24-180 3G-48-180 IEC 320/C6 Inlet 3RG-18-180 3RG-19-180 3RG-24-180 3RG-48-180 Vnom. 18V 19V 24V 48V Output Imax. 10.0A 9.47A 7.5A 3.75A Imin. 0A 0A 0A 0A 3G & 3RG SERIES Maximum Tol. 5% 5% 5% 5% Output Power 180W 180W 180W 180W N OTE: Ripple and noise: Peak-to-peak with 20MHz bandwidth and 47µF tantalum capacitor in parallel with a 0.1µF ceramic capacitor at rated line voltage and load ranges. M ECHANICAL SPECIFICATIONS or IEC 320/C6 INLET (3 round pins) NOTES: 1. Dimensions shown in inch [mm] 2 . To l e r a n c e 0 . 0 2 [ 0 . 5 ] m a x i m u m 3. Weight: 860 grams approx. 4 . St a n d a r d o u t p u t c o n n e c t o r i s a m a l e 4 - p i n p o w e r D I N p l u g . P l e a s e c o n s u l t T R U M P o w e r f o r o t h e r o p t i o n s . P IN CHART 1 2 3 4 S hell of Connector Output +V Output +V Return Return Return & AC Ground Tumbler Technologies + TRUMPower 3350 Scott Blvd., Bldg. 13, Santa Clara, California 95054, USA Phone: 408-988-6616 ● Fax: 408-988-6622 ● email: sales@trumpower.com ● Website: www.TRUMPower.com
