FX-101_10

• RoHS/Lead Free Compliant Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 2 of 7 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 10Nov06 Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 3 of 7 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 10Nov06 Reflow Profile (IPC/JEDEC J-STD-020C) Parameter Symbol PreHeat Time Ramp Up Time Above 217 oC Time To Peak Temperature Time At 260 oC Ramp Down tS R UP tL t AMB-P tP R DN Value 60 sec Min, 180 sec Max 3 oC/sec Max 60 sec Min, 150 sec Max 480 sec Max 20 sec Min, 40 sec Max 6 oC/sec Max The FX-101 is being qualified to meet the JEDEC standard for Pb-Free assembly. The temperatures and time intervals listed are based on the Pb-Free small body requirements. The temperatures refer to the topside of the package, measured on the package body surface. The FX-101 should not be subjected to a wash process that will immerse it in solvents. NO CLEAN is the recommended procedure. The FX-101 has been designed for pick and place reflow soldering. The FX-101 may be reflowed once and should not be reflowed in the inverted position. 260 tL R tP R DN tS t AMB-P Temperature (DegC) 217 200 150 25 Time (sec) Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 4 of 7 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 10Nov06 Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 5 of 7 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 10Nov06 eliability Handling Precautions Although ESD protection circuitry has been designed into the FX-101 proper precautions should be taken when handling and mounting. VI employs a human body model (HBM) and a charged-device model (CDM) for ESD susceptibility testing and design protection evaluation ESD Ratings Model Human Body Model Charged Device Model Minimum 500 V 500 V Conditions MIL-STD 883, Method 3015 JEDEC, JESD22-C101 Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 6 of 7 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 10Nov06 FX-101-DAC-D1S2G – 8 kHz, 1.544 MHz, 2.048 MHz, 19.44 MHz For Additional Information, Please Contact: USA: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: 1-88-VECTRON-1 Fax: 1-888-FAX-VECTRON EUROPE:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: +49 (0) 7268 8010 Fax: +49 (0) 7268 8012 81 ASIA: . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tel: +86-21-5048-0777 Fax: +86-21-5048-1881 Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Vectron International, 267 Lowell Road, Hudson, NH 03051 Page 7 of 7 Tel: 1-88-VECTRON-1 • Web: www.vectron.com Rev: 10Nov06
