CO-402

Vectron Products - Custom Hybrid TTL Clock Oscillators - CO-402 Page 1 of 3 Helping Customers Innovate, Improve & Grow Search XOs > CO-402 CO-402 Custom Hybrid TTL Clock Oscillators Features: Low Profile 14 Pin DIP Resistance Welded Metal Can 3 Point Mount Crystal 16 kHz to 100 MHz Frequency Range Available as QPL to Mil-0-55310/16 B&S SPECIFICATIONS Series Frequency Supply Accuracy (at 25°C) CO-402: 14 Pin DIP 16 kHz-100 MHz 5 Vdc ± 5% CO-402A ±50 ppm CO-402C ±25 ppm CO-402D ±15 ppm CO-402B ±10 ppm CO-402E ±1 ppm* *Settability via external capacitor; 16 kHz-60 MHz only. Temperature Stability Improved accuracy/stability available on some models. For example, for ±7 ppm over 0°C to +50°C and for ±10ppm over 0°C to +70°C. Improvement is also available over wider temperature ranges. Please contact factory. STANDARD: Option 1: Option 2: Option 5: Option 6: Option 7: *Option 9: 0°C -55°C -55°C 0°C 0°C -55°C -55°C to +70°C: to +85°C: to +125°C: to +50°C: to +50°C: to +125°C: to +200°C: ±25 ppm ±50 ppm ±50 ppm ±5 ppm ±10 ppm ±100 ppm ±300 ppm (Option 9: Only for CO-401/2/6/7 series in 4-20 MHz range) *Specified stability includes initial accuracy: do not specify A,B,C,D or E accuracy. Aging Rate (typical after 30 days) Case Output 3 ppm first year 2 ppm/year thereafter Resistance welded metal case Output: Drive: "0" Level: "1" Level: Rise/Fall Time: (0.5-2.4V) Symmetry: at 1.5V
