3RE-30-120

TRUMPower D E SCR IPTION T he 3RE series of AC/DC desktop power adapters are capable of delivering 120 watts of continuous output power. They are enclosed in a 94V-1 rated polyphenylene-oxide case with an IEC 320/C6 inlet to mate with interchangeable cord for world-wide use. All models meet CISPR 22 and FCC class B emission limits and comply with UL, CSA, IEC and CE requirements. 120 WATT POWER ADAPTERS 3 RE SERIES RoHS F EATU R E S ‧ High efficiency ‧ ‧ ‧ ‧ ‧ ‧ ‧ ‧ Low ripple & noise O v e r v o l ta g e p r o t e c t i o n Short-circuit protection Overpow er protection Over temperature protection 100% burn-in at full rated load S ta n d b y c o n s u m p t i o n l e s s t h a n 0 . 5 W C o m p l i a n t w i t h C E C a n d E n e r g y S ta r e f f i c i e n c y l e v e l I V r e q u i r e m e n ts (For all models except 3RE-12-96) ‧ No load power consumption less than 0.5W ‧ Av e r a g e a c t i v e e f f i c i e n c y ≥ 8 5 % ‧ C o m p l i a n t w i t h R o H S r e q u i r e m e n ts S af et y Sta n da rd A ppr o va ls ： U L 60950 3rd CSA C22.2 No. 60950 3rd I N PUT S PE C IF ICAT ION S I n p u t v o l ta g e : Input frequency: Input current: Earth leakage current: (Touch current) 9 0 t o 2 6 0 VA C 47 to 63Hz 2 . 0 A ( r m s ) f o r 11 5 VA C 1 . 0 A ( r m s ) f o r 2 3 0 VA C 1 5 0 µ A m a x . @ 11 5 VA C , 6 0 H z 2 5 0 µ A m a x . @ 2 3 0 VA C , 5 0 H z N emko EN60950:2000 GENERAL SPECIFICATIONS H old-up time: Turn on delay time: P ower factor: E fficiency: L ine regulation: I nrush current: W ithstand voltage: M TBF: 1 5 msec minimum at 115VAC 2 seconds maximum 0.98 typical at 115VAC 86% min. (80% min. on 3RE-12-96, 3RE-15-105 ) ± 0.5% maximum at full load 6 0 amps @ 115VAC or 90 amps @ 230VAC, at 25ºC cold start 3 000VAC from input to output 1500VAC from input to ground 1 50,000 hours at full load at 25ºC ambient, calculated per MIL-HDBK- 217F C lass B conducted, Class B radiated C lass B conducted, Class B radiated C lass B conducted, Class B radiated H armonic distortion, Class A and D L ine flicker E SD, ±8KV air and ±4KV contact R adiated immunity, 3V/m F ast transient/burst, ±1KV S urge, ±1KV diff, ±2KV com. C onducted immunity, 3Vrms M agnetic field immunity, 1A/m Voltage dips, 30% reduction for 500ms and >95% reduction for 10ms OUTPUT SPECIFICATIONS O utput voltage/current: Total output power: R ipple and noise: O vervoltage protection: O vercurrent protection: Temperature coefficient: Transient response: See rating chart See rating chart 350mV peak to peak maximum S e t a t 11 0 - 1 4 0 % o f i t s nominal output voltage All models protected to short circuit conditions All outputs ±0.04%/ºC maximum Maximum excursion of 4% or better on all models, recovering to 1% of final value within 500µs after a 25% step load change E MC Performance (EN55024) EN55022: FCC: VCCI: EN61000-3-2: EN61000-3-3: EN61000-4-2: EN61000-4-3: EN61000-4-4: EN61000-4-5: EN61000-4-6: EN61000-4-8: E N 6 1 0 0 0 - 4 - 11 : E N V IR O N M ENTA L SP E C IF ICATI O N S O perating temperature: S torage temperature: R elative humidity: 0ºC to +40ºC -20ºC to +80ºC 10% to 95% non-condensing Tumbler Technologies + TRUMPower 3350 Scott Blvd., Bldg. 13, Santa Clara, California 95054, USA Phone: 408-988-6616 ● Fax: 408-988-6622 ● email: sales@trumpower.com ● Website: www.TRUMPower.com U NIVERSAL INPUT OUTPUT VOLTAGE/CURRENT RATING CHART Output Product No. 3RE-12-96 3RE-15-105 3RE-18-120 3RE-19-120 3RE-20-120 3RE-24-120 3RE-30-120 3RE-36-120 3RE-48-120 NOTE: Vnom. 12V 15V 18V 19V 20V 24V 30V 36V 48V Imax. 8.0A 7.0A 6.67A 6.32A 6.0A 5.0A 4.0A 3.34A 2.5A Imin. 0A 0A 0A 0A 0A 0A 0A 0A 0A To l . 5% 5% 5% 5% 5% 5% 5% 5% 5% 3RE SERIES Maximum Output Pow er 96W 105W 120W 120W 120W 120W 120W 120W 120W Ripple and noise: Peak-to-peak with 20MHz bandwidth and 10µF tantalum capacitor in parallel with a 0.1F ceramic capacitor at rated line voltage and load ranges. M ECHANICAL SPECIFICATIONS PIN# DC OUTPUT NOTES: 1. Dimensions shown in inch [mm] 2. Tolerance 0.02 [0.5] maximum 3. Weight: 621 grams approx. 4. Standard output connector is a 4-pin power DIN plug. Please consult TRUMPower for other connector options. P IN CHART P IN Product No. 3RE-12-96 3RE-18-120 3RE-20-120 3RE-30-120 3RE-48-120 3RE-15-105 3RE-19-120 3RE-24-120 3RE-36-120 1 2 3 4 SHELL OF CONNECTOR Return Output +V Return Output +V DC Return & AC Ground Tumbler Technologies + TRUMPower 3350 Scott Blvd., Bldg. 13, Santa Clara, California 95054, USA Phone: 408-988-6616 ● Fax: 408-988-6622 ● email: sales@trumpower.com ● Website: www.TRUMPower.com
