BAS70-05

BAS70 / -04 / -05 / -06 200m Watts Surface Mount Schottky Barrier Diode SOT-23 0.020(0.51) 0.015(0.37) Features Low turn-on voltage Fast switching PN junction guard Ring for transient and ESD protection 0.080(2.05) 0.070(1.78) 0.024(0.61) 0.018(0.45) 0.120(3.05) 0.104(2.65) 0.055(1.40) 0.047(1.19) 0.098(2.50) 0.083(2.10) 0.041(1.05) 0.047(0.89) Mechanical Data Case: SOT-23, Molded plastic Terminals: Solderable per MIIL-STD-202, Method 208 Marking & Polarity: See diagram Weight: 0.008 grams 0.043(1.10) 0.035(0.89) 0.006(0.15) 0.001(0.013) 0.024(0.61) 0.018(0.45) 0.007(0.178) 0.003(0.076) Dimensions in inches and (millimeters) BAS70 Marking: 73 BAS70-04 Marking: 74 BAS70-05 Marking: 75 BAS70-06 Marking: 76 Maximum Ratings Type Number TA=25 C unless otherwise specified Symbol VRRM VRWM VR VR(RMS) o BAS70 70 49 70 100 200 625 -55 to + 125 -65 to + 150 Units V V mA mA mW K/W o o Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Forward Continuous Current (Note 1) Non-Repetitive Peak Forward Surge Current @ t ≦1.0s Power Dissipation (Note 1) Thermal Resistance Junction to Ambient Air (Note 1) Operating Junction Temperature Range Storage Temperature Range IF IFSM Pd RθJA TJ TSTG Symbol V(BR) IR VF Cj trr Min 70 _ _ _ _ C C Electrical Characteristics Type Number Reverse Breakdown Voltage (Note 2), IR=10uA Reverse Leakage Current tp
