CD4069

UNISONIC TECHNOLOGIES CO., LTD CD4069 INVERTER CIRCUIT DESCRIPTION The UTC CD4069 is a CMOS IC with six inverter circuits and designed for using of wide power supply operating range, low power consumption, high noise immunity, and symmetric controlled rise and fall times. The IC is capable of ESD protection by diode clamps to VDD and VSS. CMOS IC SOP-14 FEATURES * Wide supply voltage range: 3.0V ~ 15V. * High noise immunity: 0.45 VDD typ. * Low Power TTL compatibility: Fan out of 2 driving 74L or 1 driving 74LS. DIP-14 *Pb-free plating product number: CD4069L ORDERING INFORMATION Order Number Normal Lead Free Plating CD4069-D14-T CD4069L-D14-T CD4069-S14-R CD4069L-S14-R CD4069-S14-T CD4069L-S14-T Package DIP-14 SOP-14 SOP-14 Packing Tube Tape Reel Tube CD4069L-D14-T (1)Packing Type (2)Package Type (3)Lead Plating (1) R: Tape Reel, T: Tube (2) D14: DIP-14, S14: SOP-14 (3) L: Lead Free Plating, Blank: Pb/Sn www.unisonic.com.tw Copyright © 2005 Unisonic Technologies Co., Ltd 1 of 7 QW-R502-020,B CD4069 PIN CONFIGURATION CMOS IC VDD 14 13 12 11 10 9 8 1 2 3 4 5 6 7 VSS BLOCK DIAGRAM VDD P VIN N VSS VOUT UNISONIC TECHNOLOGIES CO., LTD www.unisonic.com.tw 2 of 7 QW-R502-020,B CD4069 ABSOLUTE MAXIMUM RATINGS PARAMETER DC Supply Voltage Input Voltage Storage Temperature Range SYMBOL VDD VIN TS CMOS IC RATINGS UNIT -0.5 ~ +18 V -0.5 ~ VDD +0.5 V -65 ~ +150 ℃ DIP-14 700 mW Power Dissipation PD SOP-14 500 mW Junction Temperature TJ 125 ℃ Operating Temperature TOPR -20 ~ +85 ℃ Storage Temperature TSTG -40 ~ +150 ℃ Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. RECOMMENDED OPERATING CONDITIONS (VSS=0V ) PARAMETER DC Supply Voltage Input Voltage Operating Temperature Range SYMBOL VDD VIN Ta RATINGS 3 ~ 15 0 ~ VDD -40 ~ +85 UNIT V V ℃ DC ELECTRICAL CHARACTERISTICS (VSS=0V, Ta=25℃, unless otherwise specified.) PARAMETER Quiescent Device Current SYMBOL IDD CONDITIONS VDD=5V, VIN=VDD or VSS VDD=10V, VIN=VDD or VSS VDD=15V, VIN=VDD or VSS |IO|
