CS-300-DFC-R4D2M2

CS-300 Clock Smoother Features • • • • • • • Output frequencies to 850 MHz Ultra Low Jitter LVPECL, LVDS Outputs Locks to Input Frequency (i.e. 622.08 MHz) 3.3 Vdc or 5.0 Vdc supply Lock / Loss of Signal Alarm 1” x 0.8” x 0.25”, Surface Mount (FR4 base) Product is compliant to RoHS directive Applications • • • • SONET / SDH / ATM DWDM / FDM DSL – PON Interconnects FEC (Forward Error Correction) CS-300 Clock Smoother Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 2 of 8 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 02Jan07 CS-300 Clock Smoother Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 3 of 8 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 02Jan07 CS-300 Clock Smoother Reflow Profile (IPC/JEDEC J-STD-020C) Parameter Symbol PreHeat Time Ramp Up Time Above 217 oC Time To Peak Temperature Time At 260 oC Ramp Down tS R UP tL t AMB-P tP R DN Value 60 sec Min, 180 sec Max 3 oC/sec Max 60 sec Min, 150 sec Max 480 sec Max 20 sec Min, 40 sec Max 6 oC/sec Max The CS-300 is being qualified to meet the JEDEC standard for Pb-Free assembly. The temperatures and time intervals listed are based on the Pb-Free small body requirements. The temperatures refer to the topside of the package, measured on the package body surface. The CS-300 should not be subjected to a wash process that will immerse it in solvents. NO CLEAN is the recommended procedure. The CS-300 has been designed for pick and place reflow soldering. The CS-300 may be reflowed once and should not be reflowed in the inverted position. 260 tL R tP R DN tS t AMB-P Temperature (DegC) 217 200 150 25 Time (sec) Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 4 of 8 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 02Jan07 CS-300 Clock Smoother Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 5 of 8 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 02Jan07 CS-300 Clock Smoother Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 6 of 8 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 02Jan07 CS-300 Clock Smoother Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 7 of 8 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 02Jan07 CS-300 Clock Smoother X G = RoHS Blank = May contain Pb For Additional Information, Please Contact: USA: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: 1-88-VECTRON-1 Fax: 1-888-FAX-VECTRON EUROPE:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: +49 (0) 7268 8010 Fax: +49 (0) 7268 8012 81 ASIA: . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: +86-21-5048-0777 Fax: +86-21-5048-1881 Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 8 of 8 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 02Jan07
