PX-200 Crystal Oscillator PX-200 Features • • • • Miniature Hybrid Design 16 Pin Flatpack Frequency Range: 4 MHZ to 500 MHZ Previous Model: CO-487 Applications Performance Speci cations Parameter vs. operating temperature range (referenced to +25°C) Min -5 -10 -25 -50 -50 -100 -50 -25 -15 -10 -1 -3 -2 Typ Max +5 +10 +25 +50 +50 +100 +50 +25 +15 +10 +1 +3 +2 Units ppm ppm ppm ppm ppm pbm ppm ppm ppm ppm ppm ppm ppm Condition 0… +50°C 0… +50°C 0… +70°C (standard) -55… +85°C -55… +125°C -55… +125°C @+25°C @+25°C @+25°C @+25°C Set via external capacitor (custom number required) after 30 days of operation Frequency Stabilities1 Initial tolerance vs. aging / 1 year vs. aging / year (following years) Supply Voltage (Vs) Supply voltage (Standard) 14.75 15.0 15.25 VDC RF Output Signal Output Power (Standard) +7 Sinewave dBm Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com Performance Speci cations Parameter Output Power (Option) Min +13 Typ Max Units dBm 1 Condition (custom number required) Additional Parameters Phase Noise3 (typical 4-100 MHZ) -100 -125 -140 -145 dBc/Hz dBc/Hz dBc/Hz dBc/Hz 100 Hz 1 kHz 10 kHz 100 kHz Screen Testing of Above Models SCREEN TEST Stabilization Bake (150°C) Seal Test (Gross and Fine) Temperature Cycling (Thermal Shock) Burn-in, operating 160 hours @125°C Acceleration (5000g in Y1 axis) MIL-STD-883 METHOD — 1014, Cond A2 1010, Cond B — 2001, Cond A Standard CLASS X X X CLASS B X X X X X Options CLASS S Class S screen test requirements include 24 hour additional bake-out, 80 hour additional burnin, thermal shock, PIND test and radiographic inspection in addition to Class B Screening. Has major cost impact. Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com Outline Drawing / Enclosure Pin Connections Dimensions in inches 8 9, 10 11 Pin Length “L” 0.4 16 Ground Output 200 Mhz: 0V, Case Supply Type A Code 0 Height “H” 0.17 Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com Ordering Information PX - 200 0 - A E T - F K X S - 10M0000000 Frequency Product Family PX: PXO Package 25 x 25 mm Height 0: A 0.17” Supply Voltage A: 15 Vdc Screening Option S: “S” Level screening B: “B” Level screening X: No Screening Enable Code X: No Option Stability Code A: ±5ppm B: ±10ppm F: ±25ppm K: ±50ppm S: ±100ppm Accuracy Code B: ±10ppm D: ±15ppm F: ±25ppm K: ±50ppm RF Output Code E: Sinewave (+7 dBm) Temperature Range A: -55°C to +85°C C: -55°C to +125°C P: 0°C to +50°C T: 0°C to +70°C Notes: 1. Contact factory for improved stabilities or additional product options. Not all options and codes are available at all frequencies. 2. Unless other stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency control voltage, load, temperature (25°C). 3. Phase noise degrades with increasing output frequency. 4. Subject to technical modi cation. 5. Contact factory for availability. For Additional Information, Please Contact USA: Vectron International 267 Lowell Road Hudson, NH 03051 Tel: 1.888.328.7661 Fax: 1.888.329.8328 Europe: Vectron International Landstrasse, D-74924 Neckarbischofsheim, Germany Tel: +49 (0) 3328.4784.17 Fax: +49 (0) 3328.4784.30 Asia: Vectron International 1F-2F, No 8 Workshop, No 308 Fenju Road WaiGaoQiao Free Trade Zone Pudong, Shanghai, China 200131 Tel: 86.21.5048.0777 Fax: 86.21.5048.1881 Disclaimer Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. Rev: 2/23/2009 daf Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
